Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_N133BGE-LB1_0_[DS]](/pics/5c8ebce32c423.gif)
>> Download Panel_CHIMEI_INNOLUX_N133BGE-LB1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
Doc. Number :
Tentative Specification
Preliminary Specification
Final Specification
MODEL NO.: N133BGE
SUFFIX: LB1
Customer: SONY
APPROVED BY SIGNATURE
Name / Title
Note
Please return 1 copy for your confirmation with your
signature and comments.
Approved By Checked By Prepared By
2012-03-05 2012-02-29 2012-02-24
22:33:52 CST 11:13:39 CST 09:42:34 CST
Version 3.0 6 March 2012 1 / 30
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
CONTENTS
1. GENERAL DESCRIPTION .........................................................................................................4
1.1 OVERVIEW ....................................................................................................................................... 4
1.2 GENERAL SPECIFICATI0NS .......................................................................................................... 4
2. MECHANICAL SPECIFICATIONS ............................................................................................. 4
2.1 INTERFACE CONNECTION............................................................................................................ 4
3. ABSOLUTE MAXIMUM RATINGS ............................................................................................. 5
3.1 ABSOLUTE RATINGS OF ENVIRONMENT ................................................................................. 5
3.2 ELECTRICAL ABSOLUTE RATINGS............................................................................................. 5
3.2.1 TFT LCD MODULE ............................................................................................................5
4. ELECTRICAL SPECIFICATIONS............................................................................................... 6
4.1 FUNCTION BLOCK DIAGRAM...................................................................................................... 6
4.2. INTERFACE CONNECTIONS ........................................................................................................ 6
4.3 ELECTRICAL CHARACTERISTICS............................................................................................... 8
4.3.1 LCD ELETRONICS SPECIFICATION...............................................................................8
4.3.2 LED CONVERTER SPECIFICATION..............................................................................10
4.3.3 BACKLIGHT UNIT...................................................................................................................... 12
4.4 LVDS INPUT SIGNAL TIMING SPECIFICATIONS .................................................................... 13
4.4.1 LVDS DC SPECIFICATIONS ...........................................................................................13
4.4.2 LVDS DATA FORMAT ......................................................................................................13
4.4.3 COLOR DATA INPUT ASSIGNMENT ............................................................................14
4.5 DISPLAY TIMING SPECIFICATIONS .......................................................................................... 15
4.6 POWER ON/OFF SEQUENCE ....................................................................................................... 16
5. OPTICAL CHARACTERISTICS ............................................................................................... 17
5.1 TEST CONDITIONS........................................................................................................................ 17
5.2 OPTICAL SPECIFICATIONS ......................................................................................................... 17
6. RABILITY TEST ITEM .............................................................................................................. 21
7. PACKING.................................................................................................................................. 22
7.1 CMI MODULE LABEL................................................................................................................... 22
7.2 CARTON .......................................................................................................................................... 23
7.3 PALLET............................................................................................................................................ 24
8. PRECAUTIONS ........................................................................................................................ 25
8.1 HANDLING PRECAUTIONS......................................................................................................... 25
8.2 STORAGE PRECAUTIONS ........................................................................................................... 25
8.3 OPERATION PRECAUTIONS........................................................................................................ 25
Appendix. EDID DATA STRUCTURE.................................................................................................. 26
Appendix. OUTLINE DRAWING ......................................................................................................... 29
Version 3.0 6 March 2012 2 / 30
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
REVISION HISTORY
Version Date Page Description
3.0 Feb.23, 2012 All Spec Ver.3.0 was first issued
Version 3.0 6 March 2012 3 / 30
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
N133BGE-LB1 is a 13.3" (13.3" diagonal) TFT Liquid Crystal Display module with LED Backlight
unit and 40 pins LVDS interface. This module supports 1366 x 768 HD mode and can display
262,144 colors. The optimum viewing angle is at 6 o'clock direction.
1.2 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Screen Size 13.3 diagonal
Driver Element a-si TFT active matrix - -
Pixel Number 1366 x R.G.B. x 768 pixel -
Pixel Pitch 0.2148 (H) x 0.2148 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 262,144 color -
Transmissive Mode Normally white - -
Surface Treatment Hard coating (3H), Glare - -
Luminance, White 200 Cd/m2
Power Consumption Total 2.85 W (Max.) @ cell 0.7 W (Max.), BL 2.15 W (Max.) (1)
Note (1) The specified power consumption (with converter efficiency) is under the conditions at VCCS =
3.3 V, fv = 60 Hz, LED_VCCS = Typ, fPWM = 200 Hz, Duty=100% and Ta = 25 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
