Image preview - the first page of the document

>> Download Panel_CMO_N154C1-L02_0_[DS] documenatation <<

Text preview - extract from the document

Global LCD Panel Exchange Center www.panelook.com
Doc No.: 14068310
Issued Date: Oct.26 2006
Model No.: N154C1 -L02
Approval

TFT LCD Approval Specification

MODEL NO.: N154C1 -L02

Customer : ASUS

Approved by :
Note :

2006-11-01 Approve by Dept. tomy_chen( Department Accept
19:12:42 CST Mgr.(QA RA) /52720/54140/43150) Manager(QA RA)

2006-10-26 Approve by teren_lin( Director Accept
17:24:39 CST Director /56910/36064)

1 / 27

Version 3.3

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 14068310
Issued Date: Oct.26 2006
Model No.: N154C1 -L02
Approval

- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3

1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS

2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT

3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT

4. BLOCK DIAGRAM ------------------------------------------------------- 11
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT

5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 12
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.4 COLOR DATA INPUT ASSIGNMENT
5.5 EDID DATA STRUCTURE

6. INTERFACE TIMING ------------------------------------------------------- 18
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE

7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 20
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS

8. PRECAUTIONS ------------------------------------------------------- 24
8.1 HANDLING PRECAUTIONS
8.2 STORAGE PRECAUTIONS
8.3 OPERATION PRECAUTIONS

9. PACKING ------------------------------------------------------- 25
9.1 CARTON
9.2 PALLET

10. DEFINITION OF LABELS ------------------------------------------------------- 26
10.1 CMO MODULE LABEL
10.2 CARTON LABEL

2 / 27

Version 3.3

REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 0.0 Aug. 30. `05 All All Tentative specification first issued.
Ver 1.0 Oct. 13. `05 All All Preliminary specification first issued.
4. 1.4. Modify Surface Treatment
10. 3.2 Modify BACKLIGHT UNIT spec.
17~19 5.5 Modify EDID DATA STRUCTURE
22. 7.2. Modify OPTICAL SPECIFICATIONS
27. 9. Packing specification changed.
Ver 1.1 Dec. 05. `05 All All Preliminary specification updated.
6. 2.1 Modify ABSOLUTE RATINGS OF ENVIRONMENT.
7. 2.2 Modify 2.2.2 BACKLIGHT UNIT
10. 3.2 Modify 3.2 BACKLIGHT UNIT
22. 7.2 Modify 7.2 OPTICAL SPECIFICATIONS
28. 10.2 Modify 10.2 CARTON LABEL
Ver 3.0 Jun. 15. `06 30 - Module drawing update
Ver3.1 Jul. 20. `06 7 3.1 Electrical characteristics/TFT LCD module
12 5.1 Input terminal pin assignment/TFT LCD module
17 6.1 Interface timing/input signal timing specifications
Ver 3.2 Aug. 01. `06 27 Outline drawing update
Ver 3.3 Oct.26. '06 Outline drawing
