Image preview - the first page of the document
![Panel_CMO_M236HGE-P01_0_[DS]](/pics/5c8eca74a49e8.gif)
>> Download Panel_CMO_M236HGE-P01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
Doc. Number :
Tentative Specification
Preliminary Specification
Approval Specification
MODEL NO.: M236HGE
SUFFIX: P01
Customer:
APPROVED BY SIGNATURE
Name / Title
Note
Product Version C1
Please return 1 copy for your confirmation with your
signature and comments.
Approved By Checked By Prepared By
Version 2.0 7 June 2011 1 / 25
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
- CONTENTS -
1. GENERAL DESCRIPTION...................................................................................................................4
1.1 OVERVIEW...................................................................................................................................4
1.2 GENERAL SPECIFICATI0NS.......................................................................................................4
2. MECHANICAL SPECIFICATIONS ......................................................................................................4
3. ABSOLUTE MAXIMUM RATINGS ......................................................................................................5
3.1 ABSOLUTE RATINGS OF ENVIRONMENT...............................................................................5
3.2 ELECTRICAL ABSOLUTE RATINGS..........................................................................................5
3.2.1 TFT LCD MODULE ..........................................................................................................5
3.3 ABSOLUTE RATINGS OF ENVIRONMENT (OPEN CELL).......................................................5
4. ELECTRICAL SPECIFICATIONS..........................................................................................................6
4.1 FUNCTION BLOCK DIAGRAM ..................................................................................................6
4.2. INTERFACE CONNECTIONS .....................................................................................................6
4.3 ELECTRICAL CHARACTERISTICS............................................................................................8
4.4 Vcc POWER DIP CONDITION ...................................................................................................10
4.5 LVDS DATA MAPPING TABLE .................................................................................................10
4.6 COLOR DATA INPUT ASSIGNMENT .......................................................................................11
4.7 DISPLAY TIMING SPECIFICATIONS .......................................................................................12
4.8 POWER ON/OFF SEQUENCE....................................................................................................14
5. OPTICAL CHARACTERISTICS ........................................................................................................15
5.1 TEST CONDITIONS ...................................................................................................................15
5.2 OPTICAL SPECIFICATIONS......................................................................................................15
5.3 Flicker Adjustment .......................................................................................................................19
6. RELIABILITY TEST ITEM ..................................................................................................................20
7. LABEL ..................................................................................................................................................21
7.1 CMI OPEN CELL LABEL...........................................................................................................21
8. PACKING..............................................................................................................................................22
8.1 Packing Information .....................................................................................................................22
8.2 CARTON .....................................................................................................................................22
8.3 PALLET .......................................................................................................................................23
9.1 HANDLING PRECAUTIONS .....................................................................................................24
9.2 SAFETY PRECAUTIONS ...........................................................................................................24
9.3 OTHER ........................................................................................................................................24
10. OUTLINE DRAWING........................................................................................................................25
Version 2.0 7 June 2011 2 / 25
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
REVISION HISTORY
Version Date Page Description
2.0 Jun.07, 2011 All Spec Ver.2.0 was first issued.
Version 2.0 7 June 2011 3 / 25
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
The M236HGE-P01 is a 23.6" TFT LCD cell with driver ICs and a 30-pins-2ch-LVDS circuit board.
The product supports 1920 x 1080 WXGA mode and can display up to 16.7M colors. The backlight unit
is not built in.
1.2 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Screen Size 23.547" real diagonal
Driver Element a-si TFT active matrix - -
Pixel Number 1920 x R.G.B. x 1080 pixel -
Pixel Pitch 0.2715 (H) x 0.2715 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7M color -
Transmissive Mode Normally white - -
Surface Treatment AG type, 3H hard coating, Haze 25 - -
Power Consumption 6.36 Watt -
2. MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Weight - 697 717 g -
I/F connector mounting The mounting inclination of the connector makes
- (2)
