Image preview - the first page of the document
![Panel_CMO_N170C3-L02_0_[DS]](/pics/5c8ed3bb79a6a.gif)
>> Download Panel_CMO_N170C3-L02_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Aug 10, 2007
Model No.: N170C3 - L02
Approval
TFT LCD Approval Specification
MODEL NO.: N170C3 - L02
Customer : JVC
Approved by :
Note :
2007-08-21 PMMD cs_lee(
Director Accept
14:15:43 CST Director /56510/44926)
1 / 24
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Aug 10, 2007
Model No.: N170C3 - L02
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 11
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 12
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.4 COLOR DATA INPUT ASSIGNMENT
5.5 EDID CODE DATA STRUCTURE
6. INTERFACE TIMING ------------------------------------------------------- 18
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 20
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PRECAUTIONS ------------------------------------------------------- 23
8.1 ASSEMBLY AND HANDLING PRECAUTIONS
8.2 SAFETY PRECAUTIONS
9. PACKING ------------------------------------------------------- 24
9.1 CARTON
9.2 PALLET
10. DEFINITION OF LABELS ------------------------------------------------------- 25
10.1 CMO MODULE LABEL
10.2 CMO CARTON LABEL
2 / 24
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Aug 10, 2007
Model No.: N170C3 - L02
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 3.0 Aug. 10,2007 All All Approval Specification was first issued
3 / 24
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Aug 10, 2007
Model No.: N170C3 - L02
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
N170C3 - L02 is a 17.0" TFT Liquid Crystal Display module with two CCFLs Backlight unit and 30 pins
LVDS interface. This module supports 1440 x 900 Wide-XGA+ mode and can display 16,777,216 colors.
The optimum viewing angle is at 6 o'clock direction. The inverter module for Backlight is not built in.
1.2 FEATURES
- Thin and High Brightness
- WXGA+ (1440 x 900 pixels) resolution
- DE only mode
- 3.3V LVDS (Low Voltage Differential Signaling) interface with 2 pixel/clock
- 2 CCFLs
1.3 APPLICATION
- TFT LCD Notebook
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 367.2 (H) x 229.5 (V) (17.0" diagonal) mm
(1)
Bezel Opening Area 371.2 (H) x 233.5 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1440 x R.G.B. x 900 pixel -
Pixel Pitch 0.255 (H) x 0.255 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16,777,216 color -
Transmissive Mode Normally white - -
Surface Treatment Hard coating (3H), Glare Type - -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 381.7 382.2 382.7 mm
Module Size Vertical (V) 246.3 246.8 247.3 mm (1)
Depth (D) --- 9.7 / 7.9 10.0~8.2 mm
Weight --- 930 960 g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
4 / 24
Version 3.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.:
Issued Date: Aug 10, 2007
Model No.: N170C3 - L02
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
