Image preview - the first page of the document
![Panel_CMO_N141XC-L01_6_[DS]](/pics/5c8ececdb47d3.gif)
>> Download Panel_CMO_N141XC-L01_6_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc No.:
Issued Date: Jan.25, 2007
Model No.: N141XC -L01
Approval
TFT LCD Approval Specification
MODEL NO.: N141XC -L01
Customer : Lenovo International
Approved by :
Note :
2007-02-02 Approve by Dept. tomy_chen( Department Accept
21:00:09 CST Mgr.(QA RA) /52720/54140/43150) Manager(QA RA)
2007-01-25 Approve by teren_lin( Director Accept
20:40:40 CST Director /56910/36064)
1 / 28
Version 3.3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.:
Issued Date: Jan.25, 2007
Model No.: N141XC -L01
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 12
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 13
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.4 COLOR DATA INPUT ASSIGNMENT
5.5 EDID DATA STRUCTURE
6. INTERFACE TIMING ------------------------------------------------------- 19
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 21
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PRECAUTIONS ------------------------------------------------------- 25
8.1 HANDLING PRECAUTIONS
8.2 STORAGE PRECAUTIONS
8.3 OPERATION PRECAUTIONS
9. PACKING ------------------------------------------------------- 26
9.1 CARTON
9.2 PALLET
10. DEFINITION OF LABELS ------------------------------------------------------- 27
10.1 CMO MODULE LABEL
10.2 CARTON LABEL
2 / 28
Version 3.3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.:
Issued Date: Jan.25, 2007
Model No.: N141XC -L01
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 3.0 Nov.22. `05 All All Approval Specification was first issued.
Ver 3.1 Dec.07 `05 5 2.1 Modify the temperature of panel surface max value.
28 6.2 Modify carton label.
20 10.2 Modify timing specifications.
Ver 3.2 Dec.27'05 9 3.2 Update backlight unit.
21 7.2 Update optical specification.
22 Update definition of response time.
23 Update measurement setup.
24 Update definition of white variation.
24 Add definition of color gamut.
Ver 3.3 Jan.25'07 16 5.5 Update EDID code
27 10.1 Update P/N , FRU. H/C number in label.
28 Update outline drawing (change CCFL cable length from 25 5mm to 30
5mm)
3 / 28
Version 3.3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.:
Issued Date: Jan.25, 2007
Model No.: N141XC -L01
Approval
1 GENERAL DESCRIPTION
1.1 OVERVIEW
N141XC -L01 is a 14.1" TFT Liquid Crystal Display module with single CCFL Backlight unit and 30 pins
LVDS interface. This module supports 1024 x 768 XGA mode and can display 262,144 colors. The optimum
viewing angle is at 6 o'clock direction. The inverter module for Backlight is not built in.
1.2 FEATURES
- Thin and light weight
- XGA (1024 x 768 pixels) resolution
- DE (Data Enable) only mode
- 3.3V LVDS (Low Voltage Differential Signaling) interface with 1 pixel/clock
- Support EDID Structure Version 1 Revision 3
1.3 APPLICATION
- TFT LCD Notebook
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Outline Dimension 299(W) x 228 (H) mm
Active Area 285.7 (H) x 214.3 (V) (14.1" diagonal) mm (1)
Bezel Opening Area 288.9 (H) x 217.5 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1024 x R.G.B. x 768 pixel -
Pixel Pitch 0.279 (H) x 0.279 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 262,144 color -
Transmissive Mode Normally white - -
Surface Treatment Hardness (2H), Anti-glare (Haze 40),Reflection 3% - -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 298.5 299.0 299.5 mm
Module Size Vertical(V) 227.5 228.0 228.5 mm (1)
Depth(D) 4.9 5.2 5.5 mm
Weight 400 415 g -
I/F connector mounting position The mounting inclination of the connector makes the screen (2)
