Image preview - the first page of the document
![Panel_AUO_P546HW03_V0_0_[DS]](/pics/5c36b1345522d.gif)
>> Download Panel_AUO_P546HW03_V0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Specification
P546HW03 0
Preliminary ersion: January 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
P546HW03 V0 Product Specification
Rev. 0.0
Model Name: P546HW03 V0
Issue Date : 2011/01/24
( )Preliminary Specifications
(...)Final Specifications
Customer Signature Date AUO Date
Approved By Approval By PM Director
Michael Goan
_________________________________ ____________________________________
Note Reviewed By RD Director
Eugene CC Chen
____________________________________
Reviewed By Project Leader
Alex Chen
____________________________________
Prepared By PM
Yalan Chen
____________________________________
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
P546HW03 V0 Product Specification
Rev. 0.0
Contents
No
CONTENTS
RECORD OF REVISIONS
1 GENERAL DESCRIPTION
2 ABSOLUTE MAXIMUM RATINGS
3 ELECTRICAL SPECIFICATION
3-1 ELECTRIACL CHARACTERISTICS
3-2 INTERFACE CONNECTIONS
3-3 SIGNAL TIMING SPECIFICATION
3-4 SIGNAL TIMING WAVEFORM
3-5 COLOR INPUT DATA REFERENCE
3-6 POWER SEQUENCE
3-7 BACKLIGHT SPECIFICATION
4 OPTICAL SPECIFICATION
5 MECHANICAL CHARACTERISTICS
5-1 PLACEMENT SUGGESTIONS
6 RELIABILITY TEST ITEMS
7 INTERNATIONAL STANDARD
7-1 SAFETY
7-2 EMC
8 PACKING
8-1 DEFINITION OF LABEL
8-2 PACKING METHODS
8-3 PALLET AND SHIPMENT INFORMATION
9 PRECAUTION
9-1 MOUNTING PRECAUTIONS
9-2 OPERATING PRECAUTIONS
9-3 ELECTROSTATIC DISCHARGE CONTROL
9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE
9-5 STORAGE
9-6 HANDLING PRECAUTIONS FOR PROTECT FILM
9-7 OPERATING CONDITION IN PID APPLICATION
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
P546HW03 V0 Product Specification
Rev. 0.0
Record of Revision
Version Date Page Description
0.0 2011/01/24 First preliminary spec release
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
P546HW03 V0 Product Specification
Rev. 0.0
1. General Description
This specification applies to the 54.6 inch Color TFT-LCD Module P546HW03 V0. This LCD module has a TFT
active matrix type liquid crystal panel 1,920x1,080 pixels, and diagonal size of 54.6 inch. This module supports
1,920x1080 mode. Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical
stripes. Gray scale or the brightness of the sub-pixel color is determined with a 10-bit gray scale signal for each
dot.
The P546HW03 V0 has been designed to apply the 10-bit 2 channel LVDS interface method. It is intended to
support displays where high brightness, wide viewing angle, high color saturation, and high color depth are very
important.
* General Information
Items Specification Unit Note
Active Screen Size 54.6 Inch
Display Area 1209.6(H) x 680.4(V) Mm
Outline Dimension 1255.6(H) x 726.4(V) x 26.3(D) Mm 1
Driver Element a-Si TFT active matrix
Display Colors 10 bit(8+FRC), 1073.7M Colors
Number of Pixels 1,920x1080 Pixel
Pixel Pitch 0.21 (H) x 0.63(W) Mm
Pixel Arrangement RGB vertical stripe
Display Operation Mode Normally Black
Display Orientation Landscape/Portrait Enable
Surface Treatment AG Haze = 11%
Note:
(1) Dmax: 26.3mm (Front bezel to Driver cover); Dmin: 10.8mm (Front bezel to Bezel back)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
P546HW03 V0 Product Specification
Rev. 0.0
2. Absolute Maximum Ratings
The followings are maximum values which, if exceeded, may cause faulty operation or damage to the unit
Item Symbol Min Max Unit Conditions
Logic/LCD Drive Voltage Vcc -0.3 14 [Volt] Note 1
Input Voltage of Signal Vin -0.3 4 [Volt] Note 1
o
Operating Temperature TOP 0 +50 [ C] Note 2
Operating Humidity HOP 10 90 [%RH] Note 2
o
Storage Temperature TST -20 +60 [ C] Note 2
Storage Humidity HST 10 90 [%RH] Note 2
o
Panel Surface Temperature PST 65 [ C] Note 3
Note 1: Duration:50 msec.
Note 2 : Maximum Wet-Bulb should be 39 and No condensation.
The relative humidity must not exceed 90% non-condensing at temperatures of 40 or less. At temperatures
greater than 40 , the wet bulb temperature must not exceed 39 .
Note 3: Surface temperature is measured at 50 Dry condition
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
P546HW03 V0 Product Specification
Rev. 0.0
3. Electrical Specification
The P546HW03 V0 requires two power inputs. One is employed to power the LCD electronics and to drive the TFT
array and liquid crystal. The second is employed for LED driver.
3.1.1 Electrical Characteristics
Value
Parameter Symbol Unit Note
Min. Typ. Max
LCD
Power Supply Input Voltage VDD 10.8 12 13.2 VDC 1
Power Supply Input Current IDD -- TBD TBD A 2
Power Consumption PC -- TBD TBD Watt 2
Inrush Current IRUSH - - TBD A 3
Differential Input High Threshold
VTH -- -- +100 mVDC 4
Voltage
LVDS
Differential Input Low Threshold
Interface VTL -100 -- -- mVDC 4
Voltage
Input Common Mode Voltage VICM 1.1 1.25 1.4 VDC 4
VIH
Input High Threshold Voltage 2.7 -- 3.3 VDC
CMOS (High) CMOS
Interface VIL Interface
Input Low Threshold Voltage 0 -- 0.6 VDC
(Low)
Backlight Power Consumption PBL -- 117.5 135.8 W
Life Time(MTTF) -- 50000 -- 7
3.1.2 AC Characteristics
Value
Parameter Symbol Unit Note
Min. Typ. Max
Receiver Clock : Spread
Fclk Fclk
Spectrum Fclk_ss -- MHz 8
-3% +3%
Modulation range
LVDS Receiver Clock : Spread
Spectrum Fss 30 -- 200 KHz 8
Interface
Modulation frequency
Receiver Data Input Margin
Fclk = 85 MHz tRMG -0.4 -- 0.4 ns 9
Fclk = 65 MHz -0.5 -- 0.5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
P546HW03 V0 Product Specification
Rev. 0.0
Note :
1. The ripple voltage should be controlled under 10% of VCC
2. Test Condition:
(1) VDD = 12.0V
(2) Fv = Type Timing, 60Hz, 120Hz or Other
(3) FCLK = Max freq.
(4) Temperature = 25
(5) Test Pattern : White Pattern
3. Measurement condition : Rising time = 400us
9''
*1'
s
4. VICM = 1.25V
LVDS -
V IC M V TH
|V ID |
V TL
LVDS +
GND
|V ID |
0V
|V ID |
5. Do not attach a conducting tape to lamp connecting wire. If the lamp wire attach to conducting tape,
TFT-LCD Module have a low luminance and the inverter has abnormal action because leakage current
occurs between lamp wire and conducting tape.
6. The relative humidity must not exceed 80% non-condensing at temperatures of 40 or less. At
temperatures greater than 40 , the wet bulb temperature must not exceed 39 . When operate at low
temperatures, the brightness of LED will drop and the life time of LED will be reduced.
7. The lifetime (MTTF) is defined as the time which luminance of the LED is 50% compared to its original
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
P546HW03 V0 Product Specification
Rev. 0.0
value.
