Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_V185BG2-LE1_1_[DS]](/pics/5c8ebe9fd6e9b.gif)
>> Download Panel_CHIMEI_INNOLUX_V185BG2-LE1_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
Doc. Number :
Tentative Specification
Preliminary Specification
Approval Specification
MODEL NO.: V185BG2
SUFFIX: LE1
Customer: Common
APPROVED BY SIGNATURE
Name / Title
Note
Please return 1 copy for your confirmation with your signature
and comments.
Approved By Checked By Prepared By
Chao-Chun Chung Roger Huang Kimi Lin
Version 2.0 16.Aug.2011 1 / 27
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
CONTENTS
1. GENERAL DESCRIPTION ...................................................................................................... 5
1.1 OVERVIEW ....................................................................................................................... 5
1.2 GENERAL SPECIFICATIONS ........................................................................................... 5
2. MECHANICAL SPECIFICATIONS .......................................................................................... 5
3. ABSOLUTE MAXIMUM RATINGS .......................................................................................... 6
3.1 ABSOLUTE RATINGS OF ENVIRONMENT...................................................................... 6
3.2 ELECTRICAL ABSOLUTE RATINGS ................................................................................ 7
3.2.1 TFT LCD MODULE .................................................................................................... 7
3.2.2 BACKLIGHT UNIT...................................................................................................... 7
4. ELECTRICAL SPECIFICATIONS............................................................................................ 8
4.1 FUNCTION BLOCK DIAGRAM ......................................................................................... 8
4.2. INTERFACE CONNECTIONS .......................................................................................... 8
4.3 ELECTRICAL CHARACTERISTICS ................................................................................ 10
4.3.1 LCD ELETRONICS SPECIFICATION ...................................................................... 10
4.3.2 VCC POWER DIP CONDITION ............................................................................... 12
4.3.3 BACKLIGHT UNIT.................................................................................................... 12
4.3.4 LIGHTBAR CONNECTOR PIN ASSIGNMENT ........................................................ 13
4.4 LVDS INPUT SIGNAL SPECIFICATIONS ....................................................................... 14
4.4.1 LVDS DATA MAPPING TABLE................................................................................. 14
4.4.2 COLOR DATA INPUT ASSIGNMENT....................................................................... 14
4.5 DISPLAY TIMING SPECIFICATIONS .............................................................................. 15
4.6 POWER ON/OFF SEQUENCE........................................................................................ 17
5. OPTICAL CHARACTERISTICS ............................................................................................ 18
5.1 TEST CONDITIONS ........................................................................................................ 18
5.2 OPTICAL SPECIFICATIONS ........................................................................................... 18
6. PACKING ............................................................................................................................... 21
6.1 PACKING SPECIFICATIONS .......................................................................................... 21
6.2 PACKING METHOD ........................................................................................................ 21
6.3 PALLET............................................................................................................................ 22
7. DEFINITION OF LABELS...................................................................................................... 23
7.1 CMO MODULE LABEL .................................................................................................... 23
8. PRECAUTIONS ..................................................................................................................... 24
8.1 ASSEMBLY AND HANDLING PRECAUTIONS ............................................................... 24
8.2 STORAGE PRECAUTIONS ............................................................................................ 24
8.3 OPERATION PRECAUTIONS ......................................................................................... 24
Version 2.0 16.Aug.2011 2 / 27
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
8.4 SAFETY PRECAUTIONS ................................................................................................ 24
8.5 SAFETY STANDARDS .................................................................................................... 25
8.6 OTHER ............................................................................................................................ 25
Appendix. OUTLINE DRAWING ............................................................................................... 25
Version 2.0 16.Aug.2011 3 / 27
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
REVISION HISTORY
Version Date Page Description
2.0 Aug.16, 2011 All Spec Ver.2.0 was first issued.
Version 2.0 16.Aug.2011 4 / 27
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V185BG2-LE1 is a 18.5" TFT Liquid Crystal Display module with WLED Backlight unit and 30 pins 1ch-LVDS
interface. This module supports 1366 x 768 HD mode and can display up to 16.7M colors. The converter
module for Backlight is not built in.
1.2 GENERAL SPECIFICATIONS
Item Specification Unit Note
Screen Size 18.51" real diagonal - -
Driver Element a-si TFT active matrix - -
Pixel Number 1366 x R.G.B. x 768 pixel -
Pixel Pitch 0.3 (H) x 0.3 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7M color -
Transmissive Mode Normally white - -
Surface Treatment AG type, 3H hard coating, Haze 25% - -
Luminance, White 225 (Typ.) (Target) Cd/m2 -
Color Gamut 72% of NTSC(Typ.) - -
TCO TCO 5.0 compliance - -
Power Consumption Total 8.95W (Typ.) @ cell 2.5 W (Typ.), BL 6.45W (Typ.) (1)
Note (1) The specified power consumption : Total= cell (reference 4.3.1)+BL (reference 4.3.3)
2. MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 429.87 430.37 430.87 mm
Module Size Vertical (V) 254.1 254.6 255.1 mm (1)
Thickness (T) - 10.5 11 mm
Horizontal 412.9 413.4 413.9 mm -
Bezel Area
Vertical 239.5 234 234.5 mm -
Horizontal - 409.8 - mm -
Active Area
Vertical - 230.4 - mm -
Weight - 1600 1800 g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Version 2.0 16.Aug.2011 5 / 27
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
3. ABSOLUTE MAXIMUM RATINGS
3.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
