Image preview - the first page of the document
![Panel_AUO_M215HW01_V0_1_[DS]](/pics/5c36af0bb7870.gif)
>> Download Panel_AUO_M215HW01_V0_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification M215HW01 V0
AU OPTRONICS CORPORATION
( ) Preliminary Specification
( V ) Final Specification
Module 21.5" Color TFT-LCD
Model Name M215HW01 V0
Customer Date Approved by Date
6HDQ &KHQ 2008/05/09
Approved by Prepared by
%RULV &KX 2008/05/09
Note: This Specification is subject to Desktop Display Business Group /
change without notice. AU Optronics corporation
document version1.2 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M215HW01 V0
AU OPTRONICS CORPORATION
Contents
1.0 Handling Precautions ............................................................................................................ 6
2.0 General Description............................................................................................................... 7
2.1 Display Characteristics....................................................................................................... 7
2.2 Optical Characteristics ....................................................................................................... 8
3.0 Functional Block Diagram................................................................................................... 12
4.0 Absolute Maximum Ratings ................................................................................................ 13
4.1 TFT LCD Module.............................................................................................................. 13
4.2 Backlight Unit ................................................................................................................... 13
4.3 Absolute Ratings of Environment ..................................................................................... 13
5.0 Electrical characteristics..................................................................................................... 14
5.1 TFT LCD Module.............................................................................................................. 14
5.1.1 Power Specification....................................................................................................... 14
5.1.2 Signal Electrical Characteristics.................................................................................... 15
6.0 Signal Characteristic ........................................................................................................... 18
6.1 Pixel Format Image.......................................................................................................... 18
6.2 The input data format....................................................................................................... 18
6.3 Signal Description ............................................................................................................ 19
6.4 Timing Characteristics...................................................................................................... 20
6.5 Timing diagram ................................................................................................................ 21
6.6 Power ON/OFF Sequence ............................................................................................... 22
7.0 Connector & Pin Assignment ............................................................................................. 23
7.1 TFT LCD Module.............................................................................................................. 23
7.1.1 Pin Assignment 23
7.2 Backlight Unit ................................................................................................................... 24
7.2.1 Signal for Lamp connector 24
8.0 Reliability Test...................................................................................................................... 25
9.0 Shipping Label ..................................................................................................................... 26
10.0 Mechanical Characteristics............................................................................................... 27
document version1.2 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M215HW01 V0
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2008/01/18 All First Edition for Customer -
0.2 2008/05/09 6 Contrast Ratio => 1000 (Typ.) (TBD) Contrast Ratio => 1000 (Typ.) Revised
0.2 2008/05/09 6 Nominal Input Voltage VDD => +5.0 V Nominal Input Voltage VDD => +5.0 V Revised
(TBD)
6 Power Consumption => TBD W (Typ.) Power Consumption => 28.72 W (Typ.)
0.2 2008/05/09 Revised
(VDD line + CCFL line) (VDD line + CCFL line)
0.2 2008/05/09 6 Weight => TBD (Typ.) Weight => 2188 (Typ.) Revised
0.2 2008/05/09 7 Contrast ratio Contrast ratio Revised
Min Typ Max Note Min Typ Max Note
600 1000 3 (TBD) 600 1000 3
7 Response Time Response Time
0.2 2008/05/09 Revised
Raising Time (TrR) Raising Time (TrR)
Min Typ Max Min Typ Max
- 3.4 7.4 - 3.8 5.5
Falling Time (TrF) Falling Time (TrF)
Min Typ Max Min Typ Max
- 1.6 2.6 - 1.2 2.5
Raising + Falling Raising + Falling
Min Typ Max Min Typ Max
- 5 10 - 5 8
0.2 2008/05/09 7 Color / Chromaticity Color / Chromaticity Revised
Coordinates (CIE) Coordinates (CIE)
Green x Green x
Min Typ Max Note Min Typ Max Note
0.262 0.292 0.322 5 (TBD) 0.252 0.282 0.312 5
11 Mating Type: Mating Type:
0.2 2008/05/09 FI-X30HL (Locked Type) Revised
FI-X30HL (Locked Type)
FI-X30H (Unlocked Type)
4.2 Backlight Unit 4.2 Backlight Unit
0.2 2008/05/09 12 Revised
Item Symbol Min Max Item Symbol Min Max
CCFL ICFL 3.0 7.5 CCFL ICFL 3.0 8.0
0.2 2008/05/09 13 IDD Input Current IDD Input Current Revised
Min Typ Max Min Typ Max
- TBD TBD - 0.9 1.17
0.2 2008/05/09 13 PDD VDD Power PDD VDD Power Revised
Min Typ Max Min Typ Max
- TBD TBD - 4.5 5.4
0.2 2008/05/09 13 IRush Inrush Current IRush Inrush Current Revised
Min Typ Max Min Typ Max
- - TBD - - 2
0.2 2008/05/09 15 5.2 Backlight Unit 5.2 Backlight Unit Revised
CCFL Frequency (FCFL) CCFL Frequency (FCFL)
Min Typ Max Min Typ Max
TBD - - 40 55 60
document version1.2 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M215HW01 V0
AU OPTRONICS CORPORATION
0.2 2008/05/09 15 Note 1: Note 1: Revised
*2 In case of using an inverter other than *2 It is recommended to check the
listed, it is recommended to check the inverter carefully. Sometimes, interfering
inverter carefully. Sometimes, interfering noise stripes appear on the screen, and
noise stripes appear on the screen, and substandard luminance or flicker at low
substandard luminance or flicker at low power may happen.
power may happen. *6 For designing CCFL current, it is highly
recommanded to use symmetric and
consistent sinusoidal wave for each CCFL
input current with asymmetric ration of 10%
or less in both postive area and negative
area (ie. 0.9* 2*Irms < I1 & I2 < 1.1* 2*Irms)
as refer to the following diagram, otherwise
proper CCFL functionality cannot be
guarantied.
0.2 2008/05/09 19 6.4 Timing Characteristics 6.4 Timing Characteristics Revised
Item Min Typ Max Item Min Typ Max
Data CLK 55 72 90 Data CLK 40 75 90
H-section H-section
Period 1010 1050 2047 Period 1034 1060 2047
Blanking 50 90 681 Blanking 74 100 1087
V-section V-section
Period 1108 1130 2047 Period 1088 1120 2047
Blanking 28 50 255 Blanking 8 40 967
0.2 2008/05/09 22 7.1 TFT LCD Module 7.1 TFT LCD Module Revised
Mating Housing Part Number Mating Housing Part Number
FI-X30HL (Locked Type) FI-X30HL (Locked Type)
FI-X30H (Unlocked Type)
0.2 2008/05/09 23 7.2.1 Signal for Lamp connector 7.2.1 Signal for Lamp connector Revised
Lower Connector No. CN3 Lower Connector No. CN3
Pin No. 1 => Pink Pin No. 1 => Blue
Pin No. 2 => White Pin No. 2 => Black
Lower Connector No. CN4 Lower Connector No. CN4
Pin No. 1 => Pink Pin No. 1 => Blue
Pin No. 2 => White Pin No. 2 => Black
0.2 2008/05/09 25 9.0 Shipping Label 9.0 Shipping Label Revised
Note 3: The Green Mark will be Note 3: For China RoHS compatible
presented only when the green
documents have been ready by AUO products, AUO will add for
Internal Green Team. identification.
Note 4: The Green Mark will be presented
only when the green documents have been
ready by AUO Internal Green Team.
0.2 2008/05/09 26 10.0 Mechanical Characteristics 10.0 Mechanical Characteristics Revised
Version 0.1 Version 0.2
1.0 2008/06/12 Preliminary Specification Final specification
Version 0.2 Version 1.0
1.1 2008/08/01 6 This specification applies to the 21.5 This specification applies to the 21.5 Revised
inch-wide Color a-Si TFT-LCD Module inch-wide Color a-Si TFT-LCD Module
M215HW01.The display supports the M215HW01.The display supports the Full
WUXGA - 1920(H) x 1080(V) screen HD - 1920(H) x 1080(V) screen format and
format and 16.7M colors (RGB 6-bits + 16.7M colors (RGB 6-bits + Hi-FRC data).
Hi-FRC data).
document version1.2 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M215HW01 V0
AU OPTRONICS CORPORATION
1.2 2008/8/22 7 NA TC0'03 Compliance Revised
document version1.2 5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M215HW01 V0
AU OPTRONICS CORPORATION
1.0 Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard
surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken
out from the container, do not press the center of the CCFL reflector edge. Instead, press at
the far ends of the CCFL Reflector edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module
even momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT
Module may be damaged.
12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow
local ordinances or regulations for disposal.
13) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
14) The LCD module is designed so that the CCFL in it is supplied by Limited Current Circuit
(IEC60950 or UL1950). Do not connect the CCFL in Hazardous Voltage Circuit.
document version1.2 6
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M215HW01 V0
AU OPTRONICS CORPORATION
2.0 General Description
This specification applies to the 21.5 inch-wide Color a-Si TFT-LCD Module M215HW01.The
display supports the Full HD - 1920(H) x 1080(V) screen format and 16.7M colors (RGB 6-bits +
Hi-FRC data). All input signals are 2-channel LVDS interface and this module doesn't contain an
inverter board for backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 546.86(21.53")
Active Area [mm] 476.64 (H) x 268.11 (V)
Pixels H x V 1920(x3) x 1080
Pixel Pitch [um] 248.25 (per one triad) ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
