Image preview - the first page of the document
![Panel_BOE_HV320WXC-100_2_[DS]](/pics/5c8eba5f7f43d.gif)
>> Download Panel_BOE_HV320WXC-100_2_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PROPRIETARY NOTE
THIS SPECIFICATION IS THE PROPERTY OF BOE HF AND SHALL NOT BE
REPRODUCED OR COPIED WITHOUT THE WRITTEN PERMISSION OF BOE OT AND
MUST BE RETURNED TO BOE HF UPON ITS REQUEST.
SPEC. NUMBER PRODUCT GROUP REV. ISSUE DATE PAGE
S86 600
S864-6002 TFT-LCD A 2011.1.20 OF 28
TITLE : HV320WXC 100
HV320WXC-100
Product Specification
Rev. A
B2010-6011-O(1/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT A 2011.1.20
SPEC. NUMBER SPEC. TITLE PAGE
S864 6002
S864-6002 HV320WXC-100 Product Specification
p 2 OF 28
REVISION HISTORY
REV. ECN NO. DESCRIPTION OF CHANGES DATE PREPARED
O Initial Release 10.11.30
A Add VDD ripple voltage spec @ Page 7 11.1.20
Add rush current spec of inverter @ Page 8
Add PWM voltage level @Page 8
Add power sequence of inverter @Page 16
B2010-6011-O(2/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT A 2011.1.20
SPEC. NUMBER SPEC. TITLE PAGE
S864-6002 HV320WXC-100 Product Specification 3 OF 28
Contents
No ITEM Page
REVISIONS HISTORY 2
CONTENTS 3
1 GENERAL DESCRIPTION 4
1.1 Introduction
1.2 Features
1.3 Applications
1.4 General Specification
2 ABSOLUTE MAXIMUM RATINGS 6
3 ELECTRICAL SPECIFICATIONS 7
3.1 TFT LCD Module
3.2 Inverter
4 INTERFACE CONNECTION 9
4.1 Module Input Signal & p
p g power
4.2 LVDS Interface
4.3 Inverter Input Signal & Power
5 SIGNAL TIMING SPECIFICATIONS 12
5.1 Timing Parameter
5.2 Signal Timing Waveform
5.3 Input Signals, Basic Display Colors & Cray Scale Of Colors
5.4 Power Sequence for LCD
5.5 Power Sequence for Inverter
6 OPTICAL SPECIFICATIONS 17
7 MECHANICAL CHARACTERISTICS 19
8 RELIABLITY 20
9 PRODUCT SERIAL NUMBER 21
10 PACKING INFORMATION 22
11 HANDING & CAUTIONS 24
12 APPENDIX 25
B2010-6011-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT A 2011.1.20
SPEC. NUMBER SPEC. TITLE PAGE
S864-6002 HV320WXC-100 Product Specification 4 OF 28
1.0 GENERAL DESCRIPTION
1.1 Introduction
HV320WXC-100 is a color active matrix TFT LCD module using amorphous silicon TFT's
(Thin Film Transistors) as an active switching devices. This module has a 31.51 inch diagonally
measured active area with WXGA resolutions (1366 horizontal by 768 vertical pixel array).
Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and
this module can display 16.7M colors. The TFT-LCD panel used for this module is adapted for a
low reflection and higher color type.
RGB(Mini-LVDS)
Source Driver Circuit
S1 S1366
G1
+12.0V
Gate Driver Cir
Timing Controller
LVDS CN1
5pair
[LVDS Rx & Mini-LVDS
(30pin) Tx integrated]
Option TFT - LCD Panel
#9 (1366 RGB 768 pixels)
rcuit
Power Circuit G768
Block
+24.0V
Inverter Back light Assembly
2pin x 4CNs (High)
+24.0V (CN2) (4 U_CCFL)
1.2 Features
z LVDS Interface with 1 pixel / clock
z High-speed response
z Lower Color shift Image Quality
z 8 bit color depth, display 16 7M colors
8-bit depth 16.7M
z High luminance and contrast ratio, low reflection and wide viewing angle
z DE (Data Enable) only mode
z AFFS technology is applied for high display quality
z RoHS Compliant
B2010-6011-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT A 2011.1.20
SPEC. NUMBER SPEC. TITLE PAGE
S864-6002 HV320WXC-100 Product Specification 5 OF 28
1.3 Application
z Home Alone Multimedia TFT-LCD TV
z Display Terminals for Control System
z High Definition TV(HD TV)
z AV application Products
1.4 General Specification
< Table 1. General Specifications >
Parameter Specification
p Unit Remarks
Active area 697.685(H) 392.256(V) mm
Number of pixels 1366(H) 768(V) pixels
Pixel pitch 170.25(H) 510.75(V) RGB
Pixel arrangement Pixels RGB stripe arrangement
Display colors 16.7M(8bits-true) colors
Display mode Transmission mode, Normally Black
Outline Dimension 760.0(H) 450.0(V) 48.0(D) typ. mm
Weight 5300 (typ.) gram
Power Consumption Total 80Watt (Typ.) (Logic= 3W, Lamp=7 Watt
7W [IBL=12mA] )
Surface Treatment Haze 10%, 3H, Semi-glare treatment
(Front Polarizer)
B2010-6011-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT A 2011.1.20
SPEC. NUMBER SPEC. TITLE PAGE
S864-6002 HV320WXC-100 Product Specification 6 OF 28
2.0 ABSOLUTE MAXIMUM RATINGS
The followings are maximum values which, if exceed, may cause faulty operation or
damage to the unit. The operational and non-operational maximum voltage and current
values are listed in Table 2.
< Table 2. LCD Module Electrical Specifications > [VSS=GND=0V]
Parameter Symbol Min. Max. Unit Remarks
Power Supply LCD Module VDD VSS-0.3 13.2 V
Voltage Ta = 25
Inverter VBL VSS-0.3 26.4 V
Operating Temperature TOP 0 +50
TSUR 0 +60
Storage Temperature TST -20 +60 1)
Operating Ambient Humidity Hop 10 80 %RH
Storage Humidity Hst 10 80 %RH
Note : 1) Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39 max. and no condensation of water.
C
B2010-6011-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT A 2011.1.20
SPEC. NUMBER SPEC. TITLE PAGE
S864-6002 HV320WXC-100 Product Specification 7 OF 28
3.0 ELECTRICAL SPECIFICATIONS
3.1 TFT LCD Module
< Table 3. LCD Module Electrical Specifications > [Ta =25 2 ]
Values
Parameter Symbol Unit Notes
Min Typ Max
Power Supply Input Voltage VDD 10.8 12 13.2 Vdc
Power Supply Ripple Voltage VRP 300 mV
Power Supply Current IDD 200 250 350 mA 1
Power Consumption PLCD 2 3 5 Watt
Rush current IRUSH - - 2.0 A 2
Differential Input High
VLVTH +100 mV
Threshold Voltage
LVDS
Differential Input Low
Interface VLVTL -100 mV
Threshold Voltage
Common Input Voltage VLVC 1.0 1.2 1.4 V
Input High Threshold
VIH 2.7 - 3.3 V
CMOS Voltage
Interface Input Low Threshold
VIL 0 - 0.7 V
Voltage
Notes : 1. The supply voltage is measured and specified at the interface connector of LCM.
The current draw and power consumption specified is for VDD=12.0V, Frame rate=60Hz and
Clock frequency = 73.9MHz. Test Pattern of power supply current
a) Typ : Black Pattern
b) Max : Sub Dot Pattern
2. The duration of rush current is about 2ms and rising time of Power Input is 1ms(min)
White : 255Gray
Black : 0Gray
Mosaic Pattern(8 x 6)
B2010-6011-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT A 2011.1.20
SPEC. NUMBER SPEC. TITLE PAGE
S864-6002 HV320WXC-100 Product Specification 8 OF 28
3.2 Inverter
< Table 4. Inverter Electrical Specifications >
Values Note
Parameter Symbol Condition Unit
Min. Typ. Max. s
I
Input V lt
t Voltage VBL 22.8
22 8 24.0
24 0 25.2
25 2 V
Input Current IBL Vadim=3.3V - 3.2 3.5 A 1
Rush current IRUSH VBL= 24V - - 6 A
Power
PBL Typ Luminance - 77 85 Watt
Consumption
Lamp ON = High 2 3.3
33 5 V
B/L on/off control VON/OFF
Lamp OFF =Low 0 - 0.8 V
Min. Luminance 0
Analog Dimming ADIM V
Max. Luminance 3.3
PWM Frequency FPWM 140 190 240 Hz
High Level 3.0 3.3 3.6 V
PWM Level
Low Level 0 - 0.3 V
PWM Duty DPWM 10 - 100 % 2
Life Time 50,000 - - Hrs 3
Notes: 1.The specified current and power consumption are under the typical supply Input voltage,
24V. It is total power consumption.
2. High-duty = On/(On+Off) * 100
3. The life time of a Lamp, 50,000Hrs, is determined as the time at which luminance of the
lamp is 50% compared to that of initial value at the typical lamp current on condition of
continuous operating at 25 r 2 C.
B2010-6011-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT A 2011.1.20
SPEC. NUMBER SPEC. TITLE PAGE
S864-6002 HV320WXC-100 Product Specification 9 OF 28
4.0 INTERFACE CONNECTION
4.1 Module Input Signal & Power
- Connector : IS100-L30B-C23(Manufactured by UJU) or Equivalent.
< T bl 5 LCM Module I
Table 5. M d l Input C
Connector Pi C fi
Pin Configuration >
i
Pin No Symbol Description Pin No Symbol Description
1 VDD Power Supply +12.0V 16 RX1+ LVDS Receiver Signal(+)
2 VDD Power Supply +12.0V 17 GND Ground
3 VDD Power Supply +12.0V 18 RX2- LVDS Receiver Signal(-)
4 VDD Power Supply +12.0V 19 RX2+ LVDS Receiver Signal(+)
5 GND Ground 20 GND Ground
6 GND Ground 21 RCLK- LVDS Receiver Clock Signal(-)
7 GND Ground 22 RCLK+ LVDS Receiver Clock Signal(+)
8 GND Ground 23 GND Ground
9 LVDS_SEL `H'=JEIDA , `L'or NC= VESA 24 RX3- LVDS Receiver Signal(-)
10 NC No Connection 25 RX3+ LVDS Receiver Signal(+)
11 GND Ground 26 GND Ground
12 RX0- LVDS Receiver Signal(-)
V S ece ve S g ( ) 7
27 NC
C No Co ec o
o Connection
13 RX0+ LVDS Receiver Signal(+) 28 NC No Connection
14 GND Ground 29 GND Ground
15 RX1- LVDS Receiver Signal(-) 30 GND Ground
Notes : 1. NC(Not Connected) : This pins are only used for BOE internal operations.
2. Input Level of LVDS signal is based on the IEA 664 Standard.
3. LVDS_SEL : This pin is used for selecting LVDS signal data format.
