Image preview - the first page of the document
![Panel_CMO_N133I6-L03_0_[DS]](/pics/5c8ecc6f208a2.gif)
>> Download Panel_CMO_N133I6-L03_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc No.:
Issued Date: Nov. 20, 2008
Model No.: N133I6 - L03
Approval
TFT LCD Approval Specification
MODEL NO.: N133I6 - L03
Rev. C1
Customer: Apple/ QSMC
Approved by:
Note:
2008-11-26 PMMD III annie_hsu(
Director Accept
18:15:55 CST Director /56522 / 54873)
1 / 28
The information described in this technical specification is tentative and it is possible to be changed without prior
notice. Please contact CMO 's representative while your product design is based on this specification. Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.:
Issued Date: Nov. 20, 2008
Model No.: N133I6 - L03
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 11
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 12
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.4 COLOR DATA INPUT ASSIGNMENT
5.5 EDID DATA STRUCTURE
6. INTERFACE TIMING ------------------------------------------------------- 16
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 18
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PRECAUTIONS ------------------------------------------------------- 22
8.1 HANDLING PRECAUTIONS
8.2 STORAGE PRECAUTIONS
8.3 OPERATION PRECAUTIONS
9. PACKING ------------------------------------------------------- 23
9.1 CARTON
9.2 PALLET
10. DEFINITION OF LABELS ------------------------------------------------------- 25
10.1 CMO MODULE LABEL
10.2 CMO CARTON LABE
10.3 CUSTOMER CARTON LABEL
10.4 CUSTOMER PALLET LABEL
2 / 28
The information described in this technical specification is tentative and it is possible to be changed without prior
notice. Please contact CMO 's representative while your product design is based on this specification. Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.:
Issued Date: Nov. 20, 2008
Model No.: N133I6 - L03
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
3.0 Nov, 20,'08 All All Approval specification was first issued.
3 / 28
The information described in this technical specification is tentative and it is possible to be changed without prior
notice. Please contact CMO 's representative while your product design is based on this specification. Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.:
Issued Date: Nov. 20, 2008
Model No.: N133I6 - L03
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
N133I6 - L03 is a 13.3" TFT Liquid Crystal Display module with LED Backlight unit and 30 pins LVDS
interface. This module supports 1280 x 800 WXGA mode and can display 262,144 colors. The optimum
viewing angle is at 6 o'clock direction. The converter module for Backlight is not built in.
1.2 FEATURES
- Thin and Light Weight
- WXGA (1280 x 800 pixels) resolution
- DE only mode
- 3.3V LVDS (Low Voltage Differential Signaling) interface with 1 pixel/clock
1.3 APPLICATION
- TFT LCD Notebook
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 286.08 (H) x 178.8 (V) mm
(1)
CF Polarizer 289.48 (H) x 182.2 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1280 x R.G.B. x 800 pixel -
Pixel Pitch 0.2235 (H) x 0.2235 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 262,144 color -
Transmissive Mode Normally white - -
Surface Treatment Glare, N2T (Reflection rate< 0.5%), 3H - -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 296.85 297.15 297.45 mm
Module Size Vertical(V) -- 203.15 -- mm (1)
Depth(D) -- -- 3.045 mm
Weight --- 216 219 g -
I/F connector mounting position The mounting inclination of the connector makes the screen (2)
