Image preview - the first page of the document
![Panel_AUO_G190SVT01-0_0_[DS]](/pics/5c36ad2f6ffe6.gif)
>> Download Panel_AUO_G190SVT01-0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SVT01.0
AU OPTRONICS CORPORATION
Preliminary Specification
Final Specification
Module 19" Color TFT-LCD (Free Shape LCD) with Touch function
Model Name G190SVT01.0
Customer Date Approved by Date
Debbie Chiu 2012/1/12
Checked &
Date Prepared by Date
Approved by
Christine Huang 2012/1/12
Note: This Specification is subject to change General Display Business Division / AU
without notice. Optronics corporation
document version 1.0 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SVT01.0
AU OPTRONICS CORPORATION
Contents
1. Operating Precautions..................................................................................... 4
2. General Description......................................................................................... 5
2.1 Display Characteristics .......................................................................................................... 5
2.2 General Touch Specification .................................................................................................. 6
2.3 Optical Characteristics ........................................................................................................... 6
3. Functional Block Diagram ............................................................................. 10
4. Absolute Maximum Ratings .......................................................................... 11
4.1 Absolute Ratings of TFT LCD Module ................................................................................. 11
4.2 Absolute Ratings of Environment ........................................................................................ 11
5. Electrical Characteristics .............................................................................. 12
5.1 TFT LCD Module..................................................................................................................12
5.2 Backlight Unit .......................................................................................................................14
5.3 Touch Panel..........................................................................................................................15
6. Signal Characteristic ..................................................................................... 19
6.1 Pixel Format Image ..............................................................................................................19
6.2 Signal Description ................................................................................................................20
6.3 Touch Sensor Pin Assignment.............................................................................................21
6.4 The Input Data Format .........................................................................................................21
6.5 Interface Timing....................................................................................................................22
6.6 Power ON/OFF Sequence...................................................................................................23
7. Connector & Pin Assignment........................................................................ 24
7.1 TFT LCD Module: LVDS Connector ....................................................................................24
7.2 Backlight Unit: LED Connector ............................................................................................25
8. Reliability Test ............................................................................................... 26
9. Mechanical Characteristics ........................................................................... 27
10. Label and Packaging ................................................................................... 29
10.1 Definition of Label ..............................................................................................................29
10.2 Packaging Method .............................................................................................................30
10.3 Pallet and Shipment Information .......................................................................................31
11. Safety............................................................................................................ 32
11.1 Sharp Edge Requirements ................................................................................................32
11.2 Materials .............................................................................................................................32
11.3 Capacitors ..........................................................................................................................32
11.4 National Test Lab Requirement .........................................................................................32
document version 1.0 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SVT01.0
AU OPTRONICS CORPORATION
Record of Revision
Version and
Page Old description New Description Remark
Date
0.1 2011/11/15 All First Edition for Customer All
document version 1.0 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SVT01.0
AU OPTRONICS CORPORATION
1. Operating Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when handling.
7) Do not open or modify the Module Assembly.
8) In case if a Module has to be put back into the packing container slot after once it was taken out from the
container, take it easily, or the TFT Module may be damaged.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface
Connector of the TFT Module.
10) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even momentary.
At designing the enclosure, it should be taken into consideration that no bending/twisting forces are applied to
the TFT Module from outside. Otherwise the TFT Module may be damaged.
11) Small amount of materials having no flammability grade is used in the LCD module. The LCD module should
be supplied by power complied with requirements of Limited Power Source (IEC60950 or UL1950), or be
applied exemption.
12) Severe temperature condition may result in different luminance, response time and LED life time.
13) The data on this specification sheet is applicable when LCD module is placed in landscape position.
14) Continuous displaying fixed pattern may induce image sticking. It is recommended to use screen saver or
shuffle content periodically if fixed pattern is displayed on the screen.
document version 1.0 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SVT01.0
AU OPTRONICS CORPORATION
2. General Description
This specification applies to the 19 inch-wide Color TFT-LCD Module G190SVT01.0.
The display supports the 1680(H) x 342(V) screen format and 16.7M colors. All input signals are 2 Channels LVDS
interface compatible.
LED driver board is included. G190SVT01.0 is designed for industrial display applications.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Screen Diagonal [inch] 19
Active Area [mm] 473.76 (H) x 96.44(V)
Pixels H x V 1680x3(RGB) x 342
Pixel Pitch [mm] 0.282x 0.282
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode P-MVA Mode,Normally Black
ack
Nominal Input Voltage VDD [Volt] +5.0 V
18W (Base Panel)+400mW(Touch Panel)
Typical Power Consumption [Watt]
=18.4W
Weight [Grams] 1100 (Base Panel)+ 380(TP)=1480
Physical Size [mm] 497.7(W) x 126.8(H) x 21.66(D) (Max.)
Electrical Interface D
Dual Channel LVDS
Surface Treatment Anti-glare, Hardness 7H
Support Color 16.7M colors (6-bits + HiFRC)
Temperature Range
o
Operating [ C] 0 to +50
o
Storage (Non-Operating) [ C] -20 to +60
RoHS Compliance RoHS Compliance
document version 1.0 5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SVT01.0
AU OPTRONICS CORPORATION
2.2 General Touch Specification
Items Unit Specifications
Detection Method Projective Capacitive
Touch Glass type G/G
Sensor Glass Dimension mm 491.7 x 122.8 x 0.5
Cover lens outline dimension mm 497.7 x 126.8 x 1.8
Black ink open area mm 475.56 x 98.24
Touch Active Area mm 476.76 x 99.44
Capacitive Sense pad size mm 9.17 (W) x 9.04 (H)
The smallest distance between 2 points mm 25
Interface Micro USB
IC Driver RM31080(AUO-T402-3C)
Channel 52X11
Light Transmission % 85%(min), 88%(Typ.)
Haze % 5~10
Touch Panel Strength mpa 400(TBD)
Windows 7,Windows XP, Win CE, Anroid, Linux
Operation System
(see note 1
Touch Points Points 10
iona
o
G190SVT01.0 is compatible with Windows 7 with no additional software.
Remember not all applications are multi-touch ready. Multi-touch behavior is a function of Your application. Check your
application vendor to determine if your software has multi-touch capability(you may refer to the User guide for software
development)
2.3 Optical Characteristics
The optical characteristics are measured under stable conditions at 25
ea (Room Temperature):
Item Unit
U Conditions Min. Typ. Max. Note
[
[cd/m2]
White Luminance IF= 80mA 210 260 - 1
%
Uniformity 9 Points 75 80 - 1, 2, 3
atio
t
Contrast Ratio 1600 2000 - 4
document version 1.0 6
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SVT01.0
AU OPTRONICS CORPORATION
Cross talk %
- - 1.5 5
Rising - 15 -
Falling - 5 - 6
Response Time [msec]
Rising + Falling - 20 -
Gray to Gray - 8 -
[degree] Horizontal (Right) 75 89 -
[degree] CR = 10 (Left)
75 89 -
Viewing Angle 7
[degree] Vertical (Upper) 75 89 -
[degree] CR = 10 (Lower)
75 89 -
Red x TBD TBD TBD
Red y TBD TBD TBD
Green x TBD TBD TBD
Color / Chromaticity Green y TBD TBD TBD
Coordinates
(CIE 1931) Blue x TBD TBD TBD
Blue y TBD TBD TBD
White x 0.252 0.302 0.352
0.
White y 0.263 3
0.313 0.363
0
Color Gamut % - 68
68 -
Note 1: Measurement method
Equipment Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter (SR_3 or equivalent)
Aperture
Test Point Center
Environment < 1 lux
LCD Module
SR_3 or
equivalent
M
Measuring distance
Module Driving Equipment
document version 1.0 7
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SVT01.0
AU OPTRONICS CORPORATION
Note 2: Definition of 9 points position (Display active area)
90 % 50 % 10 %
10 %
50 %
90 %
Note 3: The luminance uniformity of 9 points is defined by dividing the minimum luminance values by the maximum test
point luminance
Minimum Brightness of nine points
W9 =
Maximum Brightness of nine points
Note 4 Definition of contrast ratio (CR):
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
k
Note 5 Definition of cross talk (CT)
