Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_V315H4-PE2_0_[DS]](/pics/5c8ec086256c3.gif)
>> Download Panel_CHIMEI_INNOLUX_V315H4-PE2_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
Tentative Specification
Preliminary Specification
Approval Specification
MODEL NO.: V315H4
SUFFIX: PE2
Customer:
APPROVED BY SIGNATURE
Name / Title
Note
Please return 1 copy for your confirmation with your
signature and comments.
Approved By Checked By Prepared By
Chao-Chun Chung Roger Huang Hsin-Cheng Hung
Version 2.0 1 Date 9 Sep 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
CONTENTS
REVISION HISTORY.........................................................................................................................................................4
1. GENERAL DESCRIPTION............................................................................................................................................5
1.1 OVERVIEW ..........................................................................................................................................................5
1.2 FEATURES...........................................................................................................................................................5
1.3 MECHANICAL SPECIFICATIONS .......................................................................................................................5
2. ABSOLUTE MAXIMUM RATINGS ................................................................................................................................6
2.1 ABSOLUTE RATINGS OF ENVIRONMENT (BASED ON CMI MODULE V315H4-LE2)....................................6
2.2 ABSOLUTE RATINGS OF ENVIRONMENT (OPEN CELL) ................................................................................7
2.3 ELECTRICAL ABSOLUTE RATINGS (OPEN CELL)...........................................................................................7
3. ELECTRICAL CHARACTERISTICS .............................................................................................................................8
3.1 TFT LCD MODULE ..............................................................................................................................................8
4. BLOCK DIAGRAM OF INTERFACE ........................................................................................................................... 11
4.1 TFT LCD MODULE ............................................................................................................................................ 11
5. INPUT TERMINAL PIN ASSIGNMENT .......................................................................................................................12
5.1 TFT LCD MODULE INPUT ................................................................................................................................12
5.2 BLOCK DIAGRAM OF INTERFACE ..................................................................................................................15
5.3 LVDS INTERFACE .............................................................................................................................................17
5.4 COLOR DATA INPUT ASSIGNMENT ................................................................................................................18
5.5 FLICKER (Vcom) ADJUSTMENT ......................................................................................................................19
6. INTERFACE TIMING...................................................................................................................................................19
6.1 INPUT SIGNAL TIMING SPECIFICATIONS ......................................................................................................20
6.2 POWER ON/OFF SEQUENCE..........................................................................................................................23
7. OPTICAL CHARACTERISTICS ..................................................................................................................................24
7.1 TEST CONDITIONS...........................................................................................................................................24
7.2 OPTICAL SPECIFICATIONS .............................................................................................................................25
8. PRECAUTIONS...........................................................................................................................................................28
8.1 ASSEMBLY AND HANDLING PRECAUTIONS .................................................................................................28
8.2 SAFETY PRECAUTIONS ..................................................................................................................................29
Version 2.0 2 Date 9 Sep 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
9. DEFINITION OF LABELS............................................................................................................................................30
9.1 CMI MODULE LABEL ........................................................................................................................................30
10. PACKAGING..............................................................................................................................................................31
11. MECHANICAL CHARACTERISTIC...........................................................................................................................33
Version 2.0 3 Date 9 Sep 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
REVISION HISTORY
Version Date Page(New) Section Description
Ver. 2.0 Sep 9, 2010 All All The approval specification was first issued.
Version 2.0 4 Date 9 Sep 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V315H4-PE2 is a 31.5" TFT Liquid Crystal Display product with driver ICs and 2ch-LVDS interface. This product
supports 1920 x 1080 Full HDTV format and can display 16.7M colors (8-bit/color). The backlight unit is not built
in.
1.2 FEATURES
CHARACTERISTICS ITEMS SPECIFICATIONS
Screen Diagonal [in] 31.5
Pixels [lines] 1920 1080
Active Area [mm] 697.92 (H) X 392.58 (V) (31.5" diagonal)
Sub-Pixel Pitch [mm] 0.18175 (H) x 0.18175 (V)
Pixel Arrangement Square
Weight [g] TYP. 1150g
Physical Size [mm] 716.1(W) 410 (H) 1.79(D) Typ.
Display Mode Transmissive mode / Normallly black
Contrast Ratio 4000:1 Typ.
(Typical value measure at CMI's module)
Glass thickness (Array / CF) [mm] 0.7 / 0.7
Viewing Angle (CR>20) +88/-88(H), +88/-88(V) Typ. (CR 20)
(Typical value measure at CMI's module)
Color Chromaticity R = (0.655, 0.325)
G = (0.293, 0.601)
B = (0.133, 0.108)
W= (0.311, 0.347)
* Please refer to "color chromaticity" on p.23
Cell Transparency [%] 7.5 %
Polarizer Surface Treatment Anti-Glare coating (Haze 14%), Hard coating (3H)
1.3 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Weight 1100 1150 1200 g -
The mounting inclination of the connector makes the
I/F connector mounting position (1)
screen center within 0.5mm as the horizontal.
Note (1) Connector mounting position
+/- 0.5mm
Version 2.0 5 Date 9 Sep 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT (BASED ON CMI MODULE V315H4-LE2)
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
