Image preview - the first page of the document
![Panel_CMO_G133I1-L01_0_[DS]](/pics/5c8ec53c6deec.gif)
>> Download Panel_CMO_G133I1-L01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jul. 18, 2006
Model No.: G133I1 - L01
Preliminary
TFT LCD Preliminary Specification
MODEL NO.: G133I1 - L01
Customer:
Approved by:
Note:
2006-07-28 Approve by tomy_chen( Assignee Accept
20:40:52 Dept. /52720/54140/43150)
CST Mgr.(QA
RA)
2006-07-18 Approve by kf_huang( Director Accept
21:14:03 Director /56620/54380/14906/25075)
CST
1 / 27
Version 1.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jul. 18, 2006
Model No.: G133I1 - L01
Preliminary
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 11
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 12
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.4 COLOR DATA INPUT ASSIGNMENT
5.5 EDID DATA STRUCTURE
6. INTERFACE TIMING ------------------------------------------------------- 16
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 18
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PRECAUTIONS ------------------------------------------------------- 22
8.1 HANDLING PRECAUTIONS
8.2 STORAGE PRECAUTIONS
8.3 OPERATION PRECAUTIONS
9. PACKING ------------------------------------------------------- 23
9.1 CARTON
9.2 PALLET
10. DEFINITION OF LABELS ------------------------------------------------------- 25
10.1 CMO MODULE LABEL
10.2 CMO CARTON LABE
10.3 CUSTOMER CARTON LABEL
10.4 CUSTOMER PALLET LABEL
2 / 27
Version 1.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jul. 18, 2006
Model No.: G133I1 - L01
Preliminary
REVISION HISTORY
Page
Version Date Section Description
(New)
1.0 07, 18,'06 All All Preliminary specification was first issued.
3 / 27
Version 1.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jul. 18, 2006
Model No.: G133I1 - L01
Preliminary
1. GENERAL DESCRIPTION
1.1 OVERVIEW
G133I1 - L01 is a 13.3" TFT Liquid Crystal Display Rohs module and 20 pins LVDS interface. This module
supports 1280 x 800 WXGA mode and can display 262,144 colors. The optimum viewing angle is at 6
o'clock direction. The inverter module for Backlight is not built in.
1.2 FEATURES
- WXGA (1280 x 800 pixels) resolution
- DE only mode
- 3.3V LVDS (Low Voltage Differential Signaling) interface with 1 pixel/clock
- RoHs compliance
1.3 APPLICATION
- TFT LCD Panel
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 286.08 (H) x 178.8 (V) mm
(1)
Bezel Opening Area 289.1 (H) x 181.8 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1280 x R.G.B. x 800 pixel -
Pixel Pitch 0.2235 (H) x 0.2235 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 262,144 color -
Transmissive Mode Normally white - -
Surface Treatment AG , 25%Haze - -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 304.4 304.6 304.8 mm
Module Size Vertical(V) 194.5 195 195.5 mm (1)
Depth(D) - 7.7 8.0 mm
Weight - 450 465 g -
I/F connector mounting position The mounting inclination of the connector makes the screen (2)
