Image preview - the first page of the document
![Panel_BOE_HV320WXC-200_0_[DS]](/pics/5c8eba6553137.gif)
>> Download Panel_BOE_HV320WXC-200_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PROPRIETARY NOTE
THIS SPECIFICATION IS THE PROPERTY OF BOE HF AND SHALL NOT BE
REPRODUCED OR COPIED WITHOUT THE WRITTEN PERMISSION OF BOE HF AND
MUST BE RETURNED TO BOE HF UPON ITS REQUEST.
SPEC. NUMBER PRODUCT GROUP REV. ISSUE DATE PAGE
TFT-LCD P0 2011.4.12 OF 27
TITLE : HV320WXC-200
Preliminary Product Specification
Rev. P0
B2010-6011-O(1/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT P0 2011.4.12
SPEC. NUMBER SPEC. TITLE PAGE
HV320WXC-200 Preliminary Product Specification Rev.P0 2 OF 27
REVISION HISTORY
REV. ECN NO. DESCRIPTION OF CHANGES DATE PREPARED
P0 Initial Release 2011.4.12
B2010-6011-O(2/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT P0 2011.4.12
SPEC. NUMBER SPEC. TITLE PAGE
HV320WXC-200 Preliminary Product Specification Rev.P0 3 OF 27
Contents
No ITEM Page
REVISIONS HISTORY 2
CONTENTS 3
1 GENERAL DESCRIPTION 4
1.1 Introduction
1.2 Features
1.3 Applications
1.4 General Specification
2 ABSOLUTE MAXIMUM RATINGS 6
3 ELECTRICAL SPECIFICATIONS 7
3.1 TFT LCD Module
3.2 LED Converter
4 INTERFACE CONNECTION 9
4.1 Module Input Signal & Power
4.2 LVDS Interface
4.3 LED Converter Input Signal & Power
5 SIGNAL TIMING SPECIFICATIONS 12
5.1 Timing Parameters
5.2 Signal Timing Waveform
5.3 Input Signals, Basic Display Colors & Cray Scale Of Colors
5.4 Power Sequence
6 OPTICAL SPECIFICATIONS 16
7 MECHANICAL CHARACTERISTICS 18
8 RELIABLITY 19
9 PRODUCT SERIAL NUMBER 20
10 PACKING INFORMATION 21
11 HANDING & CAUTIONS 23
12 APPENDIX 24
B2010-6011-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT P0 2011.4.12
SPEC. NUMBER SPEC. TITLE PAGE
HV320WXC-200 Preliminary Product Specification Rev.P0 4 OF 27
1.0 GENERAL DESCRIPTION
1.1 Introduction
HV320WXC-200 is a color active matrix TFT LCD module using amorphous silicon TFT's
(Thin Film Transistors) as an active switching devices. This module has a 31.51 inch diagonally
measured active area with WXGA resolutions (1366 horizontal by 768 vertical pixel array).
Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and
this module can display 16.7M colors. The TFT-LCD panel used for this module is adapted for a
low reflection and higher color type.
RGB(Mini-LVDS)
VDD Source Driver Circuit
+12.0V
S1 S1366
LVDS
G1
5pairs CN1
Gate Driver Circuit
Timing Controller
LVDS_SEL
(30pin)
#9 [LVDS Rx & Mini-LVDS
Tx integrated]
BIST_ TFT - LCD Panel
# 27 (1366 RGB 768 pixels)
Power Circuit G768
Block
VBL
+24.0V CN2
VDIM Back light Assembly
(14pin) LED Converter
# 13 (80ea LED)
PDIM
# 14
1.2 Features
z LVDS interface with 1 pixel / clock
z High-speed response
z Low color shift image quality
z 8-bit color depth, display 16.7M colors
z High luminance and contrast ratio, low reflection and wide viewing angle
z DE (Data Enable) only mode
z AFFS technology is applied for high display quality
z RoHS compliant
B2010-6011-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT P0 2011.4.12
SPEC. NUMBER SPEC. TITLE PAGE
HV320WXC-200 Preliminary Product Specification Rev.P0 5 OF 27
1.3 Application
z Home Alone Multimedia TFT-LCD TV
z Display Terminals for Control System
z High Definition TV(HD TV)
z AV application Products
1.4 General Specification
< Table 1. General Specifications >
Parameter Specification Unit Remarks
Active area 697.685(H) 392.256(V) mm
Number of pixels 1366(H) 768(V) pixels
Pixel pitch 170.25(H) RGB 510.75(V)
Pixel arrangement Pixels RGB Vertical stripe
Display colors 16.7M(8bits-true) colors
Display mode Transmission mode, Normally Black
Outline Dimension 735.4(H) 433.0(V) 16.2(D) typ. mm
Weight 5900 (max.) gram
Power Consumption Total=39.2Watt (Typ.)
Watt
(Logic=3.2W, BL=36W )
Surface Treatment Haze 10%, 3H, Semi-glare treatment
(Front Polarizer)
B2010-6011-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT P0 2011.4.12
SPEC. NUMBER SPEC. TITLE PAGE
HV320WXC-200 Preliminary Product Specification Rev.P0 6 OF 27
2.0 ABSOLUTE MAXIMUM RATINGS
The followings are maximum values which, if exceed, may cause faulty operation or
damage to the unit. The operational and non-operational maximum voltage and current
values are listed in Table 2.
< Table 2. LCD Module Electrical Specifications > [VSS=GND=0V]
Parameter Symbol Min. Max. Unit Remarks
Power Supply LCD Module VDD VSS-0.3 13.2 V
Voltage Ta = 25
Converter VBL VSS-0.3 26.4 V
Operating Temperature TOP 0 +50
TSUR 0 +60
Storage Temperature TST -20 +60 Note 1
Operating Ambient Humidity Hop 10 80 %RH
Storage Humidity Hst 10 80 %RH
Note 1 : Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39 max. and no condensation of water.
C
B2010-6011-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT P0 2011.4.12
SPEC. NUMBER SPEC. TITLE PAGE
HV320WXC-200 Preliminary Product Specification Rev.P0 7 OF 27
3.0 ELECTRICAL SPECIFICATIONS
3.1 TFT LCD Module
< Table 3. LCD Module Electrical Specifications > [Ta =25 2 ]
Values
Parameter Symbol Unit Notes
Min Typ Max
Power Supply Input Voltage VDD 10.8 12 13.2 Vdc
Power Supply Ripple Voltage VRP 300 mV
Power Supply Current IDD - 266 525 mA
1
Power Consumption PDD 3.2 6.3 Watt
Rush current IRUSH - - 3.0 A 2
Differential Input High
VLVTH +100 +300 mV
Threshold Voltage
LVDS
Differential Input Low
Interface VLVTL -300 -100 mV
Threshold Voltage
Common Input Voltage VLVC 1.0 1.2 1.4 V
Input High Threshold
VIH 2.7 - 3.3 V
CMOS Voltage
Interface Input Low Threshold
VIL 0 - 0.6 V
Voltage
Notes : 1. The supply voltage is measured and specified at the interface connector of LCM.
The current draw and power consumption specified is for VDD=12.0V, Frame rate fV=60Hz and
Clock frequency = 75.4MHz. Test Pattern of power supply current
a) Typ : Mosaic 8 x 6 Pattern(L0/L255) b) Max : Skip 1H2V Sub Dot Pattern(L0/L255)
2. The duration of rush current is about 2ms and rising time of Power Input is 1ms(min)
B2010-6011-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT P0 2011.4.12
SPEC. NUMBER SPEC. TITLE PAGE
HV320WXC-200 Preliminary Product Specification Rev.P0 8 OF 27
3.2 LED Converter
< Table 4. LED Converter Electrical Specifications > [Ta =25 2 ]
Values
Parameter Symbol Condition Unit Notes
Min. Typ. Max.
Input Voltage VBL 22.8 24.0 25.2 V
Input Current IBL VDIM=3.3V - 1.5 1.7 A 1
Rush current IRUSH VBL= 24V - - 3 A
Power
PBL Typ Luminance - 36 40 Watt
Consumption
BL ON = High 2.8 3.3 5 V
B/L on/off control VON/OFF
BL OFF =Low 0 - 0.8 V
VDIM Voltage 0 3.3 V
Analog Dimming
LDIM Luminance 20 100 %
PWM Frequency FPWM 140 190 240 Hz
High Level 2.8 3.3 5 V
PWM Level
Low Level 0 - 0.5 V
PWM Duty DPWM 10 - 100 % 2
Life Time 30,000 - - Hrs 3
Notes: 1.The specified current and power consumption are under the typical supply Input voltage,
24V. It is total power consumption.
2. High-duty = On/(On+Off) * 100
3. The life time of LED, 30,000Hrs, is determined as the time at which luminance of the
LED is 50% compared to that of initial value at the typical LED current on condition of
continuous operating at 25 r 2 C.
B2010-6011-O(3/3) A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT P0 2011.4.12
SPEC. NUMBER SPEC. TITLE PAGE
HV320WXC-200 Preliminary Product Specification Rev.P0 9 OF 27
4.0 INTERFACE CONNECTION
4.1 Module Input Signal & Power
- Connector : IS100-L30B-C23(Manufactured by UJU) or Equivalent.
< Table 5. LCM Module Input Connector Pin Configuration >
Pin No Symbol Description Pin No Symbol Description
1 VDD Power Supply +12.0V 16 RX1+ LVDS Receiver Signal(+)
2 VDD Power Supply +12.0V 17 GND Ground
3 VDD Power Supply +12.0V 18 RX2- LVDS Receiver Signal(-)
4 VDD Power Supply +12.0V 19 RX2+ LVDS Receiver Signal(+)
5 GND Ground 20 GND Ground
6 GND Ground 21 RCLK- LVDS Receiver Clock Signal(-)
7 GND Ground 22 RCLK+ LVDS Receiver Clock Signal(+)
8 GND Ground 23 GND Ground
9 LVDS_SEL `L'=JEIDA , `H'or NC= VESA 24 RX3- LVDS Receiver Signal(-)
10 NC No Connection 25 RX3+ LVDS Receiver Signal(+)
11 GND Ground 26 GND Ground
`L' or NC=Free run mode ,
12 RX0- LVDS Receiver Signal(-) 27 BIST
`H'= BIST mode
13 RX0+ LVDS Receiver Signal(+) 28 NC No Connection
14 GND Ground 29 NC No Connection
15 RX1- LVDS Receiver Signal(-) 30 GND Ground
Notes : 1. NC(Not Connected) : This pins are only used for BOE internal operations.
2. Input Level of LVDS signal is based on the IEA 664 Standard.
3. LVDS_SEL : This pin is used for selecting LVDS signal data format.
If this Pin : High (3.3V) or Open (NC) ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
