Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_MT215DW02_V-0_0_[DS]](/pics/5c8ebcb34db4c.gif)
>> Download Panel_CHIMEI_INNOLUX_MT215DW02_V-0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
CONTENTS
1. GENERAL DESCRIPTION ...................................................................................................... 3
1.1 OVERVIEW ....................................................................................................................... 3
1.2 GENERAL SPECIFICATI0NS ............................................................................................ 3
2. MECHANICAL SPECIFICATIONS .......................................................................................... 3
3. ABSOLUTE MAXIMUM RATINGS .......................................................................................... 3
3.1 ABSOLUTE RATINGS OF ENVIRONMENT...................................................................... 3
3.2 ELECTRICAL ABSOLUTE RATINGS ................................................................................ 3
3.2.1 TFT LCD MODULE .................................................................................................... 3
3.2.3 BACKLIGHT UNIT...................................................................................................... 3
4. ELECTRICAL SPECIFICATIONS............................................................................................ 3
4.1 FUNCTION BLOCK DIAGRAM ......................................................................................... 3
4.2. INTERFACE CONNECTIONS .......................................................................................... 3
4.3 ELECTRICAL CHARACTERISTICS .................................................................................. 3
4.3.1 LCD ELETRONICS SPECIFICATION ........................................................................ 3
4.3.2 Vcc Power Dip Condition............................................................................................ 3
4.3.3 BACKLIGHT UNIT (LED matrix is 12S8P) ................................................................. 3
4.3.4 LIGHTBAR Connector Pin Assignment ...................................................................... 3
4.4 LVDS INPUT SIGNAL SPECIFICATIONS ......................................................................... 3
4.4.1 LVDS DATA MAPPING TABLE ................................................................................... 3
4.4.2 COLOR DATA INPUT ASSIGNMENT......................................................................... 3
4.5 DISPLAY TIMING SPECIFICATIONS ................................................................................ 3
4.6 POWER ON/OFF SEQUENCE.......................................................................................... 3
5. OPTICAL CHARACTERISTICS .............................................................................................. 3
5.1 TEST CONDITIONS .......................................................................................................... 3
5.2 OPTICAL SPECIFICATIONS ............................................................................................. 3
6. RELIABILITY TEST ITEM ......................................................................................................... 3
7. PACKING................................................................................................................................. 3
7.1 PACKING SPECIFICATIONS ............................................................................................ 3
7.2 PACKING METHOD .......................................................................................................... 3
7.3 PALLET.............................................................................................................................. 3
8. CMI LABEL.............................................................................................................................. 3
9. PRECAUTIONS ....................................................................................................................... 3
9.1 ASSEMBLY AND HANDLING PRECAUTIONS ................................................................. 3
9.2 STORAGE PRECAUTIONS .............................................................................................. 3
9.3 OPERATION PRECAUTIONS ........................................................................................... 3
Version 0.0 2 / 28 The
copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
9.4 SAFETY PRECAUTIONS .................................................................................................. 3
9.5 SAFETY STANDARDS ...................................................................................................... 3
9.6 OTHER .............................................................................................................................. 3
Appendix. OUTLINE DRAWING ................................................................................................. 3
Version 0.0 3 / 28 The
copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
REVISION HISTORY
Version Date Page Description
0.0 Sept.13, 2010 All Spec Ver.0.0 was first issued.
Version 0.0 4 / 28 The
copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
1. GENERAL DESCRIPTION
1.1 OVERVIEW
MT215DW02 V.0 is a 21.5" TFT Liquid Crystal Display module with WLED Backlight unit and 30 pins
2ch-LVDS interface. This module supports 1920 x 1080 Full HD mode and can display up to 16.7M colors.
The converter module for Backlight is not built in.
1.2 GENERAL SPECIFICATIONS
Item Specification Unit Note
Screen Size 21.53" real diagonal
Driver Element a-si TFT active matrix - -
Pixel Number 1920 x R.G.B. x 1080 pixel -
Pixel Pitch 0.248 (H) x 0.248 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7M color -
Transmissive Mode Normally white - -
Surface Treatment AG type, 3H hard coating - -
Luminance, White 250(Typ.) Cd/m2
Power Consumption Total 17.34 W (Max.) @ cell 6.5 W (Max.), BL 10.84 W (Max.) (1)
TCO 5.0 TCO 5.0 compliance -
Color Saturation 72% NTSC -
Note (1) The specified power consumption : Total= cell (reference 4.3.1)+BL (reference 4.3.3)
2. MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 495.1 495.6 496.1 mm
Module Size Vertical (V) 291.7 292.2 292.7 mm (1)
Thickness (T) 10.5 11 11.5 mm
Horizontal 479.59 479.84 480.09 mm
Bezel Area
Vertical 271.1 271.3 271.5 mm
Horizontal - 476.64 - mm
Active Area
Vertical - 268.11 - mm
Weight - 2000 2100 g
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
3. ABSOLUTE MAXIMUM RATINGS
3.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
