Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_V315H3-P01_1_[DS]](/pics/5c8ec05ce5ce4.gif)
>> Download Panel_CHIMEI_INNOLUX_V315H3-P01_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Feb. 22, 2010
Model No.: V315H3-P01
Tentative
TFT LCD Tentative Specification
MODEL NO.:V315H3-P01
Customer:
Approved by:
Note:
TV Product Marketing & Management Div
Approved By
Chao-Chun Chung
QRA Dept. Product Development Div.
Reviewed By
Hsin-Nan Chen WT Lin
LCD TV Marketing and Product Management Div.
Prepared By
Josh Chi Chris Chu
1
Version0.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Feb. 22, 2010
Model No.: V315H3-P01
Tentative
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 CHARACTERISTICS
1.3 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT (BASED ON CMO MODULE V315B1-L01)
2.2 ABSOLUTE RATINGS OF ENVIRONMENT (OPEN CELL)
2.3 ELECTRICAL ABSOLUTE RATINGS (OPEN CELL)
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD OPEN CELL
4. BLOCK DIAGRAM ------------------------------------------------------- 10
4.1 TFT LCD OPEN CELL
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 11
5.1 TFT LCD MODULE
5.2 LVDS INTERFACE
5.3 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 15
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 19
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PRECAUTIONS ------------------------------------------------------- 23
8.1 ASSEMBLY AND HANDLING PRECAUTIONS
8.2 SAFETY PRECAUTIONS
9. MECHANICAL DRAWING ------------------------------------------------------- 24
2
Version0.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Feb. 22, 2010
Model No.: V315H3-P01
Tentative
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 0.0 22, Feb, 10' All All Tentative Specification was first issued.
3
Version0.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Feb. 22, 2010
Model No.: V315H3-P01
Tentative
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V315H3-P01 is a 31.5" TFT Liquid Crystal Display module. This module supports 1920* 1080 HDTV format and
can display 16.7M colors (8 bit/color).
1.2 CHARACTERISTICS
CHARACTERISTICS ITEMS SPECIFICATIONS
Screen Diagonal [in] 31.51
Pixels [lines] 1920*1080
Active Area [mm] 698.4 (H) x 392.85 (V) (31.51" diagonal)
Sub -Pixel Pitch [mm] 0.12125 (H) x 0.36375 (V)
Pixel Arrangement RGB vertical stripe
Weight [g] TBD
Physical Size [mm] 716.1(W) x 410(H) x 1.79(D) Typ.
Display Mode Transmissive mode / Normally black
Contrast Ratio 6000:1 Typ.
(Typical value measured at CMO's module)
Glass thickness (Array/CF) [mm] 0.7 / 0.7
Viewing Angle (CR>20) +88/-88(H),+88/-88(V) Typ.
(Typical value measured at CMO's module)
Color Chromaticity R=(0.639, 0.327)
G=(0.288, 0.603)
B=(0.148, 0.048)
W=(0.280, 0.290)
(Typical value measured at CMO's module)
Cell Transparency [ ] 4.7%Typ.
(Typical value measured at CMO's module)
Polarizer (CF side) Glare coating,Hard coating (3H) 709.7(H) x 405(w)..
Polarizer (TFT side) Super Wide View, 709.7(H) x 405(w)..
1.3 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Weight - TBD - g -
I/F connector mounting The mounting inclination of the connector makes
(2)
