Image preview - the first page of the document
![Panel_CMO_M190A1-L06_1_[DS]](/pics/5c8ec756f3b92.gif)
>> Download Panel_CMO_M190A1-L06_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Aug., 31, 2007
Model No.: M190A1-L06
Approval
TFT LCD Approval Specification
MODEL NO.: M190A1-L06
Customer: AOC
Approved by:
Note:
2007-09-04 PMMD cs_lee(
Director Accept
12:11:16 CST Director /56510/44926)
1 / 25
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Aug., 31, 2007
Model No.: M190A1-L06
Approval
- CONTENTS -
1. GENERAL DESCRIPTION
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT
5. INPUT TERMINAL PIN ASSIGNMENT
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PACKAGING
8.1 PACKING SPECIFICATIONS
8.2 PACKING METHOD
9. DEFINITION OF LABELS
10. PRECAUTIONS
10.1 ASSEMBLY AND HANDLING PRECAUTIONS
10.2 SAFETY PRECAUTIONS
11. MECHANICAL CHARACTERISTICS
2 / 25
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Aug., 31, 2007
Model No.: M190A1-L06
Approval
REVISION HISTORY
Date Section Description
3.0 Aug., 31, 07' All M190A1-L06 Specifications was first issued.
3 / 25
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Aug., 31, 2007
Model No.: M190A1-L06
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
M190A1-L06 is a 19" wide TFT Liquid Crystal Display module with 4 CCFL Backlight unit and 30 pins
2ch-LVDS interface. This module supports 1440 x 900 WXGA+ mode and can display 16.7M colors. The
inverter module for Backlight is not built in.
1.2 FEATURES
- Super Wide viewing angle.
- Super High contrast ratio
- Super fast response time
- High color saturation
- WXGA+ (1440 x 900 pixels) resolution
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- RoHS Compliance
1.3 APPLICATION
- TFT LCD Monitor
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Diagonal Size 481.4 (19.05" diagonal) mm
Active Area 410.4 (H) x 256.5 (V) mm
(1)
Bezel Opening Area 414.36 x 260.45 mm
Driver Element a-si TFT active matrix - -
Pixel Number 1440 x R.G.B. x 900 pixel -
Pixel Pitch 0.285 (H) x 0.285 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7M color -
Transmissive Mode Normally White - -
Color saturation 72%NTSC (typ.) - -
Surface Treatment Hard coating (3H), Anti-glare (Haze 25) - -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 426.7 427.2 427.7 mm
Module Size Vertical(V) 276.9 277.4 277.9 mm (1)
Depth(D) - 16.0 16.5 mm
Weight - 1750 1800 g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
4 / 25
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Aug., 31, 2007
Model No.: M190A1-L06
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
