Image preview - the first page of the document
![Panel_CMO_V260B1-L02_1_[DS]](/pics/5c8ed51cd6aaf.gif)
>> Download Panel_CMO_V260B1-L02_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Mar. 29, 2007
Model No.: V260B1 - L02
Approval
TFT LCD Preliminary Specification
MODEL NO.: V260B1 - L02
Customer:
Approved by:
Note:
TV Head Division
Approved By
LY Chen
QRA Dept. Product Development Div.
Reviewed By
Tomy Chen WT Lin
LCD TV Marketing and Product Management Div.
Prepared By
Denise Shieh Hui-I Wen!
1
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Mar. 29, 2007
Model No.: V260B1 - L02
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 PACKAGE STORAGE
2.3 ELECTRICAL ABSOLUTE RATINGS
2.3.1 ELECTRICAL ABSOLUTE RATINGS (OPEN CELL)
2.3.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 RSDS CHARACTERISTICS
3.3 BACKLIGHT INVERTER UNIT
3.3.1 CCFL (Cold Cathode Fluorescent Lamp) CHARACTERISTICS
3.3.2 CMO INVERTER JIG CHARACTERISTICS
4. BLOCK DIAGRAM ------------------------------------------------------- 9
4.1 TFT LCD MODULE
5. PIN CONNECTION ------------------------------------------------------- 10
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 13
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 16
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. DEFINITION OF LABELS ------------------------------------------------------- 20
8.1 CMO MODULE LABEL
9. PACKAGING ------------------------------------------------------- 21
9.1 PACKING SPECIFICATIONS
9.2 PACKING METHOD
10. PRECAUTIONS ------------------------------------------------------- 23
10.1 ASSEMBLY AND HANDLING PRECAUTIONS
10.2 SAFETY PRECAUTIONS
10.3 STORAGE PRECAUTIONS
11. MECHANICAL CHARACTERISTICS ------------------------------------------------------- 24
2
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Mar. 29, 2007
Model No.: V260B1 - L02
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 2.0 Mar. 29,'07 All All Approval Specification was first issued.
3
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Mar. 29, 2007
Model No.: V260B1 - L02
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V260B1- L02 is a 26" TFT Liquid Crystal Display module with 8-CCFL Backlight unit and RSDS interface.
This module supports 1366 x 768 WXGA format and can display 16.2M colors (6-bits+FRC colors).
1.2 FEATURES
- Brightness 400nits
- Contrast ratio 800:1
- Fast response time (8ms)
- Color saturation NTSC 72%
- Viewing angle: 160(H)/150(V) (CR>10) TN technology
- RSDS (Reduced Swing Differential Signaling) interface
- Color reproduction (Nature color)
- RoHS compliance
1.3 APPLICATION
- TFT LCD TVs
- Multi-Media Display
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 575.769 (H) x 323.712 (V) (26" Diagonal) mm
(1)
Bezel Opening Area 580.8 (H) x 328.8 (V) mm
Driver Element a-si TFT Active Matrix -
Pixel Number 1366 x R.G.B. x 768 pixel
Pixel Pitch (Sub Pixel) 0.1405 (H) x 0.4215 (V) mm
Pixel Arrangement RGB Vertical Stripe -
Display Colors 16.2M color
Display Operation Mode Transmissive Mode / Normally White -
Anti-Glare Coating (Haze 25%)
Surface Treatment -
Hard Coating (3H)
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 625 626 627 mm (1)
Module Size Vertical(V) 372 373 374 mm (1)
Depth(D) 41.44 42.44 43.44 mm To Rear
Weight 4500 g
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
4
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Mar. 29, 2007
Model No.: V260B1 - L02
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
