Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_V315B5-L08_0_[DS]](/pics/5c8ebf8884a35.gif)
>> Download Panel_CHIMEI_INNOLUX_V315B5-L08_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
Tentative Specification
Preliminary Specification
Approval Specification
MODEL NO.: V315B5
SUFFIX:L08
Customer:
APPROVED BY SIGNATURE
Name / Title
Note
Please return 1 copy for your confirmation with your signature
and comments.
Approved By Checked By Prepared By
Chao-Chun Chung Josh Chi Chloe Chen
Version 3.0 1 Date 04 Aug 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2PACKAGE STORAGE
2.3ELECTRICAL ABSOLUTE RATINGS
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 CCFL(Cold Cathode Fluorescent Lamp) CHARACTERISTICS
4. BLOCK DIAGRAM ------------------------------------------------------- 13
4.1 TFT LCD MODULE
5. INTERFACE PIN CONNECTION ------------------------------------------------------- 14
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 INVERTER UNIT
5.4 LVDS INTERFACE
5.5 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 20
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 24
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. DEFINITION OF LABELS ------------------------------------------------------- 29
8.1 CMO MODULE LABEL
9. PACKAGING ------------------------------------------------------- 30
9.1 PACKING SPECIFICATIONS
9.2 PACKING METHOD
10. PRECAUTIONS ------------------------------------------------------- 32
10.1 ASSEMBLY AND HANDLING PRECAUTIONS
10.2 SAFETY PRECAUTIONS
11. MECHANICAL CHARACTERISTICS ------------------------------------------------------- 33
Version 3.0 2 Date 04 Aug 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 3.0 Aug 04, 10' All All Approval Specification was first issued.
Version 3.0 3 Date 04 Aug 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V315B5- L08 s a 31.5" TFT Liquid Crystal Display module with 4U-type CCFL Backlight unit and 1ch-LVDS
interface. This module supports 1366 x 768 WXGA format and can display 16.7M (8-bit/color)colors. The
inverter module for backlight is built-in.
1.2 FEATURES
- High brightness (450 nits)
- Ultra-high contrast ratio (3500:1)
- Fast response time (gray to gray average 8.5ms)
- High color saturation NTSC 72%
- Ultra wide viewing angle : 176(H)/176(V)(CR20)with Super MVA technology
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- Color reproduction (nature color)
- Low color shift function
1.3 APPLICATION
- TFT LCD TVs
- Multi-Media Display
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 697.6845 (H) x 392.256 (V) (31.51" diagonal) mm
(1)
Bezel Opening Area 703.8 (H) x 399.0 (V) mm
Driver Element a-si TFT active matrix -
Pixel Number 1366 x R.G.B. x 768 pixel
Pixel Pitch (Sub Pixel) 0.17025(H) x 0.51075 (V) mm
Pixel Arrangement RGB vertical stripe -
Display Colors 16.7M color
Display Operation Mode Transmissive mode / Normally black -
Surface Treatment Anti-Glare coating (Haze 11%),Hard coating (3H) -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 759 760 761 mm (1)
Vertical(V) 449 450 451 mm (1)
Module Size
Depth(D) 31.5 32.5 33.5 mm To Rear
Depth(D) 46.9 47.9 48.9 mm To Inverter Cover
Weight 5189 g
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Version 3.0 4 Date 04 Aug 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
