Image preview - the first page of the document
![Panel_CMO_N156B3-L04_1_[DS]](/pics/5c8ed22a884ce.gif)
>> Download Panel_CMO_N156B3-L04_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400035397
Issued Date: Dec. 21, 2009
Model No.: N156B3-L04
Approval
TFT LCD Approval Specification
MODEL NO.: N156B3-L04
Customer : Sony
Approved by :
Note :
NB
2009-12-25
2009.12.25 Director Accept
14:21:44
1 / 30
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400035397
Issued Date: Dec. 21, 2009
Model No.: N156B3-L04
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 12
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 13
5.1 TFT LCD MODULE
5.2 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.3 COLOR DATA INPUT ASSIGNMENT
5.4 EDID DATA STRUCTURE
6. INTERFACE TIMING ------------------------------------------------------- 19
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 21
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PRECAUTIONS ------------------------------------------------------- 25
8.1 HANDLING PRECAUTIONS
8.2 STORAGE PRECAUTIONS
8.3 OPERATION PRECAUTIONS
9. PACKING ------------------------------------------------------- 26
9.1 CARTON
9.2 PALLET
10. DEFINITION OF LABELS ------------------------------------------------------- 28
10.1 CMO MODULE LABEL
10.2 CARTON LABEL
11. MECHANICAL DRAWING ------------------------------------------------------- 30
2 / 30
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400035397
Issued Date: Dec. 21, 2009
Model No.: N156B3-L04
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver. 3.0 Jul. 15, 2009 All All Approval specification 3.0 was first issued for Sony.
Ver. 3.1 Dec.21, 2009 All All Approval specification 3.1 was first issued for Sony.
3 / 30
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400035397
Issued Date: Dec. 21, 2009
Model No.: N156B3-L04
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
N156B3-L04 is a 15.6" (15.547" diagonal) TFT Liquid Crystal Display module with single CCFL Backlight
unit and 30 pins LVDS interface. This module supports 1366 x 768 HD mode and can display 262,144
colors. The optimum viewing angle is at 6 o'clock direction. The inverter module for Backlight is not built in.
1.2 FEATURES
- HD (1366 x 768 pixels) resolution
- 3.3V LVDS (Low Voltage Differential Signaling) interface with 1 pixel/clock
1.3 APPLICATION
- TFT LCD Notebook
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
