Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_N133BGE-L11_0_[DS]](/pics/5c8ebcc3cce7d.gif)
>> Download Panel_CHIMEI_INNOLUX_N133BGE-L11_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
Doc. Number:
Tentative Specification
Preliminary Specification
Approval Specification
MODEL NO.: N133BGE
SUFFIX: L11
Customer: Toshiba
APPROVED BY SIGNATURE
Name / Title
Note
Please return 1 copy for your confirmation with your
signature and comments.
Approved By Checked By Prepared By
2010-10-04 2010-09-23 2010-09-17
10:48:28 CST 16:30:08 CST 12:03:37 CST
Version 3.0 4 October 2010 1 / 28
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
CONTENTS
1. GENERAL DESCRIPTION .........................................................................................................4
1.1 OVERVIEW..................................................................................................................4
1.2 GENERAL SPECIFICATI0NS......................................................................................4
2. MECHANICAL SPECIFICATIONS ............................................................................................. 4
2.1 CONNECTOR TYPE....................................................................................................4
3. ABSOLUTE MAXIMUM RATINGS ............................................................................................. 5
3.1 ABSOLUTE RATINGS OF ENVIRONMENT ...............................................................5
3.2 ELECTRICAL ABSOLUTE RATINGS .........................................................................5
3.2.1 TFT LCD MODULE ...............................................................................................5
4. ELECTRICAL SPECIFICATIONS............................................................................................... 6
4.1 FUNCTION BLOCK DIAGRAM...................................................................................6
4.2. INTERFACE CONNECTIONS ....................................................................................6
4.3 ELECTRICAL CHARACTERISTICS ...........................................................................8
4.3.1 LCD ELETRONICS SPECIFICATION...................................................................8
4.3.2 LED CONVERTER SPECIFICATION .................................................................10
4.3.3 BACKLIGHT UNIT ..............................................................................................12
4.4 LVDS INPUT SIGNAL TIMING SPECIFICATIONS ...................................................13
4.4.1 LVDS DC SPECIFICATIONS ..............................................................................13
4.4.2 LVDS DATA FORMAT .........................................................................................13
4.4.3 COLOR DATA INPUT ASSIGNMENT .................................................................14
4.5 DISPLAY TIMING SPECIFICATIONS........................................................................15
4.6 POWER ON/OFF SEQUENCE ..................................................................................16
5. OPTICAL CHARACTERISTICS ............................................................................................... 17
5.1 TEST CONDITIONS ..................................................................................................17
5.2 OPTICAL SPECIFICATIONS.....................................................................................17
6. RELIABILITY TEST ITEM ........................................................................................................ 20
7. PACKING.................................................................................................................................. 21
7.1 MODULE LABEL.......................................................................................................21
7.2 CARTON....................................................................................................................22
7.3 PALLET .....................................................................................................................23
8. PRECAUTIONS ........................................................................................................................ 24
8.1 HANDLING PRECAUTIONS .....................................................................................24
8.2 STORAGE PRECAUTIONS ......................................................................................24
8.3 OPERATION PRECAUTIONS ...................................................................................24
Appendix. EDID DATA STRUCTURE.............................................................................25
Appendix. OUTLINE DRAWING.....................................................................................28
Version 3.0 4 October 2010 2 / 28
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
REVISION HISTORY
Version Date Page Description
3.0 Sep.16, 2010 All Spec Ver.3.0 was first issued.
Version 3.0 4 October 2010 3 / 28
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
N133BGE-L11 is a 13.3" (13.3 diagonal) TFT liquid crystal display module with LED backlight unit
and 40 pins LVDS interface. This module supports 1366 x 768 HD mode and can display 262,144
colors. The optimum viewing angle is at 6 o'clock direction.
1.2 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Screen Size 13.3 diagonal
Driver Element a-si TFT active matrix - -
Pixel Number 1366 x R.G.B. x 768 pixel -
Pixel Pitch 0.2148 (H) x 0.2148 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 262,144 color -
Transmissive Mode Normally white - -
Surface Treatment Anti-Glare - -
Luminance, White 200 Cd/m2
Power Consumption Total 2.85 W (Max.) @ cell 0.65 W (Max.), BL 2.2 W (Max.) (1)
Note (1) The specified power consumption (with converter efficiency) is under the conditions at VCCS =
