Image preview - the first page of the document
![Panel_CMO_V215H1-LE1_0_[DS]](/pics/5c8ed4a3e58fb.gif)
>> Download Panel_CMO_V215H1-LE1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
Tentative Specification
Preliminary Specification
Approval Specification
MODEL NO.: V215H1
SUFFIX: LE1
Customer:
APPROVED BY SIGNATURE
Name / Title
Note
Please return 1 copy for your confirmation with your
signature and comments.
Approved By Checked By Prepared By
Chao-Chun Chung Roger Huang Vita Wu
Version 2.2 1 Date 06 Dec 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
CONTENTS
1. GENERAL DESCRIPTION ......................................................................................................................................................... 5
1.1 OVERVIEW ......................................................................................................................................................................... 5
1.2 FEATURES .......................................................................................................................................................................... 5
1.3 APPLICATION ................................................................................................................................................................... 5
1.4 GENERAL SPECIFICATIONS.......................................................................................................................................... 5
1.5 MECHANICAL SPECIFICATIONS................................................................................................................................. 6
2. ABSOLUTE MAXIMUM RATINGS .......................................................................................................................................... 7
2.1 ABSOLUTE RATINGS OF ENVIRONMENT ................................................................................................................ 7
2.2 PACKAGE STORAGE ....................................................................................................................................................... 8
2.3 ELECTRICAL ABSOLUTE RATINGS ............................................................................................................................. 8
2.3.1 TFT LCD MODULE................................................................................................................................................. 8
3. ELECTRICAL CHARACTERISTICS ......................................................................................................................................... 9
3.1 TFT LCD MODULE ........................................................................................................................................................... 9
3.2 BACKLIGHT CONNECTOR PIN CONFIGURATION .............................................................................................. 11
3.2.2 LIGHTBAR Connector Pin Assignment ............................................................................................................. 12
3.3 LVDS INPUT SIGNAL SPECIFICATIONS................................................................................................................... 12
3.3.1 LVDS DATA MAPPING TABLE......................................................................................................................... 13
4. BLOCK DIAGRAM OF INTERFACE ...................................................................................................................................... 13
4.1 TFT LCD MODULE ......................................................................................................................................................... 13
5. INPUT TERMINAL PIN ASSIGNMENT................................................................................................................................ 14
5.1 TFT LCD Module Input................................................................................................................................................... 14
5.2 BLOCK DIAGRAM OF INTERFACE ............................................................................................................................ 15
5.3 LVDS INTERFACE........................................................................................................................................................... 17
5.4 COLOR DATA INPUT ASSIGNMENT......................................................................................................................... 18
6. INTERFACE TIMING................................................................................................................................................................ 19
6.1 INPUT SIGNAL TIMING SPECIFICATIONS .............................................................................................................. 19
6.2 POWER ON/OFF SEQUENCE ...................................................................................................................................... 22
7. OPTICAL CHARACTERISTICS............................................................................................................................................... 24
7.1 TEST CONDITIONS ........................................................................................................................................................ 24
7.2 OPTICAL SPECIFICATIONS ......................................................................................................................................... 25
Version 2.2 2 Date 06 Dec 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
8. PRECAUTIONS .......................................................................................................................................................................... 28
8.1 ASSEMBLY AND HANDLING PRECAUTIONS........................................................................................................ 28
8.2 SAFETY PRECAUTIONS ................................................................................................................................................ 28
9. DEFINITION OF LABELS......................................................................................................................................................... 29
9.1 CMI MODULE LABEL .................................................................................................................................................... 29
10. PACKAGING............................................................................................................................................................................ 30
10.1 PACKAGING SPECIFICATIONS ................................................................................................................................ 30
10.2 PACKAGING METHOD............................................................................................................................................... 30
11. MECHANICAL CHARACTERISTIC .................................................................................................................................... 32
Version 2.2 3 Date 06 Dec 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
REVISION HISTORY
Version Date Page(New) Section Description
Ver. 2.0 Apr., 20, 10 All All V215H1-LE1 Approval Specifications was first issued.
Ver. 2.1 Sept., 22, 10 All All Approval Specifications Change Spec. Format.
Ver. 2.2 Dec., 06, 10 Page 5 1.4 Modify pixel pitch
Version 2.2 4 Date 06 Dec 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V215H1-LE2 is a 21.5" TFT Liquid Crystal Display module with WLED Backlight unit and 30 pins
2ch-LVDS interface. This module supports 1920 x 1080 Full HDTV format and can display up to 16.7M
colors. The converter module for Backlight is not built in.
1.2 FEATURES
Extra-wide viewing angle.
High contrast ratio.
Fast response time.
High color saturation.
Full HD (1920 x 1080 pixels) resolution.
DE (Data Enable) only mode.
LVDS (Low Voltage Differential Signaling) interface.
RoHS compliance.
1.3 APPLICATION
Standard Living Room TVs
MFM Application
1.4 GENERAL SPECIFICATIONS
Item Specification Unit Note
Active Area 476.64(H) x 268.11(V) (21.53" diagonal) mm
(1)
Bezel Opening Area 479.8 (H) x 271.3 (V) mm
Driver Element a-si TFT active matrix
Pixel Number 1920 x R.G.B. x 1080 pixel
Pixel Pitch(Sub Pixel) 0.08275(H) x 0.24825(V) mm
Pixel Arrangement RGB vertical stripe
Power consumption 15.28W (LVDS input Power 5.3W + LED Backlight Power 9.98 W) Watt (2)
Display Colors 16.7M color
Display Operation Mode Transmissive mode / Normally white
Surface Treatment Anti-Glare coating (Haze 25%) (3)
Note (1) Please refer to the attached drawings in chapter 9 for more information about the front and back outlines.
Note (2) Please refer sec 3.1 and 3.2 for more information of Power consumption
Note (3) The spec. of the surface treatment is temporarily for this phase. CMI reserves the rights to change this feature.
Version 2.2 5 Date 06 Dec 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 495.1 495.6 496.1 mm (1)
Module Size Vertical (V) 291.7 292.2 292.7 mm (1)
Depth (D) 11.0 11.5 12.0 mm (1)
Weight 2010 2060 g
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Version 2.2 6 Date 06 Dec 2010
The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT SPECIFICATION
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
