Image preview - the first page of the document

>> Download Panel_CMO_M260J3-L01_0_[DS] documenatation <<

Text preview - extract from the document

Global LCD Panel Exchange Center www.panelook.com
Doc No.: 2407Y054
Issued Date: Dec. 10, 2007
Model No.: M260J3-L01
Preliminary

TFT LCD Preliminary Specification

MODEL NO.: M260J3- L01

Customer:

Approved by:

Note: For Reference Only

2007-12-14 PMMD cs_lee(
Director Accept
18:40:57 CST Director /56510/44926)

1 / 26

Version 1.1

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 2407Y054
Issued Date: Dec. 10, 2007
Model No.: M260J3-L01
Preliminary

- CONTENTS -
REVISION HISTORY ............................................................................................................................ 3

1. GENERAL DESCRIPTION ................................................................................................................ 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS

2. ABSOLUTE MAXIMUM RATINGS ..................................................................................................... 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT

3. ELECTRICAL CHARACTERISTICS .................................................................................................. 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT

4. BLOCK DIAGRAM............................................................................................................................. 11
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT

5. INPUT TERMINAL PIN ASSIGNMENT .............................................................................................. 12
5.1 TFT LCD MODULE
5.2 LVDS DATA MAPPING TABLE
5.3 BACKLIGHT UNIT
5.4 COLOR DATA INPUT ASSIGNMENT

6. INTERFACE TIMING ......................................................................................................................... 15
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE

7. OPTICAL CHARACTERISTICS......................................................................................................... 17
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS

8. PACKAGING ..................................................................................................................................... 21
8.1 PACKING SPECIFICATIONS
8.2 PACKING METHOD

9. DEFINITION OF LABELS.................................................................................................................. 23

10. PRECAUTIONS............................................................................................................................... 24
10.1 ASSEMBLY AND HANDLING PRECAUTIONS
10.2 SAFETY PRECAUTIONS

11. MECHANICAL CHARACTERISTICS ............................................................................................... 25

2 / 26

Version 1.1

REVISION HISTORY

Version Date Section Description

Ver 1.0 Nov.5 , 07' - M260J3 -L01 Preliminary specifications was first issued.
Ver 1.1 Dec.10,07' 3.2 To correct Note(1) Lamp measure method
4.1 To correct Lamp Connector Part No. from YEONHO 20015HS-04LB to YEONHO
5.3 35001HS-02L
7.2 To revise Color chromaticity Green Gy Typ. From 0.611 to 0.601
11. To revise Mechanical Characteristics

3 / 26

Version 1.1

1. GENERAL DESCRIPTION
1.1 OVERVIEW
M260J3-L01 is a 25.54" TFT Liquid Crystal Display module with 4 CCFL Backlight unit and 30 pins
2ch-LVDS interface. This module supports 1920 x 1200 WUXGA mode and can display up to 16.7M colors.
The inverter module for Backlight is not built in.

1.2 FEATURES
- Extra-wide viewing angle.
- High contrast ratio.
- Fast response time.
- High color saturation.
- WUXGA (1920 x 1200 pixels) resolution.
- DE (Data Enable) only mode.
- LVDS (Low Voltage Differential Signaling) interface.
- RoHS compliance.

1.3 APPLICATION
- TFT LCD Monitor

1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 550.08 (H) x 343.8 (V) (25.54" diagonal) mm
(1)
Bezel Opening Area 554.1 (H) x 347.8 (V) mm
Driver Element a-Si TFT active matrix - -
Pixel Number 1920 x R.G.B. x 1200 pixel -
Pixel Pitch 0.2865 (H) x 0.2865 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7M color -
Transmissive Mode Normally White - -
Surface Treatment AG type, 3H hard coating, Haze 25 - -

1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 577.8 578.3 578.8 mm
Module Size Vertical(V) 368.35 368.85 369.35 mm (1)
Depth(D) 22.0 22.5 23.0 mm
Weight - - (4080) g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.

4 / 26

Version 1.1

2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 60
