Image preview - the first page of the document
![Panel_CMO_V296W1-L14_0_[DS]](/pics/5c8ed6014ac68.gif)
>> Download Panel_CMO_V296W1-L14_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
DCC No.:24044112
Issued Date: Dec. 31, 2004
Model No.: V296W1 - L14
Approval
TFT LCD Approval Specification
MODEL NO.: V296W1 - L14
Customer:
Approved by:
Note:
LCD TV Head Division
Director
Liquid Crystal Display Division
QRA Dept. DDIII DDII DDI
Approval Approval Approval Approval
LCD TV Marketing and Product Management Dept.
Project Manager
1-
The information described in this technical specification is tentative and it is possible to be changed without prior notice.
Please contact CMO 's representative while your product design is based on this specification. Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
DCC No.:24044112
Issued Date: Dec. 31, 2004
Model No.: V296W1 - L14
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 6
3.1 TFT LCD MODULE
3.2 BACKLIGHT INVERTER UNIT
4. BLOCK DIAGRAM ------------------------------------------------------- 11
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 12
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 INVERTER UNIT
5.4 BLOCK DIAGRAM OF INTERFACE
5.5 LVDS INTERFACE
5.6 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 18
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 20
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PACKAGING ------------------------------------------------------- 24
8.1 PACKING SPECIFICATIONS
8.2 PACKING Method
9. DEFINITION OF LABLES ------------------------------------------------------- 26
10. PRECAUTIONS ------------------------------------------------------- 27
10.1 ASSEMBLY AND HANDLING PRECAUTIONS
10.2 SAFETY PRECAUTIONS
11.MECHANICAL CHARACTERISTICS ------------------------------------------------------- 28
2-
The information described in this technical specification is tentative and it is possible to be changed without prior notice.
Please contact CMO 's representative while your product design is based on this specification. Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
DCC No.:24044112
Issued Date: Dec. 31, 2004
Model No.: V296W1 - L14
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 2.0 Dec.26,'03 All All Approval Specification was first issued.
Ver 2.1 Dec.24,'04 4 1.2 High contrast ratio (600:1) (800:1)
12 5.1 Connector Part No.: FI-SE30P-HF (JAE) FI-SE30P-HFE (JAE)
13 5.2 Note(1)The mating connector on inverter part number is
SM02(8.0)-BHS-1-TB SM02(8.0)B-BHS-1-TB(LF)
Note(2)The mating connector on inverter part number is
S2B-ZR-SM3A-TF S2B-ZR-SM4A-TF(LF)
14 5.3 CN1:S10B-PH-SM3-TB S10B-PH-SM3-TB(D)(LF)
CN2: S12B-PH-SM3-TB S12B-PH-SM3-TB(D)(LF)
CN3~10: SM02(8.0)B-BHS-1-TB(JST)
SM02(8.0)B-BHS-1-TB(LF)(JST)
CN11: S2B-ZR-SM3A-TF(JST) S2B-ZR-SM4A-TF(LF)(JST)
20 7.2 Contrast Ratio
Min. 400 600
Typ. 600 800
Response Time Gray to Gray:
Typ. 16.6 8
Max. 25 12
21 7.2 Note(3) Definition of Gray to Gray Switching Time
25 8.2 Figure. 8-2 Packing method
3-
The information described in this technical specification is tentative and it is possible to be changed without prior notice.
Please contact CMO 's representative while your product design is based on this specification. Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
DCC No.:24044112
Issued Date: Dec. 31, 2004
Model No.: V296W1 - L14
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V296W1- L14 is a 30" TFT Liquid Crystal Display module with 16-CCFL Backlight unit and 1ch-LVDS
interface. This module supports 1280 x 768 WXGA format and can display true 16.7M colors ( 8-bit/color).
The inverter module for backlight is built-in.
1.2 FEATURES
