Image preview - the first page of the document
![Panel_AUO_T420XW01_V0_0_[DS]](/pics/5c8eb5f2b1124.gif)
>> Download Panel_AUO_T420XW01_V0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Specification
T420XW01
Version June 2006
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents
No ITEM
COVER
CONTENTS
RECORD OF REVISIONS
1 GENERAL DESCRIPTION
2 ABSOLUTE MAXIMUM RATINGS
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS
3-2 INTERFACE CONNECTIONS
3-3 SIGNAL TIMING SPECIFICATIONS
3-4 SIGNAL TIMING WAVEFORMS
3-5 COLOR INPUT DATA REFERNECE
3-6 POWER SEQUENCE
4 OPTICAL SFECIFICATIONS
5 MECHANICAL CHARACTERISTICS
6 INTERNATIONAL STANDARDS
6-1 SAFETY
6-2 EMC
7 PACKING
8 PRECAUTIONS
2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Record of Revision
Version Date No Old Description New Description Remark
1.0 2005/12/23 First release
3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
1. General Description
This specification applies to the 42 inch Color TFT-LCD Module T420XW01 V0. This LCD module has
a TFT active matrix type liquid crystal panel 1366x768 pixels, and diagonal size of 42 inch. This
module supports 1366x768 WXGA mode (Non-interlace).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes.
Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale signal for each
dot.
The T420XW01 V0 has been designed to apply the 8-bit 1 channel LVDS interface method. It is
intended to support displays where high brightness, wide viewing angle, high color saturation, and
high color depth are very important.
* General Information
Items Specification Unit Note
Active Screen Size 42.02 inches
Display Area 930.25(H) x 523.01(V) mm
Outline Dimension 983.0(H) x 576.0(V) x 54.2(D) mm With inverter
Driver Element a-Si TFT active matrix
Display Colors 16.7M Colors
Number of Pixels 1366 x 768 Pixel
Pixel Arrangement RGB vertical stripe
Display Mode Normally Black
Surface Treatment AG, 3H
4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the
unit.
Item Symbol Min Max Unit Note
Logic/LCD Drive Voltage Vdd -0.3 14.0 [Volt] 1
Input Voltage of Signal Vin -0.3 3.6 [Volt] 1
BLU Input Voltage Vdd B -0.3 27.0 [Volt] 1
BLU Brightness Control Voltage BLON -0.3 6.0 [Volt] 1
o
Operating Temperature T OP 0 +50 [ C] 2
Operating Humidity HOP 10 90 [%RH] 2
o
Storage Temperature TST -20 +60 [ C] 2
Storage Humidity HST 10 90 [%RH] 2
Shock (non-operation) - 50 G 3
Vibration (non-operation) - 1.5 G 4
Thermal shock -20 60 C 5
Altitude test 50000feet (12Kpa)
Note 1 : Duration = 50msec
Note 2 : Maximum Wet-Bulb should be 39 and No condensation.
Note 3 : Half sine wave, shock level : 50G(11ms), direction : ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
