Image preview - the first page of the document
![Panel_CMO_N156B3-L0B_3_[DS]](/pics/5c8ed1e1af1ea.gif)
>> Download Panel_CMO_N156B3-L0B_3_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Dcc No.: 400043852
Issued Date: June. 2, 2010
Model No.: N156B3-L0B
Approval
TFT LCD Approval Specification
MODEL NO.: N156B3
Suffix:-L0B
Customer : ASUS
Approved by :
Note :
NB
2010-06-22 2010.06-22 Director Accept
14:23:38
1 / 30
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Dcc No.: 400043852
Issued Date: June. 2, 2010
Model No.: N156B3-L0B
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 11
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 12
5.1 TFT LCD MODULE
5.2 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.3 COLOR DATA INPUT ASSIGNMENT
5.4 EDID DATA STRUCTURE
6. INTERFACE TIMING ------------------------------------------------------- 18
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 20
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PRECAUTIONS ------------------------------------------------------- 24
8.1 HANDLING PRECAUTIONS
8.2 STORAGE PRECAUTIONS
8.3 OPERATION PRECAUTIONS
9. PACKING ------------------------------------------------------- 25
9.1 CARTON
9.2 PALLET
10. DEFINITION OF LABELS ------------------------------------------------------- 27
10.1 CMO MODULE LABEL
10.2 CARTON LABEL
11. MECHANICAL DRAWING ------------------------------------------------------- 29
REVISION HISTORY
2 / 30
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Dcc No.: 400043852
Issued Date: June. 2, 2010
Model No.: N156B3-L0B
Approval
Page
Version Date Section Description
(New)
Ver. 1.0 Jan.08, 2010 All All Preliminary spec 1.0 was first issued for N156B3-L0B
4 1.5 Update module weight
7 3.1 Update Power Supply Current and EBL
18 6.1 Update input signal timing
25 9.1 Update carton drawing
20 7.2 Update optical spec
Ver. 2.0 Jan.18, 2010 20 7.2 Update optical characteristic
25 9.1 Update carton drawing
Ver. 3.0 Jan.29, 2010 All All Approval spec 3.0 is first issued
Ver. 3.1 Jun.2, 2010 26 9 Update package drawing
3 / 30
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Dcc No.: 400043852
Issued Date: June. 2, 2010
Model No.: N156B3-L0B
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
N156B3-L0B is a 15.6" (15.547" diagonal) TFT Liquid Crystal Display module with CCFL Backlight unit
and 30 pins LVDS interface. This module supports 1366 x 768 HD mode and can display 262,144 colors.
The optimum viewing angle is at 6 o'clock direction.
1.2 FEATURES
- HD (1366 x 768 pixels) resolution
- 3.3V LVDS (Low Voltage Differential Signaling) interface
- CCFL
1.3 APPLICATION
- TFT LCD Notebook
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 344.232 (H) x 193.536 (V) (15.547" diagonal) mm
(1)
Bezel Opening Area 349.58 (H) x 198.4 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1366 x R.G.B. x 768 pixel -
Pixel Pitch 0.252 (H) x 0.252 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 262,144 color -
Transmissive Mode Normally white - -
Surface Treatment Hard coating (3H), Glare - -
Backlight Unit 1 CCFL
Power Consumption 5.376 typ/5.475 max@Black Pattern Walt
RoHS Yes
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 358.8 359.3 359.8 mm
Module Size Vertical(V) 209 209.5 210 mm (1)
Thickness(T) - 5.9 6.2 mm
Weight --- 465 480 g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
4 / 30
Version 3.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Dcc No.: 400043852
Issued Date: June. 2, 2010
Model No.: N156B3-L0B
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
