Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_N156B6-P03_0_[DS]](/pics/5c8ebdae5ecb9.gif)
>> Download Panel_CHIMEI_INNOLUX_N156B6-P03_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
Doc. Number:
Tentative Specification
Preliminary Specification
Approval Specification
MODEL NO.: N156B6
SUFFIX: P03
Customer:
APPROVED BY SIGNATURE
Name / Title
Note
Please return 1 copy for your confirmation with your
signature and comments.
Approved By Checked By Prepared By
Version 2.0 6 August 2011 1 / 27
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
CONTENTS
1. GENERAL DESCRIPTION ......................................................................................................... 4
1.1 OVERVIEW ................................................................................................................................ 4
1.2 GENERAL SPECIFICATI0NS ................................................................................................... 4
2. MECHANICAL SPECIFICATIONS ............................................................................................. 4
2.1 CONNECTOR TYPE .................................................................................................................. 4
3. ABSOLUTE MAXIMUM RATINGS ............................................................................................. 6
3.1 ABSOLUTE RATINGS OF ENVIRONMENT .......................................................................... 6
3.2 ABSOLUTE RATINGS OF ENVIRONMENT (OPEN CELL)..........................................5
3.3 ELECTRICAL ABSOLUTE RATINGS...................................................................................... 7
3.3.1 TFT LCD MODULE ............................................................................................................7
4. ELECTRICAL SPECIFICATIONS ............................................................................................... 8
4.1 FUNCTION BLOCK DIAGRAM............................................................................................... 8
4.2. INTERFACE CONNECTIONS ................................................................................................. 8
4.3 ELECTRICAL CHARACTERISTICS ...................................................................................... 11
4.3.1 LCD ELETRONICS SPECIFICATION ............................................................................. 11
4.3.2 LED CONVERTER SPECIFICATION ..............................................................................13
4.4 LVDS INPUT SIGNAL TIMING SPECIFICATIONS ............................................................. 15
4.4.1 LVDS DC SPECIFICATIONS ...........................................................................................15
4.4.2 LVDS DATA FORMAT ......................................................................................................15
4.4.3 COLOR DATA INPUT ASSIGNMENT ............................................................................16
4.5 DISPLAY TIMING SPECIFICATIONS ................................................................................... 17
4.6 POWER ON/OFF SEQUENCE ................................................................................................ 18
5. OPTICAL CHARACTERISTICS ............................................................................................... 19
5.1 TEST CONDITIONS................................................................................................................. 19
5.2 OPTICAL SPECIFICATIONS .................................................................................................. 19
6. PACKING .................................................................................................................................. 23
6.1 CMO OPEN CELL LABEL ...................................................................................................... 23
6.2 Package Reliability
6.3 CARTON ................................................................................................................................... 24
6.4 PALLET ..................................................................................................................................... 25
7. PRECAUTIONS ........................................................................................................................ 26
7.1 HANDLING PRECAUTIONS .................................................................................................. 26
7.2 STORAGE PRECAUTIONS .................................................................................................... 26
7.3 OPERATION PRECAUTIONS................................................................................................. 26
Appendix. EDID DATA STRUCTURE.............................................................. !
Appendix. OUTLINE DRAWING .................................................................................................. 27
Version 2.0 6 August 2011 2 / 27
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
REVISION HISTORY
Version Date Page Description
2.0 Mar.15, 2011 All Approval spec Ver.2.0 was first issued.
Version 2.0 6 August 2011 3 / 27
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
N156B6-P03 is a 15.6" (15.547" diagonal) TFT Liquid Crystal Display with LED Driver ICs and a
40-pins-and-1ch-LVDS circuit board. This product supports 1366 x 768 HD mode and can display
262,144 colors. The backlight unit is not built in.
1.2 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Screen Size 15.547 diagonal
Driver Element a-si TFT active matrix - -
Pixel Number 1366 x R.G.B. x 768 pixel -
Pixel Pitch 0.252 (H) x 0.252 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 262,144 color -
Transmissive Mode Normally white - -
Surface Treatment Hard coating (3H), Anti-Glare - -
2. MECHANICAL SPECIFICATIONS
item Min. Typ. Max. Unit Note
Horizontal (H) with PCB 353.13 353.63 354.13 mm
Horizontal (H) w/o PCB 353.13 353.63 354.13 mm
Vertical (V) with PCB 248.54 249.54 250.54 mm
Size
Vertical (V) w/o PCB 202.08 203.08 204.08 mm
Thickness (T) with PCB - 1.7 1.8 mm (1) (2)
Thickness (T) w/o PCB - 1.27 mm
Weight - 215 220 g
The mounting inclination of the connector makes
I/F connector mounting position
