Image preview - the first page of the document
![Panel_CMO_V260H1-LE1_1_[DS]](/pics/5c8ed5a80b4ca.gif)
>> Download Panel_CMO_V260H1-LE1_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Issued Date: 30, Nov. 2010
Model No.: V260H1 LE1
Approval
TFT LCD Approval Specification
MODEL NO.: V260H1- LE1
Customer:
Approved by:
Note:
TV Product Marketing & Management Div
Approved By
Chao-Chun Chung
QA Dept. Product Development Div.
Reviewed By
Hsin-nan Chen TC Pan
LCD TV Marketing and Product Management Div.
Prepared By
Vincent Chou Delia Lin
1
Version 6.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: 30, Nov. 2010
Model No.: V260H1 LE1
Approval
CONTENTS -
1. GENERAL DESCRIPTION...................................................................................................................................... 5
1.1 OVERVIEW .................................................................................................................................................. 5
1.2 FEATURES .................................................................................................................................................. 5
1.3 APPLICATION .............................................................................................................................................. 5
1.4 GENERAL SPECIFICATI0NS ....................................................................................................................... 5
1.5 MECHANICAL SPECIFICATIONS ................................................................................................................ 5
2. ABSOLUTE MAXIMUM RATINGS........................................................................................................................... 6
2.1 ABSOLUTE RATINGS OF ENVIRONMENT.................................................................................................. 6
2.2 ELECTRICAL ABSOLUTE RATINGS............................................................................................................ 7
3. ELECTRICAL CHARACTERISTICS........................................................................................................................ 7
3.1 TFT LCD MODULE....................................................................................................................................... 7
3.2 BACKLIGHT UNIT ........................................................................................................................................ 9
4. BLOCK DIAGRAM OF INTERFACE...................................................................................................................... 10
4.1 TFT LCD MODULE..................................................................................................................................... 10
5. INTERFACE PIN CONNECTION .......................................................................................................................... 11
5.1 TFT LCD MODULE..................................................................................................................................... 11
5.2 BACKLIGHT UNIT ...................................................................................................................................... 13
5.3 BLOCK DIAGRAM OF INTERFACE ........................................................................................................... 14
5.4 LVDS INTERFACE ..................................................................................................................................... 16
5.5 COLOR DATA INPUT ASSIGNMENT.......................................................................................................... 17
6. INTERFACE TIMING ............................................................................................................................................ 18
6.1 INPUT SIGNAL TIMING SPECIFICATIONS ................................................................................................ 18
6.2 POWER ON/OFF SEQUENCE ................................................................................................................... 21
7. OPTICAL CHARACTERISTICS ............................................................................................................................ 22
7.1 TEST CONDITIONS ................................................................................................................................... 22
7.2 OPTICAL SPECIFICATIONS ...................................................................................................................... 22
8. DEFINITION OF LABELS ..................................................................................................................................... 26
8.1 CMO MODULE LABEL............................................................................................................................... 26
9. PACKAGING......................................................................................................................................................... 27
9.1 PACKING SPECIFICATIONS...................................................................................................................... 27
9.2 PACKING METHOD ................................................................................................................................... 27
10. PRECAUTIONS.................................................................................................................................................. 29
10.1 ASSEMBLY AND HANDLING PRECAUTIONS ......................................................................................... 29
10.2 SAFETY PRECAUTIONS ......................................................................................................................... 29
10.3 STORAGE PRECAUTIONS...................................................................................................................... 29
11. REGULATORY STANDARDS.............................................................................................................................. 30
11.1 SAFETY ................................................................................................................................................... 30
2
Version 6.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: 30, Nov. 2010
Model No.: V260H1 LE1
Approval
12. MECHANICAL CHARACTERISTIC..................................................................................................................... 31
3
Version 6.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: 30, Nov. 2010
Model No.: V260H1 LE1
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 6.0 Nov. 30,'10 All All Approval Specification was first issued.
4
Version 6.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: 30, Nov. 2010
Model No.: V260H1 LE1
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V260H1- LE1 is a TFT Liquid Crystal Display module with LED Backlight unit and 2ch-LVDS interface. The
display diagonal is 26". This module supports 1920 x 1080 Full HDTV format and can display 16.7M colors
(8-bit/color).
1.2 FEATURES
- Optimized Brightness 320nits
- Contrast Ratio 800:1
- Fast Response Time 5ms
- Color Saturation NTSC 72%
- Full HDTV (1920 x 1080 pixels) resolution, true HDTV format
- DE (Data Enable) Only Mode
- LVDS (Low Voltage Differential Signaling) Interface
- Viewing Angle: 160(H)/150(V) (CR>10) TN Technology
- Color Reproduction (Nature Color)
1.3 APPLICATION
-TFT LCD TVs
-Optimized Brightness, Multi-Media Displays
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 576(H) x 324(V) (26.02" diagonal) mm
(1)
Bezel Opening Area 580.2(H) x 328.2 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1920x R.G.B. x 1080 pixel -
Pixel Pitch(Sub Pixel) 0.100 (H) x 0.300 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7M color -
Display Operation Mode Transmissive mode / Normally White - -
Anti-Glare coating (Haze 25%)
Surface Treatment - (2)
Hard Coating (3H)
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 612 613 614 mm Module Size
Vertical (V) 360 361 362 mm
Module Size
9.3 10.3 11.3 mm To Rear
Weight Depth (D)
13.8 14.8 15.8 mm To PCB Protector
Weight 2600 g
Note (1)Please refer to the attached drawings for more information of front and back outline dimensions.
Note (2) Module Depth does not include connectors.
5
Version 6.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: 30, Nov. 2010
Model No.: V260H1 LE1
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
