Image preview - the first page of the document
![Panel_CMO_M220Z1-L10_2_[DS]](/pics/5c8ec9a3f2be6.gif)
>> Download Panel_CMO_M220Z1-L10_2_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan.08, 2010
Model No.: M220Z1-L10
Approval
TFT LCD Approval Specification
MODEL NO.: M220Z1-L10
Customer : Innolux(HP)
Approved by :
Note :
MTR
2010-01-18
2010.01.18 Director Accept
10:39:44
1 / 29
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan.08, 2010
Model No.: M220Z1-L10
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 Vcc POWER DIP CONDITION
3.3 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 12
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 13
5.1 TFT LCD MODULE
5.2 LVDS DATA MAPPING TABLE
5.3 BACKLIGHT UNIT
5.4 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 16
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 19
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PACKAGING ------------------------------------------------------- 22
8.1 PACKING SPECIFICATIONS
8.2 PACKING METHOD
9. DEFINITION OF LABELS ------------------------------------------------------- 24
9.1 CMO MODULE LABEL
10. RELIABILITY TEST ------------------------------------------------------- 25
11. PRECAUSIONS ------------------------------------------------------- 26
11.1 ASSEMBLY AND HANDLING PRECAUTIONS
11.2 SAFETY PRECAUTIONS
11.3 SAFETY STANDARDS
11.4 STORAGE
11.5 OPERATION CONDITION GUIDE
11.6 OTHERS
12. MECHANICAL CHARACTERISTICS ------------------------------------------------------- 27
2 / 29
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan.08, 2010
Model No.: M220Z1-L10
Approval
REVISION HISTORY
Version Date Section Description
Ver 3.0 Jan,08 `10 All M220Z1-L10 Specifications was first issued
3 / 29
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan.08, 2010
Model No.: M220Z1-L10
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
The M220Z1-L10 model is a 22 inch wide TFT-LCD module with a 2-CCFL Backlight Unit and a 30-pin
2ch-LVDS interface. This module supports 1680 x 1050 WSXGA+ (16:10 wide screen) mode and displays
up to 16.7 millions colors. The inverter module for the Backlight Unit is not built in.
1.2 FEATURES
- Super wide viewing angle
- High contrast ratio
- Fast response time
- High color saturation (EBU Like Specifications)
- WSXGA+ (1680 x 1050 pixels) resolution
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- Lower power consumption
- Halogen Free
1.3 APPLICATION
- Workstation & desktop monitor
- Display terminals for AV application
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Diagonal size 558.68 mm -
Active Area 473.76x296.1 mm
(1)
Bezel Opening Area 477.7 (H) x 300.1 (V) mm
Driver Element a-Si TFT active matrix - -
Pixel Number 1680 x R.G.B. x 1050 pixel -
Pixel Pitch 0.282(H) x 0.282(V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7 millions color -
Transmissive Mode Normally White - -
Surface Treatment Hard coating (3H), AG (Haze 25%) - -
Module Power Consumption 17.71 Watt (2)
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 493.2 493.7 494.2 mm
Module Size Vertical(V) 319.6 320.1 320.6 mm (1)
Depth(D) 16 16.5 17 mm
Weight - 2530 2580 g -
I/F connector mounting The mounting inclination of the connector makes
- -
