Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_TM315GW11_V-1_0_[DS]](/pics/5c8ebe7bc0f0d.gif)
>> Download Panel_CHIMEI_INNOLUX_TM315GW11_V-1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 1
PA G E 3/22
InnoLux copyright
Version: 1.0 All rights reserved,
Copying forbidden.
Record of Revision
Version Revise Date Page Content
1 2010.03.04 All All
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 1
PA G E 4/22
Contents:
A. General Specification 5
B. Electrical Specifications 6
1. Pin assignment 6
2. Absolute maximum ratings 8
3. Electrical characteristics 9
a. Typical operating conditions 9
b. Display color vs. input data signals 12
c. Input signal timing 13
d. Display position 14
e. Backlight driving conditions 14
C. Optical specifications 16
D. Reliability test items 19
E. Safety 20
F. Display quality 20
G. Handling precaution 20
H. Label 21
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 1
PA G E 5/22
A. General specification
NO. Item Specification Remark
1 Display resolution (pixel) 1,366(H) X 768(V), WXGA+ resolution
2 Active area (mm) 697.685 (H) X 392.256(V)
3 Screen size (inch) 31.5 inches diagonal
4 Pixel pitch (mm) 0.17025 (H) X 0.51075 (V)
5 Color configuration R, G, B vertical stripe
6 Overall dimension (mm) 783.55 (W) X 462.55 (H) X 61.6(D)
7 Weight (g) 5300
8 Surface treatment Anti-glare, Haze=11%, Hard coating (3H) Note 1
9 Input color signal 8 bit LVDS
10 Display colors 16.7M
11 Color saturation 72% NTSC
12 Backlight 4U CCFL
13 RoHS & Halogen free RoHS & Halogen free compliance
Note 1: Glare Option available
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 1
PA G E 6/22
B. Electrical specifications
1. Pin assignment
Connector
STARCONN 106F30-000000-A2-R or mechanical interface equivalent connector.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 1
PA G E 7/22
Top view of LVDS connector
Side view of LVDS connector
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SPEC NO. T M 3 1 5 G W 11 V. 1
PA G E 8/22
2. Absolute maximum ratings
Values Unit
Parameter Symbol Remark
Min. Typ. Max.
LCD drive voltage Vcc -0.3 - 14.0 V At 25◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
