Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_V460H1-LH9_2_[DS]](/pics/5c8ec30681770.gif)
>> Download Panel_CHIMEI_INNOLUX_V460H1-LH9_2_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Feb. 12, 2010
Model No.: V460H1 - LH9
Approval
TFT LCD Approval Specification
MODEL NO.: V460H1 - LH9
Customer:
Approved by:
Note:
TV Product Marketing & Management Div
Approved By
Chao-Chun Chung
QA Dept. Product Development Div.
Reviewed By
Hsin-Nan Chen WT Lin
LCD TV Marketing and Product Management Div.
Prepared By
Ken Wu John Yen
1
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Feb. 12, 2010
Model No.: V460H1 - LH9
Approval
CONTENTS
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT INVERTER UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
3.2.1 CCFL(Cold Cathode Fluorescent Lamp) CHARACTERISTICS
3.2.2 INVERTER CHARACTERISTICS
3.2.3 INVERTER INTERFACE CHARACTERISTICS
4. BLOCK DIAGRAM ------------------------------------------------------- 15
4.1 TFT LCD MODULE
5. INTERFACE PIN CONNECTION ------------------------------------------------------- 16
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 INVERTER UNIT
5.4 BLOCK DIAGRAM OF INTERFACE
5.5 LVDS INTERFACE
5.6 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 25
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 28
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. DEFINITION OF LABELS ------------------------------------------------------- 32
9. PACKAGING ------------------------------------------------------- 34
9.1 PACKING SPECIFICATIONS
9.2 PACKING METHOD
10. PRECAUTIONS ------------------------------------------------------- 37
10.1 ASSEMBLY AND HANDLING PRECAUTIONS
10.2 SAFETY PRECAUTIONS
10.3 SAFETY STANDARDS
11. MECHANICAL CHARACTERISTICS ------------------------------------------------------- 38
12. APPENDIX ------------------------------------------------------- 41
2
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Feb. 12, 2010
Model No.: V460H1 - LH9
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver2.0 Feb. 12,'10 All All Approval Specification was first issued.
3
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Feb. 12, 2010
Model No.: V460H1 - LH9
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V460H1-LH9 is a 46" TFT Liquid Crystal Display module with 14-CCFL Backlight unit and 2ch-LVDS
interface. This module supports 1920 x 1080 HDTV format and can display true 16.7M colors (8-bit/color).
The inverter for backlight is built-in.
1.2 FEATURES
- High brightness (450nits)
- High contrast ratio (6000:1)
- Fast response time (Gray to Gray average 4.5 ms)
- High color saturation (72% NTSC)
- Full HDTV (1920 x 1080 pixels) resolution, true HDTV format
DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- Optimized response time for 120 Hz frame rate
- Ultra wide viewing angle: Super MVA technology
1.3 APPLICATION
- Standard Living Room TVs.
- Public Display Application.
- Home Theater Application.
- MFM Application.
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 1018.08(H) x 572.67(V) (46" diagonal) mm
(1)
Bezel Opening Area 1024.4(H) x 579.2(V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1920x R.G.B. x 1080 pixel -
Pixel Pitch(Sub Pixel) 0.17675(H) x 0.53025(V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7M color -
Display Operation Mode Transmissive mode / Normally black - -
Anti-Glare coating (Haze 11%)
Surface Treatment - (2)
Hardness (3H)
Note (1) Please refer to the attached drawings in chapter 9 for more information about the front and
back outlines.
Note (2) The spec of the surface treatment is temporarily for this phase. CMO reserves the rights to
change this feature.
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) - 1083 - mm
Module Size Vertical (V) - 627 - mm (1), (2)
Depth (D) - 51.2 - mm
Weight - 13270 - g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Note (2) Module Depth does not include connectors.
4
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Feb. 12, 2010
Model No.: V460H1 - LH9
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
