Image preview - the first page of the document
![Panel_AUO_M170EP01_V2_0_[DS]](/pics/5c36adaebab25.gif)
>> Download Panel_AUO_M170EP01_V2_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
AU OPTRONICS CORPORATION
Product Specification
17.0" SXGA Color TFT-LCD Module
Model Name: M170EP01 V.2
Approved by Prepared by
CC Chiou RogerYang
DDBU Marketing Division / AU Optronics corporation
Customer Checked & Approved by
Ver0.1 1/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
Page intentionally left blank.
Ver0.1 2/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
Product Specification
17.0" SXGA Color TFT-LCD Module
Model Name: M170EP01
V.2
( ) Preliminary Specifications
(...) Final Specifications
Note: This Specification is subject to change without notice.
Ver0.1 3/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
Page intentionally left blank.
Ver0.1 7/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
Contents
2.0 General Description ............................................................ 13
2.1 Display Characteristics..................................................................................................... 13
2.2 Functional Block Diagram ................................................................................................. 14
2.3 Optical Characteristics ..................................................................................................... 15
2.4 Pixel format image.......................................................................................................... 17
3.0 Electrical characteristics ..................................................... 18
3.1 Absolute Maximum Ratings ............................................................................................... 18
3.2 Connectors .................................................................................................................. 19
3.3 Pin Assignment ............................................................................................................. 20
3.4 Signal Description .......................................................................................................... 21
3.5 Signal Electrical Characteristics .......................................................................................... 24
3.6 Interface Timings ........................................................................................................... 24
3.6.1 Timing Characteristics ........................................................................................... 24
3.6.2 Definition of terms ................................................................................................ 25
3.8 Power ON/OFF Sequence ................................................................................................ 27
4.0 Backlight Characteristics .................................................... 29
4.1 Signal for Lamp connector ................................................................................................ 29
4.2 Parameter guideline for CCFL Inverter.................................................................................. 29
5.0 Vibration, Shock, and Drop ................................................. 31
5.1 Vibration & Shock........................................................................................................... 31
5.2 Drop test ..................................................................................................................... 31
6.0 Environment ....................................................................... 32
6.1 Temperature and Humidity................................................................................................ 32
6.1.1 Operating Conditions............................................................................................. 32
6.1.2 Shipping Conditions .............................................................................................. 32
6.2 Atmospheric Pressure ..................................................................................................... 32
6.3 Thermal Shock .............................................................................................................. 32
7.0 Reliability............................................................................ 33
7.1 Failure Criteria .............................................................................................................. 33
7.2 Failure Rate.................................................................................................................. 33
7.2.1 Usage.................................................................................................................. 33
8.0 Safety ................................................................................. 34
8.1 Sharp Edge Requirements ................................................................................................ 34
8.2 Materials ..................................................................................................................... 34
8.2.1 Toxicity ............................................................................................................... 34
8.2.2 Flammability ........................................................................................................ 34
8.3 Capacitors ................................................................................................................... 34
9.0 Other requirement .............................................................. 35
Ver0.1 8/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
9.1 National Test Lab Requirement .......................................................................................... 35
9.2 Label .......................................................................................................................... 35
10.0 Mechanical Characteristics................................................ 36
Ver0.1 9/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
Record of Revision
Version and Date Page Old description New Description Remark
0.1 4/26/2005 All First Edition for Customer All
Ver0.1 10/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
Page intentionally left blank.
Ver0.1 11/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
1.0 Handling Precautions
1) Do not scratch the front polarier of panel. The front polarier is easily damaged
2) Be sure to turn off power supply when inserting and disconnecting from input connector.
3) Wipe off water drop immediately. Contacted with water in a long time may cause discoloration or spots.
4) Use absorbent cotton or other kind of soft cloth to wipe when the panel is dusty.
5) Do not drop it on hard surface. The face of panel is fragile
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) The TFT module will be damaged if the center of the CCFL reflector is pressed heavily.
10) Keep the connector interface straight during the period of inserting and disconnecting it.
11) Do not twist nor bend the TFT Module even momentary. At designing the enclosure, it should be taken into
consideration that no bending/twisting forces are applied to the TFT module from outside. Otherwise the TFT
module may be damaged.
Ver0.1 12/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
2.0 General Description
This specification applies to the 17.0 inch Color TFT/LCD Module M170EP01 V0.
This module is designed for a display unit of personal computer.
The display supports the SXGA (1280(H) x 1024(V)) screen format and 16.2M colors (RGB 6-bits + FRC data).
The input signal is Analog RGB interface compatible, DVI interface optional.
This module does not contain an inverter card for backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 432(17.0")
Active Area [mm] 337.920 (H) x 270.336(V)
Pixels H x V 1280(x3) x 1024
Pixel Pitch [mm] 0.264 (per one triad) x 0.264
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
2 1
White Luminance [cd/m ] 300 (Typ)
2
Contrast Ratio 500:1(Typ)
Optical Rise Time/Fall Time [msec] 8 (Typ)
Input Voltage Required (VDD) [Volt] Min Typical Max
4.8 5.0 5.2
Power Consumption [Watt] 27 W(Typ) 0.5W (stand by)
(VDD line + CCFL line) (PDD=7 W, PCFL=20 W @Lamp=7.5mA)
Weight [Grams] 2000 (Typ)
Min. Typ. Max.
Horizatal(H) 358 358.5 359.0
Physical Size [mm]
Vertical(V) 296 296.5 297
Depth(D) 19.5 20 20.5
Electrical Interface VESA standard Analog RGB (DVI 1.0 optional)
Support Color 16.2M colors (RGB 6-bit + FRC data)
3
Plug & Play VESA DDC1/2B/2Bi/2B+/CI
Compability PC/MAC
Maximum Firmware Code Size [bite] 64K
Analog: 140MHz
Max. Pixel Clock [MHz]
Digital: 135MHz (optional)
White Point (CIE x,y) (0.313,0.329) +/-0.02
3
Auto Adjustment Yes
OSD function
Temperature Range
Operating [oC] 0 to +50
o
Storage (Shipping) [ C] -20 to +60
4
TC0-03 Compliance TC0'03 Compliance
1
at 7.5 mA
2
normal direction
3
with AUO standard firmware
4
AUO standard power module & firmware
Ver0.1 13/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
2.2 Functional Block Diagram
The following diagram shows the functional block of the 17.0 inches Color TFT/LCD Module:
Ver0.1 14/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
2.3 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) 60 70
CR = 10 (Left) 60 70 -
Viewing Angle [degree]
Vertical (Up) 60 70
CR = 10 (Down) 50 60 -
Contrast ratio Normal Direction 250 450 -
Raising Time - 6 9
Response Time [msec] Falling Time - 2 4 Note 1
Raising + Falling - 8 13
Red x 0.61 0.64 0.67
Red y 0.31 0.34 0.37
Color / Chromaticity Green x 0.26 0.29 0.32
Coordinates (CIE) Green y 0.58 0.61 0.64
Blue x 0.11 0.14 0.17
Blue y 0.04 0.07 0.10
Color Coordinates (CIE) White x 0.28 0.31 0.34
White White y 0.30 0.33 0.36
White Luminance @ CCFL 2
[cd/m ]
7.5mA (center) 250 300 Note 2
Luminance Uniformity [%] 75 80 Note 3
Crosstalk (in 75Hz) [%] 1.5 Note 4
Flicker dB -20
Equipment: Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter
(PR 880, BM-5A / BM7)
Aperture 1 with 100cm VD or 2 with 50cm viewing distance
Test Point Center (VESA point 9)
Environment < 1 lux
LCD Module
PR-880 /
BM5A /
BM7
measuring distance
Module Driving Equipment
Ver0.1 15/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
Note 1: Definition of Response time
The output signals of photodetector are measured when the input signals are changed from "Black" to "White"
(rising time), and from "White" to "Black "(falling time), respectively. The response time is interval between the
10% and 90% of amplitudes.
% Tr F Tr R
100
90
Optical
White Black White
response
10
0
Note 2: Definition of center brightness
The brightness of center is measured at 30mins when opening lamp.
Note 3: Brightness uniformity of these 9 points is defined as below
90 % 50 % 10 %
10 %
50 %
90 %
Minimum Luminance in 9 points (1 - 9)
Uniformity =
Maximum Luminance in 9 Points (1 - 9)
Ver0.1 16/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
Note 4:
1/2 1/6 2/3 1/2 1/3 1/6
1/6
A A' 1/6
1/3
1/2 1/2
B B'
2/3
184 gray level 184 gray level
Unit: percentage of dimension of display area 0 gray level
l LA-LA' l / LA x 100%= 1.5% max., LA and LB are brightness at location A and B
l LB-LB' l / LB x 100%= 1.5% max., LA' and LB' are brightness at location A' and B'
2.4 Pixel format image
Following figure shows the relationship of the input signals and LCD pixel format.
1 2 1279 1280
1st Line R G B R GB R GB R G B
1024th R G B R GB R GB R G B
Ver0.1 17/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
3.0 Electrical characteristics
3.1 Absolute Maximum Ratings
Absolute maximum ratings of the module is as following:
Item Symbol Min Max Unit Conditions
Logic/LCD Drive Voltage VIN +4.5 +5.5 [Volt]
CCFL Current ICFL - 8.5 [mA] rms
o
Operating Temperature TOP 0 +50 [ C] Note
Operating Humidity HOP 8 95 [%RH] Note
o
Storage Temperature TST -20 +60 [ C] Note
Storage Humidity HST 8 95 [%RH] Note
Note : Maximum Wet-Bulb should be 39 and No condensation.
Ver0.1 18/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
3.2 Connectors
Physical interface is described as for the connector on module.
These connectors are capable of accommodating the following signals and will be following components.
Connector Name / Designation Power Connector (J1)
Manufacturer STM or compatiable
Type Part Number STM MS242612R
Mating Housing Part Number STM P242612
Connector Name / Designation OSD Connector (J4)
Manufacturer STM or compatiable
Type Part Number STM MS242613R
Mating Housing Part Number STM PS242613
Connector Name / Designation VGA Connector (J2)
Manufacturer STM or compatiable
Type Part Number STM MS242614R
Mating Housing Part Number STM P242614R
Connector Name / Designation DVI Connector (optional)
Manufacturer STM or compatiable
Type Part Number STM MDS240315
Mating Housing Part Number STM PDS240315
Connector Name / Designation Lamp Connector / Backlight lamp
Manufacturer JST
Type Part Number BHSR-02VS-1
Mating Type Part Number SM02(4.0)B-BHS-1-TB
Ver0.1 19/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
3.3 Pin Assignment
VGA connector
Pin # Signal Name Pin # Signal Name
1 GND 2 VS
3 HS 4 GNDB
5 BIN 6 GNDG
7 GIN 8 GNDR
9 RIN 10 GND
11 SDA 12 SCL
13 PC5V 14 VGA_CON
Power connector
Pin # Signal Name Pin # Signal Name
1 VCC 2 VCC
3 GND 4 GND
5 NC 6 GND
7 BKLT_ADJ 8 BKLT_EN
9 AUDIO _EN 10 MUTE
11 VOLUME 12 GND
OSD connector
Pin # Signal Name Pin # Signal Name
1 GND 2 SOURCE
3 SELECT 4 LED_G
5 LED_A 6 UP
7 DOWN 8 MINUS
9 PLUS 10 MENU
11 Power 12 NC
13 GND
DVI connector (optional)
Pin # Signal Name Pin # Signal Name
1 GND 2 GND
3 RX2+ 4 DVI_5V
5 RX2- 6 HPD
7 GND 8 GND
9 RX1+ 10 SDA
11 RX1- 12 SCL
13 GND 14 GND
15 RX0+ 16 NC
17 RX0- 18 NC
19 GND 20 GND
21 RXC+ 22 DVI_CON
23 RXC- 24 GND
25 GND 26 NC
27 NC 28 GND
29 GND 30 NC
Ver0.1 20/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
3.4 Signal Description
The module using analog RGB signal format (DVI optional). The signal description is listed as following table
VGA connector (J2)
Pin# Sugnal Name Description
1 GND Ground
2 VS Vsync input from VGA host
3 HS Hsync input from VGA host
4 GNDB Ground for the video blue signal
5 BIN Video blue signal
6 GNDG Ground for the video green signal
7 GIN Video green signal
8 GNDR Ground for the video red signal
9 RIN Video red signal
10 GND Ground
11 SDA Data signal for the DDC2B
12 SCL Clock signal for the DDC2B
13 PC5V DC 5V from the PC host
14 VGA_CON Video cable connected detect signal(host connect this pin to ground)
Power connector (J1)
Pin# Sugnal Name Description
1 VCC DC 5V
2 VCC DC 5V
3 GND Ground
4 GND Ground
5 NC NC
6 GND Ground
7 BKLT_ADJ Light adjust for the DC/AC inverter(PWM)
8 BKLT_EN Enable for the DC/AC inverter
9 AUDIO _EN Enable audio power control signal
10 MUTE Mute audio
11 VOLUME Adjust audio volume(PWM)
12 GND Ground
OSD connector (J4)
Pin# Sugnal Name Description
1 GND Ground
2 SOURCE OSD item source function.
3 SELECT OSD item select function.
4 LED_G LED Green for the full mode.
5 LED_A LED Amber for the sleep mode.
6 UP OSD up selection function.
7 DOWN OSD down selection function.
8 MINUS OSD minus selection function.
9 PLUS OSD plus selection function.
10 MENU OSD menu on/off function.
11 Power Power on/off function.
12 NC
13 GND Ground
Ver0.1 21/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
DVI interface (J3 optional)
Pin# Sugnal Name Description
1 GND Ground
2 GND Ground
3 RX2+ TMDS RX2+ signal
4 DVI_5V DC 5V from the PC host
5 RX2- TMDS RX2- signal
6 HPD Host detect for the DVI
7 GND Ground
8 GND Ground
9 RX1+ TMDS RX1+ signal
10 SDA Data signal for the DDC2B
11 RX1- TMDS RX1- signal
12 SCL Clock signal for the DDC2B
13 GND Ground
14 GND Ground
15 RX0+ TMDS RX0+ signal
16 NC
17 RX0- TMDS RX0- signal
18 NC
19 GND Ground
20 GND Ground
21 RXC+ TMDS RXC+ signal
22 DVI_CON DVI cable connected detect
23 RXC- TMDS RXC- signal
24 GND Ground
25 GND Ground
26 NC
27 NC
28 GND Ground
29 GND Ground
30 NC
Ver0.1 22/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
The input data format is followed the VESA Vedio Signal Standard. In each RGB termination is described as following
table
Value
Max Luminance Voltage Input Data = (FFh) 0.700 Volts +0.070 /-0.035 volts
Min Luminance voltage Input Data = (00h) 0.000 Volts
Video Channel Rise/Fall Time Max 25% of minimum pixel clock period
30% of minimum pixel clock period averaged over 100
Maximum Settling Time after overshoot/undershoot
waveforms to 5% final full-scale value.
Monotonic Yes
Resolution 1 LSB
Integral Linearity Error +/- 1 LSB
Differential Linearity Error +/- 1 LSB
Video Channel to Video Channel Mismatch 6% of any video output voltage over the full voltage range
Video Noise injection ratio +/- 2.5 % of Max Luminance Voltage
Video Channel to Video Channel Output Skew 50% of minimum pixel clock period
+/-12% of step function voltage level over the full voltage
Overshoot/Undershoot
range
The Synchronization (Hsync and Vsync) Signal format is described as following table
Min Max
Driver Logic Level "1" 2.4 Volts 5.5 Volts
Driver Logic Level "0" 0.0 Volts 0.5 Vots
Driver High Level Output Current 8mA
Driver Low Level Output Current 8mA
Receiver Logic Level "1" 2.0 Volts
Receiver Logic Level "0" 0.8 Volts
Fall Time Max 80% of minimum pixel clock period
Rise Time Max 80% of minimum pixel clock period
Monotonic Rise/Fall Voltage range 0.5-2.4 Volts
30% of high level signal voltage range
Overshoot/Undershoot No signal excursions allowed in the
0.5-2.4 volt voltage range
Over the frequency spectrum: One
half of the difference between the
maximum and minimum interval
Jitter (Measured between Hsync between Hsync pulses measured over
pulses). 100,000 intervals shall be less than
15% of the pixel clock, 0Hz to max.
horizontal refresh rate at all image
formats, worst-case screen patterns.
LSB Least Significant Bit
Monotonic
1. The property of either never increasing or never decreasing in reference to the slope of a Transient response. 2. A
constant slope value containing no inflection points.
Sync Synchronization Signals
For more detail, please refer to VESA (Video Electronics Standards Association) Video Signal Standard.
Ver0.1 23/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
3.5 Signal Electrical Characteristics
VGA interface
Pin Name Type Min. Typ. Max. Unit
1 GND
High 2.5 VCC V
2 VS
Low GND 0.8
High 2.5 VCC V
3 HS
Low GND 0.8
4 GNDB
5 BIN 700 mV
6 GNDG
7 GIN 700 mV
8 GNDR
9 RIN 700 mV
10 GND
High 3.5 VCC V
11 SDA
Low GND 0.8 V
High 3.5 VCC V
12 SCL
Low GND 0.8 V
13 PC5V
14 VGA_CON
Please follow Mstar MST8116B SPEC.
OSD interface
Pin Name Type Min. Typ. Max. Unit
1 GND
High 4 VCC V
2 SOURCE
Low 0 0.45 V
High 4 VCC V
3 SELECT
Low 0 0.45 V
4 LED_G VCC
5 LED_A VCC
High 4 VCC V
6 UP
Low 0 0.45 V
High 4 VCC V
7 DOWN
Low 0 0.45 V
High 4 VCC V
8 MINUS
Low 0 0.45 V
High 4 VCC V
9 PLUS
Low 0 0.45 V
High 4 VCC V
10 MENU
Low 0 0.45 V
High 4 VCC V
11 Power
Low 0 0.45 V
12 NC
13 GND
3.6 Interface Timings
The signal interface of the TFT module is analog RGB compatible
3.6.1 Timing Characteristics
The timings are supported by the signal interface of M170EP01 are listed as following table.
Ver0.1 24/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
Horizontal Vertical
Dot Clock
Resolution Frequency Frequency Actually Display Resolution Remark
(MHz)
(KHz) (Hz)
640x350 31.47(P) 70.08(N) 25.17 1280x943 DOS
720x400 31.47(N) 70.08(P) 28.32 1280x1024 DOS
640x480 31.47(N) 60.00(N) 25.18 1280x1024 DOS
640x480 35.00(N) 67.00(N) 30.24 1280x1024 Macintosh
640x480 37.86(N) 72.80(N) 31.5 1280x1024 VESA
640x480 37.50(N) 75.00(N) 31.5 1280x1024 VESA
800x600 37.88(P) 60.32(P) 40 1280x1024 VESA
800x600 48.08(P) 72.19(P) 50 1280x1024 VESA
800x600 46.86(P) 75.00(P) 49.5 1280x1024 VESA
832X624 49.72(N) 74.55(N) 57.29 1280x1024 Macintosh
1024x768 48.36(N) 60.00(N) 65 1280x1024 VESA
1024x768 56.48(N) 70.10(N) 75 1280x1024 VESA
1024x768 60.02(P) 75.00(P) 78.75 1280x1024 VESA
1024X768 60.24(N) 74.93(N) 80 1280x1024 Macintosh
1152x864 67.50(P) 75.00(P) 108 1280x1024 VESA
1152x870 68.68(N) 75.06(N) 100 1280x1024 Macintosh
1152x900 61.80(N) 66.00(N) 94.5 1280x1024 SUN 66
1152x900 71.81(N) 76.14(N) 108 1280x1024 SUN
1280x1024 64.00(P) 60.00(P) 108 1280x1024 VESA
1280x1024 75.83(N) 71.53(N) 128 1280x1024 IBM1
1280x1024 80.00(P) 75.00(P) 135 1280x1024 VESA
1280x1024 81.18(N) 76.16(N) 135.09 1280x1024 SPARC2
P", "N" stands for "Positive", "Negative" polarity of incoming H-sync/V-sync (input timing)
For each timming detail, please refer to individual video siganl standard.
3.6.2 Definition of terms
Video Signal Definition
a) Vmin steady state Amplitude before transition
b) Video Rise Time Delta (t), (measured from the 10% to 90% points of Vmin Steady State to Vmax Steady State)
c) Overshoot Amplitude
d) Undefined
e) Settling Time - Measured from the end of the overshoot to the point where the amplitude of the video ringing is
down to +/- 5% of the final steady state value
Ver0.1 25/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
f) Undefined
g) Video Fall Time Delta (t), (measured from the 90% to 10% points of Vmax Steady State to Vmin Steady State)
h) Undefined here, Note: Undershoot is within this period and with an Amplitude of (j)
i) Settling Time - Measured from the end of the undershoot to the point where the amplitude of the video ringing is
down to +/- 5% of the final steady state value
j) Vmin steady state Amplitude after transition
Synchronization Signal Definition
Ver0.1 26/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
3.7 Power Consumption
Input power specifications are as follows;
Symbol Parameter Min Typ Max Units Condition
VDD Logic/LCD Drive 4.9 5.1 5.3 [Volt]
Voltage
IDD* VDD current - 1100 1500 [mA] Vin=5.1V ,All Black Pattern.
PDD* VDD Power 5.6 7.6 [Watt] Vin=5.1V ,All Black Pattern.
VDDrp Allowable 100 [mV]
Logic/LCD Drive p-p
Ripple Voltage
Power Saving
- 0.4 0.5 [Watt] Vin=5.1V
*2 line dot inversion
3.8 Power ON/OFF Sequence
Vin and lamp power on/off sequence are as follows. The timing parameters of interface signal are shown in
the table below. The signal please reference "3.4 Signal Description".
90% 90%
Panel
Power
10% 10% 10%
0V
T1 T2 T5 T6 T7
Panel
Signal
0V
T3 T4
Lamp
0V
Values
Symbol Unit
Min. Typ. Max.
T1 - 0.1 - ms
T2 5 10 - ms
T3 200 - - ms
T4 100 - - ms
T5 0 16 50 ms
T6 - 200 - ms
T7 1000 - - ms
Ver0.1 27/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
Ver0.1 28/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
M170EP01 V.2
Product Specification
4.0 Backlight Characteristics
4.1 Signal for Lamp connector
Pin No. Input Color Function
1 Hot1 Pink High Voltage
2 Cold1 White Low Voltage
Upper 3 Hot2 Blue High Voltage
4 Cold2 Black Low Voltage
1 Hot1 Pink High Voltage
2 Cold1 White Low Voltage
Lower 3 Hot2 Blue High Voltage
4 Cold2 Black Low Voltage
4.2 Parameter guideline for CCFL Inverter
Symbol Parameter Min. Typ. Max. Unit Condition
[mA]
ISCFL CCFL standard current 7.0 7.5 8.5 o
(Ta=25 C) Note 1
rms
[mA]
IRCFL CCFL operation range 3.0 7.5 8.5 (Ta=25oC)
rms
FCFL CCFL Frequency 40 60 80 [KHz] (Ta=25oC) Note 2
ViCFL [Volt]
CCFL Ignition Voltage 1500 - - (Ta=0oC)
o
(0 C) rms
ViCF [Volt]
CCFL Ignition Voltage 1150 - - (Ta=25oC)
o
(25 C) rms
CCFL Operation Voltage 660 700 [Volt]
VCFL - (Ta=25oC) Note 3
@7.5mA @3.0mA rms
CCFL Power consumption
PCFL - 19.8 21.8 [Watt] (Ta=25oC) Note 4
(for reference)
o
LTCFL CCFL life Time 40,000 45,000 - [Hour] (Ta=25 C) Note 5
Note 1: CCFL standard current is measured at 25 2 . The variance of the current is 10%.When lamp current
achieve to Max. 8.5mA, brightness will decay more than 7.5mA. But it still could be opened.
Note 2: CCFL Frequency should be carefully determined to avoid interference between inverter and TFT LCD
Note 3: CCFL operation voltage is measured at 25 2 .
Note 4: The variance of CCFL power consumption is 10%. Calculator value for reference
(ICFL◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
