Image preview - the first page of the document
![Panel_BOE_HT260WXC-200_1_[DS]](/pics/5c8eba410d409.gif)
>> Download Panel_BOE_HT260WXC-200_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PROPRIETARY NOTE
THIS SPECIFICATION IS THE PROPERTY OF BOE HF AND SHALL NOT BE
REPRODUCED OR COPIED WITHOUT THE WRITTEN PERMISSION OF BOE HF AND
MUST BE RETURNED TO BOE HF UPON ITS REQUEST
SPEC. NUMBER PRODUCT GROUP PAGE
TFT-LCD Rev.O ISSUE DATE
OF 27
TITLE : HT260WXC-200
Product Specification
Rev. O
HEFEI BOE OPTOELECTRONICS TECHNOLOGY
R2010-6053-O(1/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT O 2011.9.28
SPEC. NUMBER SPEC. TITLE PAGE
HT260WXC-200 Product Specification OF 27
REVISION HISTORY
REV. ECN No. DESCRIPTION OF CHANGES DATE PREPARED
O Initial Release 2011.9.28
R2010-6053-O(2/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT O 2011.9.28
SPEC. NUMBER SPEC. TITLE PAGE
HT260WXC-200 Product Specification OF 27
Contents
No. Item Page
REVISION HISTORY 2
CONTENTS 3
1.0 GENERAL DESCRIPTION 4
1.1 Introduction
1.2 Features
1.3 Applications
1.4 General Specification
2.0 ABSOLUTE MAXIMUM RATINGS 6
3.0 ELECTRICAL SPECIFICATIONS 7
3.1 TFT LCD Module
3.2 LED Driver
4.0 INTERFACE CONNECTION 9
4.1 Module Input Signal & power
4.2 LVDS Interface
4.3 LED Driver Input Signal & Power
5.0 SIGNAL TIMING SPECIFICATIONS 12
5.1 Timing Parameters
5.2 Signal Timing Waveform
5.3 Input Signals, Basic Display Colors & Cray Scale Of Colors
5.4 Power Sequence
6.0 OPTICAL SPECIFICATIONS 16
7.0 MECHANICAL CHARACTERISTICS 18
8.0 RELIABLITY TEST 19
9.0 PRODUCT SERIAL NUMBER 20
10.0 PACKING INFORMATION 21
11.0 HANDING & CAUTIONS 23
12.0 APPENDIX 24
R2010-6053-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT O 2011.9.28
SPEC. NUMBER SPEC. TITLE PAGE
HT260WXC-200 Product Specification OF 27
1.0 GENERAL DESCRIPTION
1.1 Introduction
HT260WXC-200 is a color active matrix TFT LCD module using amorphous silicon TFT's
(Thin Film Transistors) as an active switching devices. This module has a 26.0inch diagonally
measured active area with WXGA resolutions (1366 horizontal by 768 vertical pixel array).
Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and
this module can display 16.7M colors. The TFT-LCD panel used for this module is adapted for a
low reflection and higher color type.
RGB(Mini-LVDS)
Source Driver Circuit
S1 S1366
G1
+12.0V
Gate Driver Circuit
Timing Controller
LVDS CN1
5pair
[LVDS Rx & Mini-LVDS
(30pin) Tx integrated]
Option TFT - LCD Panel
#9 (1366 RGB 768 pixels)
Power Circuit G768
Block
+24.0V, GND Back light Assembly
LED Driver
(52ea LED)
1.2 Features
z LVDS Interface with 1 pixel / clock
z High-speed response
z Lower Color shift Image Quality
z 6-bit Hi-FRC color depth, display 16.7M colors
z High luminance and contrast ratio, low reflection and wide viewing angle
z DE (Data Enable) only mode
z RoHS Compliant
R2010-6053-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT O 2011.9.28
SPEC. NUMBER SPEC. TITLE PAGE
HT260WXC-200 Product Specification OF 27
1.3 Application
z Home Alone Multimedia TFT-LCD TV
z Display Terminals for Control System
z High Definition TV(HD TV)
z AV application Products
1.4 General Specification
< Table 1. General Specifications >
Parameter Specification Unit Remarks
Active area 575.769(W) x 323.712(H) mm
Number of pixels 1366(H) 768(V) pixels
Pixel pitch 140.5(H) RGB 421.5(V)
Pixel arrangement Pixels RGB stripe arrangement
Display colors 16.7M(6bits + Hi FRC) colors
Display mode Transmission mode, Normally White
Outline Dimension 609.8(H) 357.8(V) 9.6 (body) (typ.) mm
Weight 2650 (typ.) gram
Power Consumption Total 26Watt (typ) Watt
Surface Treatment Haze 25%, 3H, AG treatment (Front
Polarizer)
R2010-6053-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT O 2011.9.28
SPEC. NUMBER SPEC. TITLE PAGE
HT260WXC-200 Product Specification OF 27
2.0 ABSOLUTE MAXIMUM RATINGS
The followings are maximum values which, if exceed, may cause faulty operation or
damage to the unit. The operational and non-operational maximum voltage and current
values are listed in Table 2.
< Table 2. LCD Module Electrical Specifications > [VSS=GND=0V]
Parameter Symbol Min. Max. Unit Remarks
Power Supply LCD Module VDD VSS-0.3 13 V
Voltage Ta = 25
LED Driver VIN VSS-0.3 26.4 V
Operating Temperature TOP 0 +50
TSUR 0 +60
Storage Temperature TST -20 +60 1)
Operating Ambient Humidity Hop 10 80 %RH
Storage Humidity Hst 10 80 %RH
Note : 1) Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39 max. and no condensation of water.
C
R2010-6053-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT O 2011.9.28
SPEC. NUMBER SPEC. TITLE PAGE
HT260WXC-200 Product Specification OF 27
3.0 ELECTRICAL SPECIFICATIONS
3.1 TFT LCD Module
< Table 3. LCD Module Electrical Specifications > [Ta =25 2 ]
Values
Parameter Symbol Unit Notes
Min Typ Max
Power Supply Input Voltage VDD 11.4 12 12.6 Vdc
Power Supply Ripple Voltage VRP 300 mV
Power Supply Current IDD - 160 280 mA
1
Power Consumption PDD 1.92 3.8 Watt
Rush current IRUSH - - 3 A 2
Differential Input High
VLVTH +100 +300 mV
Threshold Voltage
LVDS
Differential Input Low
Interface VLVTL -300 -100 mV
Threshold Voltage
Common Input Voltage VLVC 1.0 1.2 1.4 V
Input High Threshold
VIH 2.7 - 3.3 V
CMOS Voltage
Interface Input Low Threshold
VIL 0 - 0.6 V
Voltage
Notes : 1. The supply voltage is measured and specified at the interface connector of LCM.
The current draw and power consumption specified is for VDD=12.0V, Frame rate fV=60Hz and
Clock frequency = 75.4MHz. Test Pattern of power supply current
a) Typ : Mosaic 8 x 6 Pattern(L0/L255) b) Max : Skip 1H2V Sub Dot Pattern(L0/L255)
2. The duration of rush current is about 2ms and rising time of Power Input is 1ms(min)
R2010-6053-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT O 2011.9.28
SPEC. NUMBER SPEC. TITLE PAGE
HT260WXC-200 Product Specification OF 27
3.2 LED Driver
< Table 4. LED Driver Electrical Specifications > [Ta =25 2 ]
Values
Parameter Symbol Condition Unit Notes
Min. Typ. Max.
Input Voltage VBL 22.8 24.0 25.2 V
Input Current IBL VDIM=3.3V - 1 1.2 A 1
Rush current IRUSH VBL= 24V - - 3 A
Power
PBL Typ Luminance - 24 27 Watt
Consumption
BL ON = High 2.8 3.3 5 V
B/L on/off control VON/OFF
BL OFF =Low 0 - 0.8 V
PWM Frequency FPWM 140 190 240 Hz
High Level 2.8 3.3 5 V
PWM Level
Low Level 0 - 0.4 V
PWM Duty DPWM 10 - 100 % 2
Life Time 30,000 - - Hrs 3
Notes: 1.The specified current and power consumption are under the typical supply Input voltage,
24V. It is total power consumption.
2. High-duty = On/(On+Off) * 100
3. The life time of LED, 30,000Hrs, is determined as the time at which luminance of the
LED is 50% compared to that of initial value at the typical LED current on condition of
continuous operating at 25 r 2 C.
R2010-6053-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT O 2011.9.28
SPEC. NUMBER SPEC. TITLE PAGE
HT260WXC-200 Product Specification OF 27
4.0 INTERFACE CONNECTION
4.1 Module Input Signal & Power
- Connector : IS100-L30B-C23(Manufactured by UJU) or Equivalent.
< Table 5. LCM Module Input Connector Pin Configuration >
Pin No Symbol Description Pin No Symbol Description
1 VDD Power Supply +12.0V 16 RX1+ LVDS Receiver Signal(+)
2 VDD Power Supply +12.0V 17 GND Ground
3 VDD Power Supply +12.0V 18 RX2- LVDS Receiver Signal(-)
4 VDD Power Supply +12.0V 19 RX2+ LVDS Receiver Signal(+)
5 GND Ground 20 GND Ground
6 GND Ground 21 RCLK- LVDS Receiver Clock Signal(-)
7 GND Ground 22 RCLK+ LVDS Receiver Clock Signal(+)
8 GND Ground 23 GND Ground
9 LVDS_SEL `L'=JEIDA , `H'or NC= VESA 24 RX3- LVDS Receiver Signal(-)
10 NC No Connection 25 RX3+ LVDS Receiver Signal(+)
11 GND Ground 26 GND Ground
12 RX0- LVDS Receiver Signal(-) 27 NC No Connection
13 RX0+ LVDS Receiver Signal(+) 28 NC No Connection
14 GND Ground 29 GND Ground
15 RX1- LVDS Receiver Signal(-) 30 GND Ground
Notes : 1. NC(Not Connected) : This pins are only used for BOE internal operations.
2. Input Level of LVDS signal is based on the IEA 664 Standard.
3. LVDS_SEL : This pin is used for selecting LVDS signal data format.
