Image preview - the first page of the document

>> Download Panel_CHIMEI_INNOLUX_N156BGE-L21_1_[DS] documenatation <<

Text preview - extract from the document

Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION

Doc. Number:

Tentative Specification
Preliminary Specification
Approval Specification

MODEL NO.: N156BGE
SUFFIX: L21

Customer: ASUS

APPROVED BY SIGNATURE

Name / Title
Note

Please return 1 copy for your confirmation with your
signature and comments.

Approved By Checked By Prepared By

2010-12-30 2010-12-30 2010-12-20
16:03:35 CST 15:20:31 CST 17:23:41 CST

Version 3.0 30 December 2010 1 / 30
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION

CONTENTS
1. GENERAL DESCRIPTION .........................................................................................................4
1.1 OVERVIEW ................................................................................................................................ 4
1.2 GENERAL SPECIFICATI0NS ................................................................................................... 4
2. MECHANICAL SPECIFICATIONS ............................................................................................. 4
2.1 CONNECTOR TYPE .................................................................................................................. 4
3. ABSOLUTE MAXIMUM RATINGS ............................................................................................. 5
3.1 ABSOLUTE RATINGS OF ENVIRONMENT .......................................................................... 5
3.2 ELECTRICAL ABSOLUTE RATINGS...................................................................................... 5
3.2.1 TFT LCD MODULE ............................................................................................................5
4. ELECTRICAL SPECIFICATIONS............................................................................................... 6
4.1 FUNCTION BLOCK DIAGRAM............................................................................................... 6
4.2. INTERFACE CONNECTIONS ................................................................................................. 6
4.3 ELECTRICAL CHARACTERISTICS........................................................................................ 8
4.3.1 LCD ELETRONICS SPECIFICATION...............................................................................8
4.3.2 LED CONVERTER SPECIFICATION..............................................................................10
4.3.3 BACKLIGHT UNIT...........................................................................................................12
4.4 LVDS INPUT SIGNAL TIMING SPECIFICATIONS ............................................................. 13
4.4.1 LVDS DC SPECIFICATIONS ...........................................................................................13
4.4.2 LVDS DATA FORMAT ......................................................................................................13
4.4.3 COLOR DATA INPUT ASSIGNMENT ............................................................................14
4.5 DISPLAY TIMING SPECIFICATIONS ................................................................................... 15
4.6 POWER ON/OFF SEQUENCE ................................................................................................ 16
5. OPTICAL CHARACTERISTICS ............................................................................................... 17
5.1 TEST CONDITIONS................................................................................................................. 17
5.2 OPTICAL SPECIFICATIONS .................................................................................................. 17
6. RELIABILITY TEST ITEM ........................................................................................................ 20
7. PACKING.................................................................................................................................. 22
7.1 MODULE LABEL .................................................................................................................... 22
7.2 CARTON ................................................................................................................................... 23
7.3 PALLET..................................................................................................................................... 24
8. PRECAUTIONS ........................................................................................................................ 25
8.1 HANDLING PRECAUTIONS.................................................................................................. 25
8.2 STORAGE PRECAUTIONS .................................................................................................... 25
8.3 OPERATION PRECAUTIONS................................................................................................. 25
Appendix. EDID DATA STRUCTURE........................................................................................... 26
Appendix. OUTLINE DRAWING .................................................................................................. 29

Version 3.0 30 December 2010 2 / 30
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION

REVISION HISTORY

Version Date Page Description

1.0 Aug.17, 2010 All Preliminary spec Ver.1.0 was first issued.

3.0 Oct, 29, 2010 All Approval spec Ver.3.0 was first issued.

Version 3.0 30 December 2010 3 / 30
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION

1. GENERAL DESCRIPTION
1.1 OVERVIEW
N156BGE-L21 is a 15.6" (15.547" diagonal) TFT Liquid Crystal Display module with LED Backlight
unit and 40 pins LVDS interface. This module supports 1366 x 768 HD mode and can display
262,144 colors. The optimum viewing angle is at 6 o'clock direction.
1.2 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Screen Size 15.547 diagonal
Driver Element a-si TFT active matrix - -
Pixel Number 1366 x R.G.B. x 768 pixel -
Pixel Pitch 0.252 (H) x 0.252 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 262,144 color -
Transmissive Mode Normally white - -
Surface Treatment Hard coating (3H), Glare - -
Luminance, White 220 Cd/m2
Power Consumption Total 5.184 W (Max.) @ cell 0.9 W (Max.), BL 4.284W (Max.) (1)
Note (1) The specified power consumption (with converter efficiency) is under the conditions at VCCS =
3.3 V, fv = 60 Hz, LED_VCCS = Typ, fPWM = 200 Hz, Duty=100% and Ta = 25
