Image preview - the first page of the document
![Panel_BOE_HM215WU3-100_0_[DS]](/pics/5c8eb9a724722.gif)
>> Download Panel_BOE_HM215WU3-100_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PROPRIETARY NOTE
THIS SPECIFICATION IS THE PROPERTY OF BOE HF AND SHALL NOT BE
REPRODUCED OR COPIED WITHOUT THE WRITTEN PERMISSION OF BOE HF AND
MUST BE RETURNED TO BOE HF UPON ITS REQUEST
TITLE : B3 HM215WU3-100 Open Cell
Preliminary Product Specification
Rev. P0
HEFEI BOE OPTOELECTRONICS TECHNOLOGY
SPEC. NUMBER PRODUCT GROUP ISSUE DATE PAGE
Rev. P0
TFT-LCD 2011.03.23 OF 28
A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT P0 Mar. 23. 11'
REVISION HISTORY
REV. ECN No. DESCRIPTION OF CHANGES DATE PREPARED
P0 Initial Release 2011.03.23
SPEC. TITLE
PAGE
SPEC. NUMBER B3 HE185WX1-100 Open Cell Preliminary Product
Specification_ Rev.P0 OF 28
A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT P0 Mar. 23. 11'
Contents
No. Item Page
1.0 General Description 4
2.0 Absolute Maximum Ratings 6
3.0 Electrical Specifications 7
4.0 Optical Specifications 8
5.0 Interface Connection 10
6.0 Signal Timing Specifications 14
7.0 Signal Timing Waveforms of Interface Signal 16
8.0 Input Signals, Display Colors & Gray Scale of Colors 18
9.0 Power Sequence 19
10.0 Mechanical Characteristics 20
11.0 Reliability Test 21
12.0 Handling& Cautions 22
13.0 Product Serial Number 23
14.0 Packing 24
15.0 Appendix 26
SPEC. TITLE
PAGE
SPEC. NUMBER B3 HM215WU3-100 Open Cell Preliminary Product
Specification _Rev.P0 OF 28
A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT P0 Mar. 23. 11'
1.0 GENERAL DESCRIPTION
1.1 Introduction
HM215WU3-100 is a color active matrix TFT LCD open cell using amorphous silicon
TFT's (Thin Film Transistors) as an active switching devices. This module has a 21.5 inch
diagonally measured active area with WXGA resolutions (1920 horizontal by 1080 vertical
pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in
vertical stripe and this module can display 16.7M colors. The TFT-LCD panel used for this
module is adapted for a low reflection and higher color type.
LVDS LVDS Rx Source Driver
Input +
Signal T/CON
+
Connector (CN
Gate Driver
Mini LVDS Tx
TFT LCD Panel
1920 1080
VDD DC/DC
1 Gamma
)
Vcom
1.2 Features
z LVDS Interface with 2 pixel / clock
z High-speed response
z 6-bit (Hi-FRC) color depth, display 16. 7M colors
z Incorporated edge type back-light (One Light Bar)
z High luminance and contrast ratio, low reflection and wide viewing angle
z DE (Data Enable) only
z RoHS /TCO 5.0 Compliant
SPEC. TITLE
PAGE
SPEC. NUMBER B3 HM215WU3-100 Open Cell Preliminary Product
Specification _Rev.P0 OF 28
A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT P0 Mar. 23. 11'
1.3 Application
z Desktop Type of PC & Workstation Use
z Slim-Size Display for Stand-alone Monitor
z Display Terminals for Control System
z Monitors for Process Controller
1.4 General Specification
The followings are general specifications at the open cell HE185WX1-100.
