Image preview - the first page of the document
![Panel_CMO_V236H1-P02_0_[DS]](/pics/5c8ed4ffbf3b4.gif)
>> Download Panel_CMO_V236H1-P02_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400039934
Issued Date: Oct.19, 2009
Model No.: V236H1-P02
Approval
TFT LCD Approval Specification
MODEL NO.: V236H1-P02
Customer :
Approved by :
Note :
MTR
2009-10-29 2009.10.29 Director Accept
08:48:46
1 / 24
Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400039934
Issued Date: Oct.19, 2009
Model No.: V236H1-P02
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT (BASED ON CMO MODULE V236H1-L01)
2.2 ABSOLUTE RATINGS OF ENVIRONMENT (OPEN CELL)
2.3 ELECTRICAL ABSOLUTE RATINGS (OPEN CELL)
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 6
3.1 TFT LCD OPEN CELL
3.2 Vcc POWER DIP CONDITION
4. BLOCK DIAGRAM ------------------------------------------------------- 8
4.1 TFT LCD OPEN CELL
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 9
5.1 TFT LCD MODULE
5.2 LVDS DATA MAPPING TABLE
5.3 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 12
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 15
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
7.3 FLICKER ADJUSTMENT
8. PACKAGING ------------------------------------------------------- 19
8.1 PACKING SPECIFICATIONS
8.2 PACKING METHOD
9. DEFINITION OF LABELS ------------------------------------------------------- 21
9.1 OPEN CELL LABEL
9.2 CARTON LABEL
10. RELIABILITY TEST ------------------------------------------------------- 22
11. PRECAUTIONS ------------------------------------------------------- 23
11.1 ASSEMBLY AND HANDLING PRECAUTIONS
11.2 SAFETY PRECAUTIONS
11.3 OTHER
12. MECHANICAL DRAWING ------------------------------------------------------- 24
2 / 24
Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400039934
Issued Date: Oct.19, 2009
Model No.: V236H1-P02
Approval
REVISION HISTORY
Version Date Section Description
Ver. 2.0 Sep, 16, '09 - V236H1-P02 Approval Specifications was first issued.
Ver. 2.1 Oct, 19, '09 1.5 Modified weight Column "Typ." and "Max."
3.1 Modified the value of Maximum Logic High Input Voltage from "3.3" to "3.6".
Removed "Minimum" and "Maximum" value of LVDS common input voltage .
3 / 24
Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Doc No.: 400039934
Issued Date: Oct.19, 2009
Model No.: V236H1-P02
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
The V236H1-P02 is a 23.6-inch wide TFT LCD open cell with driver ICs and a 30-pins-2ch-LVDS circuit
board. The product supports 1920 x 1080 Full HD mode and can display up to 16.7M colors. The backlight
unit is not built in.
1.2 FEATURES
- Super wide viewing angle
- High contrast ratio
- Fast response time
- High color saturation
- Full HDTV (1920 x 1080 pixels) resolution
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- RoHS Compliance
1.3 APPLICATION
- TFT LCD Monitor/TV
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Diagonal Size 23.547 inch
Active Area 521.28 (H) x 293.22 (V) mm (1)
Driver Element a-Si TFT active matrix - -
Pixel Number 1920 x R.G.B. x 1080 pixel -
Pixel Pitch 0.2715 (H) x 0.2715 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7M color -
Transmissive Mode Normally White - -
Surface Treatment Hard coating (3H), Anti-glare (Haze 25%) - -
Power Consumption 4.5 Watt (3)
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Weight - 706 - g -
I/F connector mounting The mounting inclination of the connector makes
- (2)
position the screen center within ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
