Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_M220Z3-LA3_0_[DS]](/pics/5c8ebc1d87d01.gif)
>> Download Panel_CHIMEI_INNOLUX_M220Z3-LA3_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
Doc. Number :
Tentative Specification
Preliminary Specification
Approval Specification
MODEL NO.: M220Z3
SUFFIX: LA3
Customer:
APPROVED BY SIGNATURE
Name / Title
Note
Please return 1 copy for your confirmation with your
signature and comments.
Approved By Checked By Prepared By
2010.11.03
Version 1.0 4 November 2010 1 / 28
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
CONTENTS
1. GENERAL DESCRIPTION ...................................................................................................... 5
1.1 OVERVIEW ....................................................................................................................... 5
1.2 GENERAL SPECIFICATIONS ........................................................................................... 5
2. MECHANICAL SPECIFICATIONS .......................................................................................... 5
3. ABSOLUTE MAXIMUM RATINGS .......................................................................................... 6
3.1 ABSOLUTE RATINGS OF ENVIRONMENT...................................................................... 6
3.2 ELECTRICAL ABSOLUTE RATINGS ................................................................................ 7
3.2.1 TFT LCD MODULE .................................................................................................... 7
3.2.2 BACKLIGHT UNIT...................................................................................................... 7
4. ELECTRICAL SPECIFICATIONS............................................................................................ 8
4.1 FUNCTION BLOCK DIAGRAM ......................................................................................... 8
4.2. INTERFACE CONNECTIONS .......................................................................................... 8
4.3 ELECTRICAL CHARACTERISTICS ................................................................................ 10
4.3.1 LCD ELETRONICS SPECIFICATION ...................................................................... 10
4.3.2 Vcc Power Dip Condition.......................................................................................... 12
4.3.3 BACKLIGHT UNIT (LED matrix is 14S8P) ............................................................... 12
4.3.4 LIGHTBAR Connector Pin Assignment .................................................................... 13
4.4 LVDS INPUT SIGNAL SPECIFICATIONS ....................................................................... 13
4.4.1 LVDS DATA MAPPING TABLE ................................................................................. 13
4.4.2 COLOR DATA INPUT ASSIGNMENT....................................................................... 14
4.5 DISPLAY TIMING SPECIFICATIONS .............................................................................. 15
4.6 POWER ON/OFF SEQUENCE........................................................................................ 17
5. OPTICAL CHARACTERISTICS ............................................................................................ 18
5.1 TEST CONDITIONS ........................................................................................................ 18
5.2 OPTICAL SPECIFICATIONS ........................................................................................... 18
6. RELIABILITY TEST ITEM ..................................................................................................... 21
7. PACKING............................................................................................................................... 22
7.1 PACKING SPECIFICATIONS .......................................................................................... 22
7.2 PACKING METHOD ........................................................................................................ 22
7.3 PALLET............................................................................................................................ 23
8. CMI MODULE LABEL ........................................................................................................... 24
9. PRECAUTIONS ..................................................................................................................... 25
9.1 ASSEMBLY AND HANDLING PRECAUTIONS ............................................................... 25
9.2 STORAGE PRECAUTIONS ............................................................................................ 25
9.3 OPERATION PRECAUTIONS ......................................................................................... 25
Version 1.0 4 November 2010 2 / 28
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
9.4 SAFETY PRECAUTIONS ................................................................................................ 26
9.5 SAFETY STANDARDS .................................................................................................... 26
9.6 OTHER ............................................................................................................................ 26
Appendix. OUTLINE DRAWING ............................................................................................... 26
Version 1.0 4 November 2010 3 / 28
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
REVISION HISTORY
Version Date Page Description
1.0 Oct,28, 2010 All Spec Ver.1.0 was first issued.
Version 1.0 4 November 2010 4 / 28
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
The M220Z3-LA3 model is a 22 inch wide TFT-LCD slimming module with a WLED light bar Backlight Unit
and a 30-pin 2ch-LVDS interface. This module supports 1680 x 1050 WSXGA+ (16:10 wide screen) mode
and displays up to 16.7 millions colors. The converter module for the Backlight Unit is not built in.
1.2 GENERAL SPECIFICATIONS
Item Specification Unit Note
Screen Size 22 inch
Driver Element a-Si TFT active matrix - -
Pixel Number 1680 x R.G.B. x 1050 pixel -
Pixel Pitch 0.282(H) x 0.282(V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7 millions color -
Transmissive Mode Normally White - -
Surface Treatment Hard coating (3H), AG (Haze 25%) - -
Luminance, White 250 (typical) Cd/m2
Color Gamut 72% of NTSC(Typ.)
TCO TCO 5.0 compliance
Power Consumption Total14.60W (Max.) @ cell 5.0W (Max.), BL 9.6W (Max.) (1)
Note (1) The specified power consumption : Total= cell (reference 4.3.1)+BL (reference 4.3.3)
2. MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 493.2 493.7 494.2 mm
Module Size Vertical (V) 319.6 320.1 320.6 mm (1)
Thickness (T) 10.5 11 11.5 mm
Horizontal 477.4 477.7 478 mm
Bezel Area
Vertical 299.8 300.1 300.4 mm
Horizontal - 473.76 - mm
Active Area
Vertical - 296.1 - mm
Weight - 2200 2290 g
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Version 1.0 4 November 2010 5 / 28
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
3. ABSOLUTE MAXIMUM RATINGS
3.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
