Image preview - the first page of the document
![Panel_CMO_N156B3-L02_9_[DS]](/pics/5c8ed21bb76b4.gif)
>> Download Panel_CMO_N156B3-L02_9_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400034764
Issued Date: June. 03, 2009
Model No.: N156B3-L02
Approval
TFT LCD Approval Specification
MODEL NO.: N156B3-L02
Customer : HP
Approved by :
Note :
NB
2009-06-26
2009.06.26 Director Accept
11:18:24
1 / 29
Version 3.2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400034764
Issued Date: June. 03, 2009
Model No.: N156B3-L02
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 11
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 12
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.4 COLOR DATA INPUT ASSIGNMENT
5.5 EDID DATA STRUCTURE
5.6 EDID SIGNAL SPECIFICATION
6. INTERFACE TIMING ------------------------------------------------------- 18
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 20
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PRECAUTIONS ------------------------------------------------------- 24
8.1 HANDLING PRECAUTIONS
8.2 STORAGE PRECAUTIONS
8.3 OPERATION PRECAUTIONS
9. PACKING ------------------------------------------------------- 25
9.1 CARTON
9.2 PALLET
10. DEFINITION OF LABELS ------------------------------------------------------- 27
10.1 CMO MODULE LABEL
10.2 CARTON LABEL
2 / 29
Version 3.2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400034764
Issued Date: June. 03, 2009
Model No.: N156B3-L02
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver. 1.0 Mar. 06, 2008 All All Preliminary specification was first issued.
Ver. 2.0 May.13, 2008 P.7 3.1 TFT LCD MODULE
P.18 6.1 INPUT SIGNAL TIMING SPECIFICATIONS
P.20 7.2 OPTICAL SPECIFICATIONS
P.25 9 PACKING
Ver. 3.0 Jul. 20, 2008 P.20 7.2 OPTICAL SPECIFICATIONS
Ver. 3.1 Sep.09, 2008 P.15 5.5 EDID DATA STRUCTURE
Ver. 3.2 June.03,2009 P.4 1.1 &1.2 OVERVIEW & FEATURES
P.5 2.1 The temperature of panel surface specification.
3 / 29
Version 3.2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400034764
Issued Date: June. 03, 2009
Model No.: N156B3-L02
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
N156B3-L02 is a 15.6" (15.547" diagonal) TFT Liquid Crystal Display module with single CCFL Backlight
unit and 30 pins LVDS interface. This module supports 1366 x 768 HD mode and can display 262,144
colors. The optimum viewing angle is at 6 o'clock direction. The inverter module for Backlight is not built in.
1.2 FEATURES
- HD (1366 x 768 pixels) resolution
- 3.3V LVDS (Low Voltage Differential Signaling) interface with 1 pixel/clock
1.3 APPLICATION
- TFT LCD Notebook
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 344.232(H) ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
