Image preview - the first page of the document
![Panel_CMO_M220Z1-PS1_0_[DS]](/pics/5c8ec9bba6545.gif)
>> Download Panel_CMO_M220Z1-PS1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 14076425
Issued Date: Sep. 06, 2007
Model No.: M220Z1-PS1
Approval
TFT LCD Approval Specification
Model No : M220Z1-PS1
Customer :
Approved by :
Note :
2007-09-19 PMMD cs_lee(
Director Accept
13:50:03 CST Director /56510/44926)
1 / 28
Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 14076425
Issued Date: Sep. 06, 2007
Model No.: M220Z1-PS1
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ABSOLUTE RATINGS OF ENVIRONMENT
2.3 ELECTRICAL ABSOLUTE RATINGS
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
4. BLOCK DIAGRAM ------------------------------------------------------- 8
4.1 TFT LCD MODULE
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 9
5.1 TFT LCD MODULE
5.2 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.3 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 12
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. DRIVER DC CHARACTERISTICS ------------------------------------------------------- 14
7.1 RSDS CHARACTERISTICS
7.2 ELECTRICAL CHARACTERISTICS (VSSD=VSSA=0V)
8. DRIVER AC CHARACTERISTICS ------------------------------------------------------- 16
9. VERTICAL TIMING ------------------------------------------------------- 17
10. OPTICAL CHARACTERISTICS ------------------------------------------------------- 18
10.1 TEST CONDITIONS
10.2 OPTICAL SPECIFICATIONS
10.3 FLICKER ADJUSTMENT
11. PACKAGING ------------------------------------------------------- 23
11.1 PACKING SPECIFICATIONS
11.2 PACKING METHOD
12. DEFINITION OF LABELS ------------------------------------------------------- 25
12.1 OPEN CELL LABEL
12.2 CARTON LABEL
13. PRECAUTIONS ------------------------------------------------------- 27
13.1 ASSEMBLY AND HANDLING PRECAUTIONS
13.2 SAFETY PRECAUTIONS
14. PANEL DRAWING ------------------------------------------------------- 28
2 / 28
Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 14076425
Issued Date: Sep. 06, 2007
Model No.: M220Z1-PS1
Approval
REVISION HISTORY
Version Date Section Description
Ver. 1.0 Apr., 26 '07 - M220Z1- PS1 Preliminary Specifications was first issued.
Ver. 2.0 Jun, 13 `07 - M220Z1- PS1 Approval Specifications was first issued.
11.2 Modified Packing Method.
12.1 Modified CMO OPEN CELL LABEL.
Ver. 2.1 Sep, 06 `07 11.2 Modified Packing Method.
3 / 28
Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 14076425
Issued Date: Sep. 06, 2007
Model No.: M220Z1-PS1
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
The M220Z1-PS1 is a 22-inch wide TFT LCD cell with driver ICs and a RSDS circuit board. The product
supports 1680 x 1050 WSXGA+ mode. The backlight unit is not built in.
1.2 FEATURES
Super wide viewing angle
High contrast ratio
Fast response time
High color saturation
WSXGA+ (1680 x 1050 pixels) resolution
RSDS (Reduced Swing Differential Signaling) Interface
RoHS Compliance
1.3 APPLICATION
TFT LCD Monitor
TFT LCD TV
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Diagonal Size 22 inch
Active Area 473.76 (H) x 296.10 (V) mm (1)
Driver Element a-si TFT active matrix - -
Pixel Number 1680 x R.G.B. x 1050 pixel -
Pixel Pitch 0.282 (H) x 0.282 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Transmissive Mode Normally white - -
Surface Treatment Hard coating (3H), Anti-glare (Haze 25%)
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Weight - 619 - g -
I/F connector mounting The mounting inclination of the connector makes
(2)
