Image preview - the first page of the document
![Panel_CMO_N140B6-L06_1_[DS]](/pics/5c8ecd2918ba6.gif)
>> Download Panel_CMO_N140B6-L06_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400038865
Issued Date: Nov, 11, 2009
Model No.: N140B6 - L06
Approval
TFT LCD Approval Specification
MODEL NO.: N140B6 - L06
Customer : Samsung
Approved by :
Note :
NB
2009-11-18
2009.11.18 Director Accept
21:52:26
1 / 33
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400038865
Issued Date: Nov, 11, 2009
Model No.: N140B6 - L06
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 3
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 11
4.1 TFT LCD MODULE
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 12
5.1 TFT LCD MODULE
5.2 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.3 COLOR DATA INPUT ASSIGNMENT
5.4 EDID DATA STRUCTURE
6. CONVERTER SPECIFICATION ------------------------------------------------------- 19
6.1 ABSOLUTE MAXIMUM RATINGS
6.2 RECOMMENDED OPERATING RATINGS
7. INTERFACE TIMING ------------------------------------------------------- 21
7.1 INPUT SIGNAL TIMING SPECIFICATIONS
7.2 POWER ON/OFF SEQUENCE
8. OPTICAL CHARACTERISTICS ------------------------------------------------------- 24
8.1 TEST CONDITIONS
8.2 OPTICAL SPECIFICATIONS
9. PRECAUTIONS ------------------------------------------------------- 28
9.1 HANDLING PRECAUTIONS
9.2 STORAGE PRECAUTIONS
9.3 OPERATION PRECAUTIONS
10. PACKING ------------------------------------------------------- 29
10.1 CARTON
10.2 PALLET
11. DEFINITION OF LABELS ------------------------------------------------------- 31
11.1 CMO MODULE LABEL
11.2 CARTON LABEL
12. MECHANICAL DRAWING ------------------------------------------------------- 33
REVISION HISTORY
2 / 33
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400038865
Issued Date: Nov, 11, 2009
Model No.: N140B6 - L06
Approval
Page
Version Date Section Description
(New)
Ver 3.0 Sep. 1,'09 All All Approval specification first issued.
Ver 3.1 Nov. 11,'09 4 1.5 Update mechanical specification
7~8 3.1 Update Note (2)
12 5.1 Update Connector Part No.
19 6 Update converter specification
23 7.2 Update Note (1) ~ (4)
24 8.2 Update optical specification
33 12 Update mechanical drawing
1 GENERAL DESCRIPTION
3 / 33
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400038865
Issued Date: Nov, 11, 2009
Model No.: N140B6 - L06
Approval
1.1 OVERVIEW
N140B6-L06 is a 14.0" TFT Liquid Crystal Display module with LED Backlight unit and 40 pins LVDS
interface. This module supports 1366 x 768 HD mode and can display 262,144 colors. The optimum
viewing angle is at 6 o'clock direction.
1.2 FEATURES
- HD (1366 x 768 pixels) resolution
- 3.3V LVDS (Low Voltage Differential Signaling) interface with 1 pixel/clock
- WLED
- LED converter embedded
1.3 APPLICATION
- TFT LCD Notebook
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 309.40 (H) x 173.95 (V) (14.0" diagonal) mm (1)
Driver Element a-si TFT active matrix - -
Pixel Number 1366 x R.G.B. x 768 pixel -
Pixel Pitch 0.2265 (H) x 0.2265 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 262,144 color -
Transmissive Mode Normally white - -
Surface Treatment Hard coating (3H), glare type - -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 319.9 320.4 320.9 mm
Vertical(V)
W/o PCB and 186.6 187.1 187.6 mm
Bracket
Vertical(V)
Module Size With PCB W/o 198.1 198.6 199.1 mm (1)
Bracket
Vertical(V)
With PCB and 204.6 205.1 205.6 mm
Bracket
Thickness(T) - 3.3 3.6 mm
Weight - 310 325 g
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
4 / 33
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400038865
Issued Date: Nov, 11, 2009
Model No.: N140B6 - L06
Approval
2.ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
