Global LCD Panel Exchange Center www.panelook.com
Doc. No.: 14074327
Issued Date: Dec. 05, 2007
Model No.: N201J4 - L01
Approval
TFT LCD Approval Specification
MODEL NO.: N201J4 - L01
Customer :
Approved by :
Note :
2007-12-12 PMMD cs_lee(
Director Accept
14:04:41 CST Director /56510/44926)
1 / 30
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.: 14074327
Issued Date: Dec. 05, 2007
Model No.: N201J4 - L01
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 11
4.1 TFT LCD MODULE
4.2 BACKLIGHT UNIT
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 12
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 TIMING DIAGRAM OF LVDS INPUT SIGNAL
5.4 COLOR DATA INPUT ASSIGNMENT
5.5 EDID CODE DATA STRUCTURE
6. INTERFACE TIMING ------------------------------------------------------- 18
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 20
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PRECAUTIONS ------------------------------------------------------- 23
8.1 ASSEMBLY AND HANDLING PRECAUTIONS
8.2 SAFETY PRECAUTIONS
9. PACKING ------------------------------------------------------- 24
9.1 CARTON
9.2 PALLET
10. DEFINITION OF LABELS ------------------------------------------------------- 25
10.1 CMO MODULE LABEL
10.2 CMO CARTON LABEL
2 / 30
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.: 14074327
Issued Date: Dec. 05, 2007
Model No.: N201J4 - L01
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 2.0 Dec. 05,2007 All All Approval specification is first issued
3 / 30
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.: 14074327
Issued Date: Dec. 05, 2007
Model No.: N201J4 - L01
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
N201J4 - L01 is a 20.1" TFT Liquid Crystal Display module with two CCFLs Backlight unit and 40 pins
LVDS interface. This module supports 1920 x 1200 Wide-WUXGA mode and can display 16,777,216 colors.
The optimum viewing angle is at 6 o'clock direction. The inverter module for Backlight is not built in.
1.2 FEATURES
- Thin and High Brightness
- WUXGA (1920 x 1200 pixels) resolution
- DE only mode
- 5.0V LVDS (Low Voltage Differential Signaling) interface with 2 pixel/clock
- 2 CCFLs
1.3 APPLICATION
- TFT LCD Notebook
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 433.44 (H) x 270.9 (V) (20.1" diagonal) mm
(1)
Bezel Opening Area 437.2 (H) x 274.7 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1920 x R.G.B. x 1200 pixel -
Pixel Pitch 0.22575 (H) x 0.22575 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16,777,216 color -
Transmissive Mode Normally white - -
Surface Treatment Hard coating (3H), Glare Type - -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 453 453.5 454 mm
Module Size Vertical (V) 296 296.5 297 mm (1)
Depth (D) --- 8.3 8.6 mm
Weight --- 1385 1400 g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
4 / 30
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc. No.: 14074327
Issued Date: Dec. 05, 2007
Model No.: N201J4 - L01
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
