Image preview - the first page of the document



>> Download Panel_AUO_T550QVN01-1_0_[DS] documenatation <<

Text preview - extract from the document

55" 4K2K one page spec
55"4K2K Preliminary Spec:
                                                                   T550QVN01.1
          Resolution                                               3840 x 2160
        Aspect Ratio                                                   16:9
          Pixel Pitch                                              0.315 x 0.315
          Brightness                                                    400
      Contrast Ratio                                                  5000:1
       Display Color                                                   10bit
         Frame Rate                                                   120Hz
                  I/F                                      V by One (41 + 51pin)
        Color Gamut                                                     72
  Module Chromaticity
                                                                   (0.280, 0.290)
        (X,Y)
       B/L Power (w)                                                   150W
         View Angle                                                 89/89/89/89
                BLU                                                 Edge-LED
             Outline                                         1242.6(H)*715.4(V)
           Thickness                                                   16.2
         Bezel width
                                                                    14/12/12/12
          U/L/R/D
              Weight                                                 18,500 g
