Image preview - the first page of the document
![Panel_CMO_N156B6-L0B_5_[DS]](/pics/5c8ed25e22bce.gif)
>> Download Panel_CMO_N156B6-L0B_5_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400044436
Issued Date: May. 28, 2010
Model No.: N156B6-L0B
Approval
TFT LCD Approval Specification
MODEL NO.: N156B6-L0B
Customer : Acer
Approved by :
Note :
NB
2010-06-02 2010.06.02 Director Accept
10:51:28
1 / 37
Version 3.2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400044436
Issued Date: May. 28, 2010
Model No.: N156B6-L0B
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 4
1. GENERAL DESCRIPTION ------------------------------------------------------- 5
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 6
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 8
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 12
4.1 TFT LCD MODULE
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 13
5.1 TFT LCD MODULE
5.2 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.3 COLOR DATA INPUT ASSIGNMENT
5.4 EDID DATA STRUCTURE
6. CONVERTER ------------------------------------------------------- 20
6.1 ABSOLUTE MAXIMUM RATINGS
6.2 RECOMMENDED OPERATING RATINGS
7. INTERFACE TIMING ------------------------------------------------------- 22
7.1 INPUT SIGNAL TIMING SPECIFICATIONS
7.2 POWER ON/OFF SEQUENCE
8. OPTICAL CHARACTERISTICS ------------------------------------------------------- 25
8.1 TEST CONDITIONS
8.2 OPTICAL SPECIFICATIONS
8.3 GAMMA CURVE CHARACTERISTIC ON COLOR ENGINE
9. PRECAUTIONS ------------------------------------------------------- 29
9.1 HANDLING PRECAUTIONS
9.2 STORAGE PRECAUTIONS
9.3 OPERATION PRECAUTIONS
10. PACKING ------------------------------------------------------- 30
10.1 CARTON
10.2 PALLET
11. DEFINITION OF LABELS ------------------------------------------------------- 32
11.1 CMO MODULE LABEL
11.2 CARTON LABEL
2 / 37
Version 3.2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400044436
Issued Date: May. 28, 2010
Model No.: N156B6-L0B
Approval
12. SYSTEM COVER DESIGN NOTICE ------------------------------------------------------- 34
13. MECHANICAL DRAWING ------------------------------------------------------- 37
3 / 37
Version 3.2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400044436
Issued Date: May. 28, 2010
Model No.: N156B6-L0B
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver. 0.0 Sep.30, 2009 All All Tentative spec 0.0 was first issued for N156B6-L0B
Ver. 1.0 Dec.30, 2009 All All Preliminary spec 1.0 was first issued for N156B6-L0B for Acer
Ver. 3.0 Jan.28, 2010 All All Approval spec 3.0 was first issued for N156B6-L0B for Acer
Ver. 3.1 Mar.04, 2010 p.37 13 Drawing updated for module label.
Ver. 3.2 May.28,2010 p.30 10 Drawing updated for packing changed.
p.33 11.2 Carton label updated.
p.37 13 Drawing updated for PCBA cover changed.
4 / 37
Version 3.2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400044436
Issued Date: May. 28, 2010
Model No.: N156B6-L0B
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
N156B6-L0B is a 15.6" (15.547" diagonal) TFT Liquid Crystal Display module with LED Backlight unit and
40 pins LVDS interface. This module supports 1366 x 768 HD mode and can display 262,144 colors. The
optimum viewing angle is at 6 o'clock direction.
1.2 FEATURES
- HD (1366 x 768 pixels) resolution
- 3.3V LVDS (Low Voltage Differential Signaling) interface with 1 pixel/clock
- WLED
- LED converter embedded
1.3 APPLICATION
- TFT LCD Notebook
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 344.232 (H) x 193.536 (V) (15.547" diagonal) mm
(1)
Bezel Opening Area 349.58 (H) x 198.29 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1366 x R.G.B. x 768 pixel -
Pixel Pitch 0.252 (H) x 0.252 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 262,144 color -
Transmissive Mode Normally white - -
Surface Treatment Hard coating (3H), Glare - -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 358.8 359.3 359.8 mm
Module Size Vertical(V) 209 209.5 210 mm (1)
Thickness(T) - 5.2 5.5 mm
Glass CF 0.45 0.5 0.55 mm
Thickness TFT 0.45 0.5 0.55 mm
Weight --- 430 445 g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
5 / 37
Version 3.2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400044436
Issued Date: May. 28, 2010
Model No.: N156B6-L0B
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
