Image preview - the first page of the document
![Panel_CHIMEI_INNOLUX_V315HK2-PE1_0_[DS]](/pics/5c8ec09a8cf04.gif)
>> Download Panel_CHIMEI_INNOLUX_V315HK2-PE1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
Tentative Specification
Preliminary Specification
Approval Specification
MODEL NO.: V315HK2
SUFFIX: PE1
Customer:
APPROVED BY SIGNATURE
Name / Title
Note
Please return 1 copy for your confirmation with your
signature and comments.
Approved By Checked By Prepared By
Chao-Chun Chung Josh Chi Edouard Huang
Version 2.0 1 Date 7 Dec 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
CONTENTS
REVISION HISTORY.........................................................................................................................................................4
1. GENERAL DESCRIPTION............................................................................................................................................5
1.1 OVERVIEW ..........................................................................................................................................................5
1.2 FEATURES...........................................................................................................................................................5
1.3 MECHANICAL SPECIFICATIONS .......................................................................................................................5
2. ABSOLUTE MAXIMUM RATINGS ................................................................................................................................6
2.1 ABSOLUTE RATINGS OF ENVIRONMENT........................................................................................................6
2.2 PACKAGE STORAGE..........................................................................................................................................7
2.3 ELECTRICAL ABSOLUTE RATINGS ..................................................................................................................7
2.3.1 TFT LCD MODULE ....................................................................................................................................7
3. ELECTRICAL CHARACTERISTICS .............................................................................................................................8
3.1 TFT LCD MODULE ..............................................................................................................................................8
4. BLOCK DIAGRAM OF INTERFACE ........................................................................................................................... 11
4.1 TFT LCD MODULE ............................................................................................................................................ 11
5. INPUT TERMINAL PIN ASSIGNMENT .......................................................................................................................12
5.1 TFT LCD MODULE INPUT ................................................................................................................................12
5.2 LVDS INTERFACE .............................................................................................................................................16
5.3 COLOR DATA INPUT ASSIGNMENT ................................................................................................................17
5.5 FLICKER (Vcom) ADJUSTMENT ......................................................................................................................19
6. INTERFACE TIMING...................................................................................................................................................21
6.1 INPUT SIGNAL TIMING SPECIFICATIONS ......................................................................................................21
6.2 POWER ON/OFF SEQUENCE..........................................................................................................................24
7. OPTICAL CHARACTERISTICS ..................................................................................................................................25
7.1 TEST CONDITIONS...........................................................................................................................................25
7.2 OPTICAL SPECIFICATIONS .............................................................................................................................26
8. PRECAUTIONS...........................................................................................................................................................29
8.1 ASSEMBLY AND HANDLING PRECAUTIONS .................................................................................................29
8.2 SAFETY PRECAUTIONS ..................................................................................................................................30
Version 2.0 2 Date 7 Dec 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
9. DEFINITION OF LABELS............................................................................................................................................31
9.1 OPEN CELL LABEL ........................................................................................................................................31
10. PACKAGING..............................................................................................................................................................32
10.1 PACKAGING SPECIFICATIONS .....................................................................................................................32
10.2 PACKAGING METHOD....................................................................................................................................32
11. MECHANICAL CHARACTERISTIC...........................................................................................................................34
Version 2.0 3 Date 7 Dec 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
REVISION HISTORY
Version Date Page(New) Section Description
Ver. 2.0 Dec. 7, 2010 All All The Approval specification was first issued.
Version 2.0 4 Date 7 Dec 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V315HK2-PE1 is a 31.5" TFT Liquid Crystal Display product with driver ICs and 4ch-LVDS interface. This product
supports 1920 x 1080 Full HDTV format and can display 1.07G (8-bit+Hi-FRC)colors. The backlight unit is not built
in.
1.2 FEATURES
CHARACTERISTICS ITEMS SPECIFICATIONS
Screen Diagonal [in] 31.51
Pixels [lines] 1920 x 1080
Active Area [mm] 698.4 (H) x 392.85 (V) (31.51" diagonal)
Sub-Pixel Pitch [mm] 0.12125 (H) x 0.36375 (V)
Pixel Arrangement RGB vertical stripe
Weight [g] 1175
Physical Size [mm] 716.1(H)X410.0 (V) 1.8(D) Typ.
Display Mode Transmissive mode / Normallly black
Contrast Ratio 6000:1 Typ.
(Typical value measure at CMI's module)
Glass thickness (Array / CF) [mm] 0.7 / 0.7
Viewing Angle (CR>20) +88/-88(H), +88/-88(V) Typ. (CR 20)
(Typical value measure at CMI's module)
Color Chromaticity R = (0.654, 0.325)
G = (0.266, 0.591)
B = (0.131, 0.115)
W= (0.301, 0.357)
Standard light source "C"
Cell Transparency [%] 4.5%Typ..
(Typical value measured at CMO's module)
Polarizer Surface Treatment Super clear coating, Hard coating (3H)
1.3 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Weight 1175 g -
The mounting inclination of the connector makes the
I/F connector mounting position (2)
screen center within 0.5mm as the horizontal.
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Note (2) Connector mounting position
Version 2.0 5 Date 7 Dec 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
