Image preview - the first page of the document
![Panel_CMO_M190Z3-L02_0_[DS]](/pics/5c8ec86bb8650.gif)
>> Download Panel_CMO_M190Z3-L02_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Jul. 21, 2008
Model No.: M190Z3-L02
Preliminary
TFT LCD Preliminary Specification
MODEL NO.: M190Z3-L02
Customer:
Approved by:
Note: For reference only.
Liquid Crystal Display Division
QRA Division. OA Head Division.
Approval Approval
1 / 25
Version 1.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Jul. 21, 2008
Model No.: M190Z3-L02
Preliminary
- CONTENTS -
1. GENERAL DESCRIPTION
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS
3.1 TFT LCD MODULE
3.2 Vcc POWER DIP CONDITION
3.3 BACKLIGHT UNIT
4. BLOCK DIAGRAM
4.1 TFT LCD MODULE
5. INPUT TERMINAL PIN ASSIGNMENT
5.1 TFT LCD MODULE
5.2 LVDS DATA MAPPING TABLE
5.3 CONVERTER SPECIFICATION
5.3.1 Connector type
5.3.2 Input connector pin assignment
5.4 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PACKAGING
8.1 PACKING SPECIFICATIONS
8.2 PACKING METHOD
9. DEFINITION OF LABELS
10. PRECAUTIONS
10.1 ASSEMBLY AND HANDLING PRECAUTIONS
10.2 SAFETY PRECAUTIONS
11. MECHANICAL CHARACTERISTICS
2 / 25
Version 1.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Jul. 21, 2008
Model No.: M190Z3-L02
Preliminary
Date Section Description
1.0 Jul. 21, 08' All M190Z3-L02 Specifications was first issued.
3 / 25
Version 1.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Jul. 21, 2008
Model No.: M190Z3-L02
Preliminary
1. GENERAL DESCRIPTION
1.1 OVERVIEW
M190Z3-L02 is a 19" wide TFT Liquid Crystal Display module with white LED Backlight unit and 30 pins
2ch-LVDS interface. This module supports 1680 x 1050 WSXGA+ mode and can display 16.7M colors. The
inverter module for Backlight is not built in.
1.2 FEATURES
- Super Wide viewing angle.
- Super High contrast ratio
- Super fast response time
- High color saturation
- WSXGA+ (1680 x 1050 pixels) resolution
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- RoHS Compliance
1.3 APPLICATION
- TFT LCD Monitor
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Diagonal Size 481.4 (18.95" diagonal) mm
Active Area 408.24 (H) x 255.15 (V) mm
(1)
Bezel Opening Area 412.24 (H) x 259.15 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1680 x R.G.B. x 1050 pixel -
Pixel Pitch 0.243 (H) x 0.243 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7M color -
Transmissive Mode Normally White - -
Color saturation 68%NTSC (typ.) - -
Surface Treatment Glare - -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 427.5 428 428.5 mm
Module Size Vertical(V) 277.5 278 278.5 mm (1)
Depth(D) - 12.84 mm
Weight - 1425 g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
4 / 25
Version 1.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Jul. 21, 2008
Model No.: M190Z3-L02
Preliminary
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
