Image preview - the first page of the document

>> Download Panel_CHIMEI_INNOLUX_M185BGE-L21_0_[DS] documenatation <<

Text preview - extract from the document

Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION

Doc. Number: M185BGE-L21-DR2- 01

Tentative Specification
Preliminary Specification
Approval Specification

MODEL NO.: M185BGE-L21

Customer:

APPROVED BY SIGNATURE

Name / Title
Note

Please return 1 copy for your confirmation with your
signature and comments.

Approved By Checked By Prepared By

Version 0.0 19 April 2011 1 / 29
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION

CONTENTS
1. GENERAL DESCRIPTION ...................................................................................................... 4
1.1 OVERVIEW ....................................................................................................................... 4
1.2 GENERAL SPECIFICATIONS ........................................................................................... 4
2. MECHANICAL SPECIFICATIONS .......................................................................................... 4
3. ABSOLUTE MAXIMUM RATINGS .......................................................................................... 4
3.1 ABSOLUTE RATINGS OF ENVIRONMENT...................................................................... 4
3.2 ELECTRICAL ABSOLUTE RATINGS ................................................................................ 5
3.2.1 TFT LCD MODULE .................................................................................................... 5
3.2.2 BACKLIGHT UNIT...................................................................................................... 5
4. ELECTRICAL SPECIFICATIONS............................................................................................ 6
4.1 FUNCTION BLOCK DIAGRAM ......................................................................................... 6
4.2. INTERFACE CONNECTIONS .......................................................................................... 6
4.3 ELECTRICAL CHARACTERISTICS .................................................................................. 8
4.3.1 LCD ELECTRONICS SPECIFICATION...................................................................... 8
4.3.2 Vcc Power Dip Condition.......................................................................................... 10
4.3.3 BACKLIGHT UNIT (LED matrix is 7S4P) ................................................................. 10
4.3.4 LIGHTBAR Connector Pin Assignment .....................................................................11
4.4 LVDS INPUT SIGNAL SPECIFICATIONS ....................................................................... 11
4.4.1 LVDS DATA MAPPING TABLE ..................................................................................11
4.4.2 COLOR DATA INPUT ASSIGNMENT....................................................................... 12
4.5 DISPLAY TIMING SPECIFICATIONS .............................................................................. 13
4.6 POWER ON/OFF SEQUENCE........................................................................................ 15
5. OPTICAL CHARACTERISTICS ............................................................................................ 16
5.1 TEST CONDITIONS ........................................................................................................ 16
5.2 OPTICAL SPECIFICATIONS ........................................................................................... 16
6. RELIABILITY TEST ITEM ..................................................................................................... 19
7. PACKING............................................................................................................................... 20
7.1 PACKING SPECIFICATIONS .......................................................................................... 20
7.2 PACKING METHOD ........................................................................................................ 20
7.3 PALLET............................................................................................................................ 21
9. PRECAUTIONS ..................................................................................................................... 27
9.1 ASSEMBLY AND HANDLING PRECAUTIONS ............................................................... 27
9.2 STORAGE PRECAUTIONS ............................................................................................ 27
9.3 OPERATION PRECAUTIONS ......................................................................................... 27
9.4 SAFETY PRECAUTIONS ................................................................................................ 27
9.5 SAFETY STANDARDS .................................................................................................... 27
9.6 OTHER ............................................................................................................................ 27
Appendix. OUTLINE DRAWING ............................................................................................... 27

Version 0.0 19 April 2011 2 / 29
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION

REVISION HISTORY
Version Date Page Description

V.0 Dec.08, 2010 All Spec V.0 was first issued.

V.1 Jan.08, 2011 10 IPIN Page

Version 0.0 19 April 2011 3 / 29
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION

1. GENERAL DESCRIPTION
1.1 OVERVIEW
M185BGE-L21 is a 18.5" TFT Liquid Crystal Display module with WLED Backlight unit and 30 pins
1ch-LVDS interface. This module supports 1366 x 768 Full HD mode and can display up to 16.7M colors.
The converter module for Backlight is not built in.
1.2 GENERAL SPECIFICATIONS
Item Specification Unit Note
Screen Size 18.5" real diagonal
Driver Element a-si TFT active matrix - -
Pixel Number 1366x R.G.B. x 768 pixel -
Pixel Pitch 0.3(H) X 0.3 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7M color -
Transmissive Mode Normally white - -
Surface Treatment AG type, 3H hard coating - -
B/L UNIT White LED Light bar (Right Side)
LED connector 6Pin
Luminance, White 300(Typ.) Cd/m2
Power Consumption Total 10.137W (Max.) @ cell 3.30W (Max.), BL 6.66W (Max.) (1)
ROHS, Halogen Free &TCO'03 ROHS, Halogen Free &TCO' 03 compliance
Color Saturation 72% NTSC
Note (1) The specified power consumption: Total= cell (reference 4.3.1)+BL (reference 4.3.3)

2. MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 429.87 430.37 430.87 mm
Module Size Vertical (V) 254.1 254.6 255.1 mm (1)
Thickness (T) -- 9.3 9.7 mm
Horizontal 413.2 413.4 413.6 mm
Bezel Area
Vertical 233.8 234 234.2 mm
Horizontal 409.8 mm
Active Area
Vertical 230.4 mm
Weight 1420 1800 mm
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.

3. ABSOLUTE MAXIMUM RATINGS
3.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 60
