Image preview - the first page of the document
![Panel_CMO_N133B6-L02_3_[DS]](/pics/5c8ecbd2e06f2.gif)
>> Download Panel_CMO_N133B6-L02_3_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Dcc No.: 400042779
Issued Date: Jun. 28, 2010
Model No.: N133B6-L02
Approval
TFT LCD Approval Specification
MODEL NO.: N133B6-L02
Customer : Samsung
Approved by :
Note :
NB
2010-07-09 2010.07.09 Director Accept
08:32:47
1 / 33
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Dcc No.: 400042779
Issued Date: Jun. 28, 2010
Model No.: N133B6-L02
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 11
4.1 TFT LCD MODULE
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 12
5.1 TFT LCD MODULE
5.2 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.3 COLOR DATA INPUT ASSIGNMENT
5.4 EDID DATA STRUCTURE
6. CONVERTER ------------------------------------------------------- 19
6.1 ABSOLUTE MAXIMUM RATINGS
6.2 RECOMMENDED OPERATING RATINGS
7. INTERFACE TIMING ------------------------------------------------------- 21
7.1 INPUT SIGNAL TIMING SPECIFICATIONS
7.2 POWER ON/OFF SEQUENCE
8. OPTICAL CHARACTERISTICS ------------------------------------------------------- 24
8.1 TEST CONDITIONS
8.2 OPTICAL SPECIFICATIONS
9. PRECAUTIONS ------------------------------------------------------- 28
9.1 HANDLING PRECAUTIONS
9.2 STORAGE PRECAUTIONS
9.3 OPERATION PRECAUTIONS
10. PACKING ------------------------------------------------------- 29
10.1 CARTON
10.2 PALLET
11. DEFINITION OF LABELS ------------------------------------------------------- 31
11.1 CMO MODULE LABEL
11.2 CARTON LABEL
12. MECHANICAL DRAWING ------------------------------------------------------- 33
2 / 33
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Dcc No.: 400042779
Issued Date: Jun. 28, 2010
Model No.: N133B6-L02
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver.3.0 Jan,08,2010 All All Approval spec 3.0 was first issued for N133B6-L02
Ver.3.1 Jun'28,2010 6 2 Update backlight unit.
10 3 Update backlight unit parameter.
19 6 Update LED power current.
24 8 Update color chromaticity.
33 12 Update Label position.
3 / 33
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Dcc No.: 400042779
Issued Date: Jun. 28, 2010
Model No.: N133B6-L02
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
N133B6-L02 is a 13.3" (13.3" diagonal) TFT Liquid Crystal Display module with LED Backlight unit and 40
pins LVDS interface. This module supports 1366 x 768 HD mode and can display 262,144 colors. The
optimum viewing angle is at 6 o'clock direction.
1.2 FEATURES
- HD (1366 x 768 pixels) resolution
- 3.3V LVDS (Low Voltage Differential Signaling) interface with 1 pixel/clock
- WLED
- LED converter embedded
1.3 APPLICATION
- TFT LCD Notebook
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 293.4168 (H) x 164.9664 (V) (13.3" diagonal) mm
(1)
Bezel Opening Area 297.47 (H) x 168.67 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1366 x R.G.B. x 768 pixel -
Pixel Pitch 0.2148 (H) x 0.2148 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 262,144 color -
Transmissive Mode Normally white - -
Surface Treatment Glare, 3H - -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 307.1 307.6 308.1 mm
Module Size Vertical(V) 182.6 183.1 183.6 mm (1)
Thickness(T) - 4.9 5.2 mm
Weight --- 315 330 g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
4 / 33
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Dcc No.: 400042779
Issued Date: Jun. 28, 2010
Model No.: N133B6-L02
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
