Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_V546H1-LH3_0_[DS]](/pics/5c8ec45ca421d.gif)
>> Download Panel_CHIMEI_INNOLUX_V546H1-LH3_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
Tentative Specification
Preliminary Specification
Approval Specification
MODEL NO.: V546H1
SUFFIX: LH3
W W Z K s z ^ /' E d h Z
E d
E
W
Approved By Checked By Prepared By
Chao-Chun
Ken Wu Wei-ting Hsu
Chung
s :
d ,/D/ / >
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
CONTENTS -
REVISION HISTORY ..................................................................................................................................................4
1. GENERAL DESCRIPTION ......................................................................................................................................5
1.1 OVERVIEW ....................................................................................................................................................5
1.2 FEATURES ....................................................................................................................................................5
1.3 APPLICATION................................................................................................................................................5
1.4 GENERAL SPECIFICATI0NS .........................................................................................................................5
1.5 MECHANICAL SPECIFICATIONS ..................................................................................................................5
2. ABSOLUTE MAXIMUM RATINGS ...........................................................................................................................6
2.1 ABSOLUTE RATINGS OF ENVIRONMENT....................................................................................................6
2.2 ELECTRICAL ABSOLUTE RATINGS..............................................................................................................7
3. ELECTRICAL CHARACTERISTICS ........................................................................................................................8
3.1 TFT LCD MODULE.........................................................................................................................................8
3.2 BACKLIGHT UNIT........................................................................................................................................ 11
4.1 TFT LCD MODULE.......................................................................................................................................15
5 .INPUT TERMINAL PIN ASSIGNMENT ..................................................................................................................16
5.1 TFT LCD Module ..........................................................................................................................................16
5.2 BACKLIGHT UNIT........................................................................................................................................20
5.3 INVERTER UNIT ..........................................................................................................................................20
5.4 BLOCK DIAGRAM OF INTERFACE .............................................................................................................22
5.5 LVDS INTERFACE .......................................................................................................................................23
5.6 COLOR DATA INPUT ASSIGNMENT............................................................................................................24
6.1 INPUT SIGNAL TIMING SPECIFICATIONS..................................................................................................25
6.2 POWER ON/OFF SEQUENCE.....................................................................................................................27
7.1 TEST CONDITIONS.....................................................................................................................................29
7.2 OPTICAL SPECIFICATIONS ........................................................................................................................29
8. DEFINITION OF LABELS......................................................................................................................................33
8.1 CMI MODULE LABEL...................................................................................................................................33
9. PACKING ..............................................................................................................................................................34
9.1 PACKING SPECIFICATIONS TYPE I............................................................................................................34
9.2 PACKING METHOD TYPE I .........................................................................................................................34
s :
d ,/D/ / >
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
9.3 PACKING SPECIFICATIONS TYPE II...........................................................................................................35
9.4 PACKING METHOD TYPE II ........................................................................................................................35
10.1 ASSEMBLY AND HANDLING PRECAUTIONS ...........................................................................................37
10.2 SAFETY PRECAUTIONS ...........................................................................................................................37
10.3 SAFETY STANDARDS ...............................................................................................................................37
11. MECHANICAL CHARACTERISTIC......................................................................................................................38
A.1 PIN ASSIGNMENT.......................................................................................................................................40
A.2 I2C BUS APPLICATION NOTE.....................................................................................................................40
A.3 TWO WIRE BUS DEVICE ADDRESS...........................................................................................................40
A.4 TWO WAY TO CONTROL THE TWO WIRE BUS .........................................................................................42
A.5 TWO WIRE BUS COMMAND TABLE ...........................................................................................................43
A.6 TWO WIRE BUS REQUIREMENT ...............................................................................................................46
A.6 TWO WIRE BUS REQUIREMENT ...............................................................................................................47
A.7 THE TWO WIRE BUS SEQUENCE..............................................................................................................47
A.7 THE TWO WIRE BUS SEQUENCE..............................................................................................................48
s :
d ,/D/ / >
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
REVISION HISTORY
Page
Version Date Section Description
(New)
s :
d ,/D/ / >
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V546H1-LH3 is a 54.6" TFT Liquid Crystal Display module with 22-CCFL Backlight unit and 2ch-LVDS
interface. This module supports 1920 x 1080 HDTV format and can display true 1.073G colors
(8-bit+Hi-FRC/color). The inverter module for backlight is built-in.
1.2 FEATURES
- High brightness (500nits)
- High contrast ratio (4000:1)
- Fast response time (Gray to Gray typical 4.5ms)
- High color saturation (72% NTSC)
- Full HDTV (1920 x 1080 pixels) resolution, true HDTV format
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- Optimized response time for 120 Hz frame rate
- Ultra wide viewing angle: Super MVA technology
1.3 APPLICATION
- Standard Living Room TVs.
- Public Display Application.
- Home Theater Application.
- MFM Application.
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 1209.6(H) x 680.4(V) (54.6" diagonal) mm
(1)
Bezel Opening Area 1217.6 (H) x 688.4 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1920x R.G.B. x 1080 pixel -
Pixel Pitch(Sub Pixel) 0.21(H) x 0.63(V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 1.073G (8-bit+Hi-FRC/color) color -
Display Operation Mode Transmissive mode / Normally black - -
Glare (Super Clear)
Surface Treatment - (2)
Hardness (3H)
Note (1) Please refer to the attached drawings in chapter 9 for more information about the front and
back outlines.
Note (2) The spec of the surface treatment is temporarily for this phase. CMI reserves the rights to
change this feature.
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 1266.1 1267.6 1269.1 mm
Module Size Vertical (V) 737.2 738.4 739.6 mm (1), (2)
Depth (D) 38.5 40 41.5 mm
Weight - 20500 - g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Note (2) Module Depth does not include connectors.
s :
d ,/D/ / >
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
WZKhd ^W/&/ d/KE
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
