Image preview - the first page of the document

>> Download Panel_CHIMEI_INNOLUX_V315H3-PE5_0_[DS] documenatation <<

Text preview - extract from the document

Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION

Tentative Specification
Preliminary Specification
Approval Specification

MODEL NO.: V315H3
SUFFIX: PE5
Customer: Foxconn for Sony Project
CONFIRMED BY SIGNATURE

Name / Title
APPROVED BY SIGNATURE

Name / Title
Note

Please return 1 copy for your confirmation with your
signature and comments.

Approved By Checked By Prepared By

Chao-Chun Chung Vincent Chou Wayne Lin

Version 2.0 1 Date 15 Jan. 2011
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION
CONTENTS

REVISION HISTORY......................................................................................................................................................... 4

1. GENERAL DESCRIPTION............................................................................................................................................ 5
1.1 OVERVIEW .......................................................................................................................................................... 5
1.2 FEATURES .......................................................................................................................................................... 5
1.3 MECHANICAL SPECIFICATIONS ....................................................................................................................... 5

2. ABSOLUTE MAXIMUM RATINGS ................................................................................................................................ 6
2.1 ABSOLUTE RATINGS OF ENVIRONMENT........................................................................................................ 6
2.2 ABSOLUTE RATINGS OF ENVIRONMENT (OPEN CELL) ................................................................................ 6
2.3 ELECTRICAL ABSOLUTE RATINGS .................................................................................................................. 7

3. ELECTRICAL CHARACTERISTICS ............................................................................................................................. 8
3.1 TFT OPEN CELL.................................................................................................................................................. 8
3.2 CIRCUIT AND WIRING DIAGRAM OF SPWB .................................................................................................... 9
3.3 SPWB INFORMATION......................................................................................................................................... 9

4. INPUT TERMINAL PIN ASSIGNMENT ....................................................................................................................... 10
4.1 TFT LCD OPEN CELL INPUT............................................................................................................................ 10
4.2 FLICKER (Vcom) ADJUSTMENT ...................................................................................................................... 13

5. INTERFACE TIMING ................................................................................................................................................... 14
5.1 INPUT SIGNAL TIMING SPECIFICATIONS ...................................................................................................... 14

6. OPTICAL CHARACTERISTICS .................................................................................................................................. 18
6.1 TEST CONDITIONS........................................................................................................................................... 18
6.2 OPTICAL SPECIFICATIONS ............................................................................................................................. 19

7. RELIABILITY TEST CONDITION................................................................................................................................ 22

8. PRECAUTIONS........................................................................................................................................................... 23
8.1 ASSEMBLY AND HANDLING PRECAUTIONS ................................................................................................. 23
8.2 SAFETY PRECAUTIONS .................................................................................................................................. 24

9. DEFINITION OF LABELS............................................................................................................................................ 25
9.1 OPEN CELL LABEL ........................................................................................................................................... 25
9.2 CARTON LABEL ................................................................................................................................................ 27

Version 2.0 2 Date 15 Jan. 2011
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION
10. PACKAGING.............................................................................................................................................................. 28
10.1 PACKAGING SPECIFICATIONS ..................................................................................................................... 28
10.2 PACKAGING METHOD.................................................................................................................................... 28

11. MECHANICAL CHARACTERISTIC........................................................................................................................... 30

Version 2.0 3 Date 15 Jan. 2011
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION
REVISION HISTORY
Version Date Page(New) Section Description
Ver. 1.0 Sep. 01, 2010 All All The preliminary specification was first issued.
Ver. 2.0 Jan. 15, 2011 All All The approval specification was first issued.

Version 2.0 4 Date 15 Jan. 2011
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V315H3-PE5 is a 31.5" TFT Liquid Crystal Display product with driver ICs and 2ch-LVDS interface. This product
supports 1920 x 1080 Full HDTV format and can display 1G colors (10bit/FRC). The backlight unit is not built in.

1.2 FEATURES
CHARACTERISTICS ITEMS SPECIFICATIONS
Screen Diagonal [in] 31.5
Pixels [lines] 1920 1080
Active Area [mm] 698.4(H) 392.85(V)
Sub-Pixel Pitch [mm] 0.12125(H) 0.36375(V)
Pixel Arrangement RGB vertical stripe
Weight [g] TYP. 1150g
Physical Size [mm] 727.68(W) 434.3(H) 1.8(D) Typ.
Display Mode Transmissive mode / Normallly black
Contrast Ratio 5000:1 Typ.
(Typical value measure at CMI's module)
Glass thickness (Array / CF) [mm] 0.7 / 0.7
Viewing Angle (CR>20) +88/-88(H), +88/-88(V) Typ. (CR 20)
(Typical value measure at CMI's module)
Color Chromaticity R = (0.644, 0.323)
G = (0.252, 0.580)
B = (0.134, 0.103)
W= (0.281, 0.327)
* Please refer to "color chromaticity" on p.18
Cell Transparency [%]
Polarizer Surface Treatment Anti-Glare coating (Haze 11%),
Hard coating :(3H) (CF Side),(6B) (TFT Side)
Polarizer Maker & Mark Sumika

1.3 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Weight 1100 1150 - g -
The mounting inclination of the connector makes the
I/F connector mounting position (2)
screen center within 0.5mm as the horizontal.
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Note (2) Connector mounting position

+/- 0.5mm

Version 2.0 5 Date 15 Jan. 2011
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

PRODUCT SPECIFICATION
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
(1)
Storage Temperature TST -20 +60
