Image preview - the first page of the document
![Panel_CMO_M220Z2-L02_0_[DS]](/pics/5c8ec9bec6cca.gif)
>> Download Panel_CMO_M220Z2-L02_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc No.:
Issued Date: Apr. 30, 2008
Model No.: M220Z2-L02
Tentative
TFT LCD Tentative Specifications
Model No. : M220Z2-L02
Customer :
Approved by :
Note :
System cy_kung(
2008-06-05
Products /52860/ Director Accept
10:06:08 CST
Biz Div. 54060)
1 / 22
Version 0.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.:
Issued Date: Apr. 30, 2008
Model No.: M220Z2-L02
Tentative
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.1.1 Vcc Power Dip Condition
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 10
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 11
5.1 TFT LCD MODULE
5.2 LVDS DATA MAPPING TABLE
5.3 BACKLIGHT UNIT
5.4 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 14
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 16
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. DEFINITION OF LABELS ------------------------------------------------------- 19
8.1 CMO MODULE LABEL
9. PRECAUTIONS ------------------------------------------------------- 20
9.1 ASSEMBLY AND HANDLING PRECAUTIONS
9.2 SAFETY PRECAUTIONS
2 / 22
Version 0.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.:
Issued Date: Apr. 30, 2008
Model No.: M220Z2-L02
Tentative
REVISION HISTORY
Version Date Section Description
Ver. 0.0 Apr,07 `08 All M220Z2-L02 RGB BLU Module Tentative Specifications was first issued.
3 / 22
Version 0.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.:
Issued Date: Apr. 30, 2008
Model No.: M220Z2-L02
Tentative
1. GENERAL DESCRIPTION
1.1 OVERVIEW
The M220Z2-L02 model is a 22 inch wide TFT-LCD module with 4pcs LED light-bar Backlight unit and
LVDS interface. This module supports 1680 x 1050 WSXGA+ mode and displays up to 16.7 millions colors.
The inverter module for the Backlight Unit is not built in.
1.2 FEATURES
z 22" wide WSXGA+ TFT LCD Panel
z TN Mode Liquid Crystal
z Super Wide Viewing Angle
z High Color saturation
z High Brightness & Contrast Ratio
z High Brightness & Contrast Angular Dependent
z Fast LC Response Time
z Light Weight
1.3 APPLICATION
- Workstation & desktop monitor
- Display terminals for AV application
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Diagonal size 558.68 mm
Active Area 473.76x296.1 mm
(1)
Bezel Opening Area 477.7 (H) x 300.1 (V) mm
Driver Element a-Si TFT active matrix - -
Pixel Number 1680 x R.G.B. x 1050 pixel -
Pixel Pitch 0.282(H) x 0.282(V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7 millions color -
Transmissive Mode Normally White - -
Color saturation 104%NTSC - -
Surface Treatment Hard coating (3H), AG (Haze 25%) - -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 493.2 493.7 494.2 mm
Module Size Vertical(V) 319.6 320.1 320.6 mm (1)
Depth(D) - 21.4 21.9 mm
Weight TBD g
I/F connector mounting The mounting inclination of the connector makes
